ABSTRACT: The Swordfish Scalable Storage Management API defines a RESTful interface and a standardized data model to provide a scalable, customer-centric interface for managing storage and related data services.
Publication of this Working Draft for review and comment has been approved by the Scalable Storage Management Technical Work Group. This draft represents a ‘best effort’ attempt by the Scalable Storage Management Technical Work Group to reach preliminary consensus, and it may be updated, replaced, or made obsolete at any time. This document should not be used as reference material or cited as other than a ‘work in progress.’ Suggestions for revision should be directed to http://www.snia.org/feedback.
This document has been released and approved by the SNIA. The SNIA believes that the ideas, methodologies, and technologies described in this document accurately represent the SNIA goals and are appropriate for widespread distribution. Suggestion for revision should be directed to http://www.snia.org/feedback/.
Copyright (c) 2016 - 2021 SNIA. All rights reserved. All other trademarks or registered trademarks are the property of their respective owners.
The SNIA hereby grants permission for individuals to use this document for personal use only, and for corporations and other business entities to use this document for internal use only (including internal copying, distribution, and display) provided that:
Any text, diagram, chart, table or definition reproduced must be reproduced in its entirety with no alteration, and,
Any document, printed or electronic, in which material from this document (or any portion hereof) is reproduced must acknowledge the SNIA copyright on that material, and must credit the SNIA for granting permission for its reuse.
Other than as explicitly provided above, you may not make any commercial use of this document, or any portion thereof, or distribute this document to third parties. All rights not explicitly granted are expressly reserved to SNIA.
Permission to use this document for purposes other than those enumerated above may be requested by emailing tcmd@snia.org. Please include the identity of the requesting individual and/or company and a brief description of the purpose, nature, and scope of the requested use.
All code fragments, scripts, data tables, and sample code in this SNIA document are made available under the following license:
BSD 3-Clause Software License
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of The Storage Networking Industry Association (SNIA) nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The information contained in this publication is subject to change without notice. The SNIA makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. The SNIA shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use.
Suggestions for revisions should be directed to http://www.snia.org/feedback/.
Current SNIA practice is to make updates and other information available through their web site at http://www.snia.org.
Requests for interpretation, suggestions for improvement and addenda, or defect reports are welcome. They should be sent via the SNIA Feedback Portal at http://www.snia.org/feedback/ or by mail to the Storage Networking Industry Association, 4360 ArrowsWest Drive, Colorado Springs, Colorado 80907, U.S.A.
This document is intended for use by individuals and companies engaged in storage management.
This document is versioned material. Versioned material shall have a three-level revision identifier, comprised of a version number ‘v’, a release number ‘r’ and an errata number ‘e’. Future publications of this document are subject to specific constraints on the scope of change that is permissible from one revision to the next and the degree of interoperability and backward compatibility that should be assumed between products designed to this standard. This versioning policy applies to all SNIA Swordfish versioned materials.
Version Number: Versioned material having version number ‘v’ shall be backwards compatible with all of revisions of that material that have the same version number ‘v’. There is no assurance of interoperability or backward compatibility between revisions of a versioned material with different version numbers.
Release Number: Versioned material with a version number ‘v’ and release number ‘r’ shall be backwards compatible with previous revisions of the material with the same version number, and a lower release number. A minor revision represents a technical change to existing content or an adjustment to the scope of the versioned material. Each minor revision causes the release number to be increased by one.
Errata Number: Versioned material having version number ‘v’, a release number ‘r’, and an errata number ‘e’ should be backwards compatible with previous revisions of the material with the same version number and release number (“errata versions”). An errata revision of versioned material is limited to minor corrections or clarifications of existing versioned material. An errata revision may be backwards incompatible, if the incompatibility is necessary for correct operation of implementations of the versioned material.
The evolution of this document is summarized in Table .
Date | Rev | Notes |
---|---|---|
19 September 2016 | 1.0.0 | Initial Release |
12 October 2016 | 1.0.1 | General clean up and formatting consistency |
A discussion of unused CoS and LoS entries in ServiceCatalog | ||
Improve purpose for many use cases | ||
1 November 2016 | 1.0.2 | Corrected XREF link formatting |
24 January 2017 | 1.0.3 | Additional use cases and new document section addressing client considerations |
25 April 2017 | 1.0.4 | Update cross-references |
3 October 2017 | 1.0.5 | Minor updates and corrections |
13 February 2018 | 1.0.6 | Added on-demand replication use cases |
12 October 2018 | 1.0.7 | Editorial cleanup of JSON |
22 August 2019 | 1.1.0 | Restructured to add features and feature cross references, and many new use cases added: |
Create Volume for multiple scenarios (including Redfish Storage) | ||
Create Storage Pool for multiple scenarios | ||
Replication use cases using single Volume | ||
Replication use cases using Consistency Groups | ||
12 November 2019 | 1.1.0 | Released as Technical Position |
12 November 2019 | 1.1.0a | Released as Corrected Technical Position |
Formatting fixes – word wrap in pdf doc format to fix truncated lines | ||
Added cross referencing of Features to use cases | ||
Editorial changes and cleanup | ||
18 August 2020 | 1.2.1 | Added NVMe-specific use cases |
31 October 2020 | 1.2.1c | Released as SNIA Approved Publication |
2 March 2021 | 1.2.2 | Added cross-references to NVMe mapping document |
Added new use cases for StoragePool actions. | ||
Errata fixes. | ||
14 June 2021 | 1.2.2a | Released as SNIA Approved Publication |
30 August 2021 | 1.2.3 | Update references in examples |
Add use cases for ChangeRAIDType, ChangeSpanCount. | ||
5 December 2021 | 1.2.3 | Release as SNIA Approved Publication |
The Storage Networking Industry Association (SNIA) is a non-profit organization made up of member companies spanning information technology. A globally recognized and trusted authority, SNIA’s mission is to lead the storage industry in developing and promoting vendor-neutral architectures, standards and educational services that facilitate the efficient management, movement and security of information.
The SNIA Scalable Storage Management Technical Work Group, which developed and reviewed this work in progress, would like to recognize the significant contributions made by the following members listed in Table .
Member | Representatives (* – prior employer) |
---|---|
Broadcom Inc. | Richelle Ahlvers * |
Cisco Systems, Inc. | Krishnakumar Gowravaram |
Dell Inc. | Patrick Boyd |
George Ericson Jim Pendergraft Sean McGinnis Michael Raineri Rich Roscoe |
|
George Ericson | |
Jim Pendergraft | |
Sean McGinnis | |
Michael Raineri | |
Rich Roscoe | |
Futurewei Inc. | Sean McGinnis * |
Hitachi Data Systems | Eric Hibbard |
Hewlett Packard Enterprise | Curtis Ballard |
Jeff Hilland | |
Chris Lionetti | |
John Mendonca | |
Doug Voigt | |
Inova Development Inc. | Karl Schopmeyer |
Intel Corporation | Richelle Ahlvers |
Rajalaxmi Angadi | |
Klaudia Jablonska | |
Mariusz Krzywienski | |
Slawek Putyrski | |
Paul von Behren | |
Microsemi Corporation | Anand Nagarjan |
Microsoft Corporation | Hector Linares |
Jim Pinkerton | |
Michael Pizzo | |
Scott Seligman | |
NetApp, Inc. | Don Deel |
Fred Knight | |
Nilesh Maheshwari | |
ScienceLogic | Patrick Strick |
VMware, Inc. | Murali Rajagopal |
1. Introduction
1.1. Audience
1.2. Documentation structure
1.3. Implementation scope assumptions
1.4. Base implementation assumptions
1.5. Knowledge assumptions
1.6. Related documents
2. General query syntax { .page_break_before }
2.1. Query method
2.2. Query Headers
2.2.1. Request headers
2.2.2. Response headers
2.3. Service root
2.4. Resource path
2.5. Query options
2.6. Filter expressions
2.7. HTTP status codes
3. Actors
3.1. Actors
3.2. CloudAdmin
3.2.1. Use Cases
3.3. DevOps
3.3.1. Use Cases
3.4. Storage Admin
3.4.1. Use Cases
4. Management domains
4.1. Management Domain Overview
4.2. Application storage management domain
4.2.1. Use cases
4.3. Block storage management domain
4.3.1. Use Cases
4.4. Service catalog management domain
4.4.1. Data protection
4.4.2. Data security
4.4.3. Data storage
4.4.4. IO connectivity
4.4.5. IO performance
4.4.6. Use cases
4.5. File system storage management domain
4.5.1. Use cases
5. User Guidance { .page_break_before }
6. Features
6.1. Overview
6.2. Block provisioning feature { .page_break_before }
6.2.1. Overview
6.2.2. Feature-specific Guidance
6.2.3. Block provisioning use cases
6.3. Capacity management feature
6.3.1. Overview
6.3.2. Feature-specific Guidance
6.3.3. Capacity management use cases
6.4. Class of Service Features
6.4.1. Overview
6.4.2. Feature-specific Guidance
6.4.2.1. Default Class of Service
6.4.3. Class of service use cases
6.5. Event notification feature
6.5.1. Overview
6.5.2. Feature-specific Guidance
6.5.3. Event notification use cases
6.6. File provisioning feature { .page_break_before }
6.6.1. Overview
6.6.2. Feature-specific Guidance
6.6.3. File provisioing use cases
6.7. Block IO performance feature
6.7.1. Overview
6.7.2. Feature-specific Guidance
6.7.3. IO performance use cases
6.8. Block mapping and masking feature
6.8.1. Overview
6.8.2. Feature-specific Guidance
6.8.3. Mapping and masking use cases
6.9. NVMe Support feature
6.9.1. Overview
6.9.2. Feature-specific Guidance
6.9.3. NVMe use cases
6.10. Replication Feature
6.10.1. Overview
6.10.2. Feature-specific Guidance
6.10.3. Replication use cases
7. Use cases { .page_break_before }
7.1. Use cases by feature
7.1.1. Uncategorized Use Cases
7.1.2. Block provisioning use cases
7.1.3. Capacity management use cases
7.1.4. Class of service use cases
7.1.5. Event notification use cases
7.1.6. File provisioing use cases
7.1.7. IO performance use cases
7.1.8. Mapping and masking use cases
7.1.9. NVMe use cases
7.1.10. Replication use cases
7.2. Alphabetic list of use cases
7.2.1. Create a New Replication Relationship by Assigning a Target Volume
7.2.2. Attach a Namespace
7.2.3. Create an on-demand snapshot of a Volume { .page_break_before }
7.2.4. Change only the RAID Type of an Existing Volume
7.2.5. Change only the span count of an existing volume
7.2.6. Create class of service { .page_break_before }
7.2.7. Create file share { .page_break_before }
7.2.8. Create file system { .page_break_before }
7.2.9. Create file system { .page_break_before }
7.2.10. Create line of service { .page_break_before }
7.2.11. Create storage pool using Specified Set of Drives and RAIDTypes { .page_break_before }
7.2.12. Create storage pool using Specified Set of Drives { .page_break_before }
7.2.13. Create storage pool { .page_break_before }
7.2.14. Create StorageGroup { .page_break_before }
7.2.15. Create Volume from an Existing Storage Pool { .page_break_before }
7.2.16. Create Volume using the Volume Collection { .page_break_before }
7.2.17. Make a New Replication Relationship by Creating a Target Volume { .page_break_before }
7.2.18. Provision a Namespace { .page_break_before }
7.2.19. Remove Replication Relationship for a Consistency Group { .page_break_before }
7.2.20. Remove Replication Relationship { .page_break_before }
7.2.21. Report Namespace Capacity { .page_break_before }
7.2.22. Report Remaining Life for a Namespace { .page_break_before }
7.2.23. Resume the Replication Synchronization Activity for a Consistency Group { .page_break_before }
7.2.24. Resume the Replication Synchronization Activity { .page_break_before }
7.2.25. Reverse a Replication Relationship for Consistency Groups { .page_break_before }
7.2.26. Reverse a Replication Relationship { .page_break_before }
7.2.27. Split a Replica { .page_break_before }
7.2.28. Split a set of Replicas in Consistency Groups { .page_break_before }
7.2.29. Subscribe to Threshold Events { .page_break_before }
This guide is intended to provide a common repository of best practices, common tasks and education for the users of the Swordfish API. Each use case includes an indication of the classes of API users who are most likely to find the case useful.
This document begins with a set of information intended to provide a solid foundation for readers new to restful APIs in general and Swordfish in particular. While this material is no replacement for a thorough understanding of the Swordfish specification and the material that it references, it is intended as a stand alone document that can provide a solid introduction to Swordfish.
Based on that foundational material, this document then presents a set of Use Cases intended to capture common tasks and best practices that can be used to exercise the breadth and strength of the Swordfish API. In general, the guide is structured to provide more basic use cases first, and examine common refinements and options at the same time. More advanced tasks are handled later in the guide, and assume the prior skills and assumptions have been mastered.
For each use case, this guide will use a common template. Table lists each field of the template and its description.
Name | Description |
---|---|
Title | A description of the high-level scope of the Use Case |
Summary | A high-level summary of the use case |
Purpose | The intended goals or motivations for the use case |
Who | The Actor(s) who are likely to use this use case. The actor description also includes a list of other use cases of interest for a named actor |
Management Domain | The Management Domain(s) applicable to this use case. The domain description also includes a list of other use cases of interest for the named management domains |
Triggers | A description of likely business conditions or goals that would make this use case useful |
Detailed Context | A detailed description of the operations environment and configuration assumptions for this use case |
Preconditions | Pre-existing knowledge, configurations or capabilities |
Inputs | A set of parameters and values that are used to adapt a generic use case to a specific business needs. Where appropriate, the parameter description will include a data type (e.g., {CAPACITY}: desired storage capacity (int64)) |
Basic Course of Events | A sequence of API requests, including required headers, the body of the request, and the expected reply |
Configuration Impacts | Changes to the storage configurations caused by the use case |
Failure Scenario | Common failure conditions encountered in this use case |
See Also | Other Use Cases that may be of interest |
The precise scope of a given Swordfish implementation can vary widely. Some installations will opt to deploy a basic level of the API that only extends the Redfish standard slightly. Others will decide to implement a number of features, providing a broader range of functionality. While this guide cannot provide examples of all possible configurations and situations, it does attempt to cover a range of possible functionality options. Use cases that assume functionality that correspond to specific features are clearly identified.
This document assumes that some fundamental configuration issues have been properly implemented, and will not need to be addressed in any detail. In particular, this document assumes:
The Swordfish API conforms to the standards defined in the Redfish API. More generally, it is provides a RESTful interface. The reader is assumed to be familiar with common conventions for RESTful APIs. Those readers who are interested in additional background information are encouraged to refer to the following sources:
This User’s Guide is part of the documentation suite for the Swordfish API. Readers are encouraged to refer to the following for additional information: - Swordfish API Specification - Swordfish Tutorials - Swordfish NMVe Mapping Guide - Swordfish Profile Bundle
Swordfish queries support four query methods. Each query URL must include exactly one of of the query methods listed in Table .
Method | Action |
---|---|
GET | Retrieve the current state or settings of the named Resource Path as seen through the Service Root |
POST | Create a new object under the named Resource Path |
PUT | Replace the object referenced by the named Resource Path |
DELETE | Delete the object referenced by the named Resource Path |
PATCH | Update the object referenced by the named Resource Path |
HEAD | Validates a GET request against the named Resource Path without returning the HTML headers for the response without the result of the query |
All HTTP requests and responses in a compliant Swordfish implementation support the HTTP headers required by the Redfish Protocol Specification. The supported headers are reproduced here for convenience.
HTTP request headers that are commonly used in Swordfish queries are summarized in Table .
Header | Supported Values | Notes |
---|---|---|
Accept | RFC 7231 | Indicates to the server what media type(s) this client is prepared to accept. Services shall support requests for resources with an Accept header including application/json or application/json;charset=utf-8. Services shall support requests for metadata with an Accept header including application/xml or application/xml;charset=utf-8. |
Content-Type | RFC 7231 | Describes the type of representation used in the message body. Content-Type shall be required in requests that include a request body. Services shall accept Content-Type values of application/json or application/json;charset=utf-8. |
OData-Version | 4.0 | Services shall reject requests which specify an unsupported OData version. If a service encounters a version that it does not support, the service should reject the request with status code 412. If client does not specify an Odata-Version header, the client is outside the boundaries of this specification. |
Authorization | RFC 7235, Section 4.2 | Required for Basic Authentication |
User-Agent | RFC 7231 | Required for tracing product tokens and their version. Multiple product tokens may be listed. |
Host | RFC 7230 | Required to allow support of multiple origin hosts at a single IP address. |
Origin | W3C CORS, Section 5.7 | Used to allow web applications to consume Redfish Service while preventing CSRF attacks. |
If-Match | RFC 7232 | If-Match shall be supported on PUT and PATCH requests for resources for which the service returns ETags, to ensure clients are updating the resource from a known state. |
X-Auth-Token | Opaque encoded octet strings | Used for authentication of user sessions. The token value shall be indistinguishable from random. |
HTTP response headers that are commonly used in Swordfish queries are summarized in Table .
Header | Supported Values | Notes |
---|---|---|
OData-Version | 4.0 | Describes the OData version of the payload that the response conforms to. |
Content-Type | RFC 7231 | Describes the type of representation used in the message body. Services shall specify a Content-Type of application/json when returning resources as JSON, and application/xml when returning metadata as XML. ;charset=utf-8 shall be appended to the Content-Type if specified in the chosen media-type in the Accept header for the request. |
ETag | RFC 7232 | An identifier for a specific version of a resource, often a message digest. Etags shall be included on responses to GETs of ManagerAccount objects. |
Server | RFC 7231 | Required to describe a product token and its version. Multiple product tokens may be listed. |
Link | Link headers shall be returned as described in the clause on Link Headers | |
Location | RFC 7231 | Indicates a URI that can be used to request a representation of the resource. Shall be returned if a new resource was created. Location and X-Auth-Token shall be included on responses which create user sessions. |
Cache-Control | RFC 7234 | This header shall be supported and is meant to indicate whether a response can be cached or not. |
Access-Control-Allow-Origin | W3C CORS, Section 5.7 | Prevents or allows requests based on originating domain. Used to prevent CSRF attacks. |
Allow | POST, PUT, PATCH, DELETE, GET, HEAD | Shall be returned with a 405 (Method Not Allowed) response to indicate the valid methods for the specified Request URI. Should be returned with any GET or HEAD operation to indicate the other allowable operations for this resource. |
WWW-Authenticate | RFC 7234, Section 4.1 | Required for Basic and other optional authentication mechanisms. See the Security clause for details. |
X-Auth-Token | Opaque encoded octet strings | Used for authentication of user sessions. The token value shall be indistinguishable from random. |
This is the base of all Swordfish URL’s. A GET request to the Service Root will return an overview of the services provided by a given Swordfish service. In addition, the Service Root will include versioning information.
All Service Root URLs that are compliant with the Swordfish specification will be of the form https://
hostName/redfish/v1
, where hostName specifies the system (and optionally port number), of the Swordfish service provider.
The Resource Path identifies the specific object (or collection of objects) that is the target of the Swordfish query. Swordfish Resource Paths can identify:
At the highest level, Swordfish systems are discoverable in the Storage Systems collection in the ServiceRoot.
Swordfish queries can include arbitrary sets of query options to further refine the target of given query or the actions being requested of that target. These general query options are summarized in Table .
Note: Additional query options may be supported (or constrained) for a specific query target or resource path. These target-specific query options will be addressed in specific use case descriptions, as required.
Parameter Name | Arguments | Notes |
---|---|---|
$skip=n | Integer | Omit the first n entries in the collection from the returned set of objects (required by redfish) |
$top=n | Integer | Return, at most, the first n entries in the returned set of objects (required by redfish) |
$filter=condition | Filter Expression | Returns only the members of the named collection that match the provided logical expression (required by swordfish) |
$expand=target | Expand Expression | Expand additional detail on the target property(s) in the returned result set (required by swordfish) |
$select=property list | Comma-separated list of object properties | Return the named properties for each object in the result set, rather than the entire object (required by swordfish) |
$orderby=filter condition | Filter Expression | sort the result set by the output values from the filter expression (required by swordfish) |
$filter=(age gt 30)
A group of people never to trust.For more information see Filter Expression in the OData specification.
Swordfish clients may receive any of the standard HTTP status codes. Both the Redfish specification and the Swordfish specification define a detailed mapping from the generic HTTP codes to domain-specific situations, and probable causes. In addition, the server can return extended status information as a simple JSON object to further clarify the handling and outcome of a particular API request. For more information, see the Swordfish Specification and the Redfish Specification.
This document covers a broad range of common use cases and storage management operations.
In an attempt to serve as both a introductory text and as a reference tool, the use cases have been grouped in a number of different ways:
A Cloud Administrator (CloudAdmin) is a converged infrastructure administrator, working with systems that are:
The CloudAdmin role in an enterprise or service provider is the individual or group primarily responsible for managing the operational lifecycle of a cloud, virtualization, converged environment that consists of the workloads, resource abstractions, storage, networking, and compute.
Also referred to as a “cloud architect”, this role:
A member of the DevOps group:
This role is typically aligned with the business unit. Their focus is the delivery, deployment, and maintenance of apps on IaaS and PaaS resources. This role is not typically a deep subject matter expert in compute, storage, or networking. From a development perspective, their desire is to treat the infrastructure as a programmable subsystem that presents resources on-demand.
This role:
A storage administrator designs storage solutions for modern environments, including:
The storage admin role in an enterprise or service provider can have responsibility for managing the operational lifcycle of storage in the datacenter. In particular:
This document covers a broad range of common use cases and storage management operations.
In an attempt to serve as both a introductory text and as a reference tool, the use cases have been grouped in a number of different ways:
Alphabetically. Each use case is ordered according to a self-expanatory title, to make it easier for an experienced user to find a specifc piece of guidance.
By actor. While the precise titles and responsibilities within storage management organizations will differ from one organization to the next, this guide has identified three broad functional roles, known as actorsand identfied the use cases that are most applicable to those roles;
By management domain. Similarly, while each organization will allocate responsibilities differently, there are general broad classes of storage management that share tasks. This guide has identified four management domains:
This domain manages the interface between applications and the storage that they rely upon.
StorageGroups provide a means to collectively manage the Volumes and FileShares utilized by an Application. The StorageGroup specifies whether the collected resources are managed so that storage is updated or replicated consistently across all members. Additionally, the StorageGroup provides the means to atomically expose (or hide) the collected resources to (or from) host endpoints.
Many devices and services provide their storage capacity to external devices and applications through block-based protocols to storage devices. This domain includes the management of resources that provide block-based access to storage.
Block-based storage is represented by a Volume. This domain provides for the discovery and provisioning of Volumes and for maintaining relationships to Device, Endpoint, StorageService, StorageGroup, StoragePool, and ComputerSystem resources.
Swordfish supports access to, and management of, a catalog of service options, (see ITIL glossary and abbreviations), supported by storage services.
When the Swordfish Class of Service Feature is implemented, the ClassOfService resource represents a service option that may be used to specify requirements for utility or warranty when provisioning a resource. Currently ClassOfService is defined for use in the Block Storage, File System, and ApplicationStorage domains.
The service catalog for each StorageService is represented by a collection of references to supported ClassOfService resources. Each ClassOfService is known minimally by a Name and a unique Identifier. When a ClassOfService is specified for a resource, the StorageService shall attempt to maintain that resource in compliance to the requirements of that ClassOfService. The requirements may be specified informally by text in the Description property or may be specified formally by the property values of embedded options related to specific lines of service.
The embedded service options are described by values of complex types representing lines of service.
Over time, as the service catalog is continually updated to match evolving user needs and service provider offerings, it is expected that the catalog will contain entries (one or more ClassOfSerice or LineOfService instances) that are not currently active.
The primary storage is described by a ClassOfService resource. That ClassOfService may aggregate any number of data protection service options. Each instance of a data protection service option describes the characteristics a replication session that shall be maintained for the containing primary storage resource.
For additional information, see the definitions for DataProtectionLineOfService and DataProtectionLoSCapabilities.
An instance of a data security service option describes an optional set of data security requirements. A data security Service option is typically aggregated into a ClassOfService resource that is associated with storage. At most one data security service option may be aggregated into a ClassOfService resource. When storage is provisioned with that ClassOfService, it will provide the currently specified data security characteristics.
A data security service option may specify data security characteristics that enable the storage system to be used in an environment where compliance with an externally-specified security standard or standards is required. Examples of such standards include FIPS-140, HIPAA and PCI. In this case, the names of the standard or standards can usefully be included in the user/admin-visible name of the instance. With the notable exception of FIPS-140, compliance requires measures well beyond the means of a storage system to provide (e.g., both HIPAA and PCI impose significant requirements on administration and operation of the data center), so this approach promises that the storage system will do its part in supporting compliance, but does not (and cannot) promise that the storage system will deliver full compliance by itself.
The description attribute value may include human readable information including:
Whether encryption keys are drive or array resident or externally managed (e.g., via KMIP).
Information on how the array supports compliance to a standard identified in the name of the Service option. (e.g., specific algorithms employed that are FIPS-140 compliant, information about the validated cryptographic module and its validation certificate, relationship of the security functionality to specific PCI or HIPAA requirements).
NOTE For comparable cryptographic strengths, (see NIST SP 800-57 part 1)
NOTE For symmetric encryption algorithm key sizes, 112 bits is the 3DES key size and 128, 192, and 256 bits are options for AES key sizes.`
NOTE MediaEncryptionStrength includes the case where metadata about the data must be encrypted. (e.g. data presence vs. absence in a thin volume, array filesystem metadata) The implementation may be self-encrypting drives or encryption in the storage system’s drive controller. Keys may be drive or array resident or externally managed (e.g., via KMIP).
For additional information, see the definitions for DataSecurityLineOfService and DataSecurityLoSCapabilities.
Each data storage service option describes characteristics of the storage at a particular location. A class of service will have at most one data storage service option, which describes the storage specified by that class of Service.
For additional information, see the DataStorageLineOfService and DataProtectionLoSCapabilities.
An IO connectivity service option specifies the characteristics of storage connectivity. For each value of AccessProtocol, at most one IO connectivity service option may be aggregated into a class of service.
NOTE: If used within a ClassOfService for Storage Provisioning, this value constrains the set of connections used to expose that storage.
For additional information, see the IOConnectivityLineOfService and IOConnectivityLoSCapabilities.
An IO performance service option specifies a choice of performance characteristics as viewed through the data path to the storage. This is affected by choices of storage and connection technologies.
At most one IO performance service option may be aggregated into a ClassOfService for a storage resource. When storage is provisioned with that ClassOfService, it should provide at least the specified performance.
For additional information, see the IOConnectivityLineOfService and IOConnectivityLoSCapabilities.
FileSystems provide access to byte-accessible storage through file-based protocols. This domain includes the management of resources that provide file-based access to storage.
File-based storage is represented by a FileSystem resources. Remote access to portions of a FileSystem is provided by FileShare resources.
Swordfish supports a range of possible features. Clients use the Features registry to determine what SupportedFeatures a specific instance of an implementation is capable of. These range from discovery (read-only functionality), to event notification, to performance instrumentation, to multiple levels of block and file provisioning capabilities.
Supporting the granular feature definition is a detailed profile description that includes precise definitions of what functionality must be implemented in order to advertise support for each feature.
For use cases specified in this document, there is an expectation that specific features have been implemented to support the corresponding use case. For example, the “AssignReplicaTarget” use case highlights functionality for either local or remote replication, depending on the selected target volume’s system (either the same or different than the source volume). In either case, the client is working with the presumption that the feature has been advertised.
This guide covers use cases for both installations that have opted to deploy a basic level of the API, and only extends the Redfish standard slightly, and those that implement a number of advanced features, providing a broader range of functionality. Use cases that assume functionality or features beyond a basic Swordfish implementation are clearly identified below, and are group with one another.
This version of the Users’ Guide incorporates the functionality defined in v1.1.0 of the Swordfish specification, which defines a number of features. In addition to basic use cases, this document includes cases that rely on the implementation of each of those features:
This feature provides basic, block-based storage provisioning.
None defined.
The use cases defined for block provisioning are summarized in Table .
Title | Description |
---|---|
Add Drives to a StoragePool | Add multiple drives to an existing StoragePool |
Change the only the RAID Type of an Existing Volume | Change the RAIDType of an existing Volume without a change to the underlying Drives collection |
Change the only the span count of an Existing Volume | Change the span count of an existing Volume without a change to the underlying Drives collection |
Create Volume from a StoragePool | Create Volume from an Existing Storage Pool |
Create Volume using the Volume Collection | Create Volume using the Volume Collection |
Delete Drives from a StoragePool | Delete multiple drives from an existing StoragePool |
This feature provide the management and alteration of storage once it has been allocated.
None defined.
The use cases defined for capacity management are summarized in Table .
Title | Description |
---|---|
Expand Volume | Expand capacity of a Volume |
This feature provides support for automated storage management based on ClassOfService and LineOfService modeling.
If a pool, storage volume or other construct is created with no specified class of service when a class of service exists, the implementation will attempt to apply the DefaultClassOfService.
The use cases defined for class of service are summarized in Table .
Title | Description |
---|---|
Create class of service | Create a class of service |
Create file system | Create a files system |
Create line of service | Create a line of service |
Create Volume specifying Class of Service | Create Volume specifying Class of Service |
Create Volume using Default Class of Service | Create Volume using Default Class of Service |
Create an on-demand snapshot of a Volume | Create an on-demand snapshot of a Volume |
This feature provides basic eventing.
None defined.
The use cases defined for event notification are summarized in Table .
Title | Description |
---|---|
Subscribe to thresholds events | Subscribe to Threshold Events |
This feature provides file-based storage provisioning.
None defined.
The use cases defined for file provisioning are summarized in Table .
Title | Description |
---|---|
Create file share | Create a file share |
Create file system | Create a file system |
This feature provides basic performance metrics.
None defined.
The use cases defined for IO performance are summarized in Table .
Title | Description |
---|---|
Subscribe to thresholds events | Subscribe to Threshold Events |
This feature provides block-based mapping and assignment of storage volumes.
None defined.
The use cases defined for mapping and masking are summarized in Table .
Title | Description |
---|---|
Create StorageGroup | Create a StorageGroup |
This feature provides NVMe-specific use cases.
The detailed mapping between Swordfish objects and the NVMe object model can be found in Swordfish NVMe Model Overview and Mapping Guide.
Title | Description |
---|---|
Attach a Namespace | Attach a Namespace |
Deprovision a Namespace | Deprovision a Namespace |
Detach a Namespace | Detach a Namespace |
Provision a Namespace | Provision a Namespace |
Provision a Namespace with NVMSet | Provision a Namespace associated with an NVMSet |
Report capacity for a Namespace | Report capacity for a Namespace |
Report remaining life for a Namespace | Report remaining life for a Namespace |
This set of features (local replication and remote replication) provides support for a broad range of storage redundancy protections.
Replication can be implemented many ways. The use cases defined for this feature illustrate two possible approaches, one using volumes and the other using consistency groups. Those use cases employing consistency groups will include “CG” in their titles, to avoid confusion.
The use cases defined for replication are summarized in Table .
Title | Description |
---|---|
Assign Replica Target | Create a New Replication Relationship by Assigning a Target Volume |
Assign Replica Target (CG) | Create a New Replication Relationship by Assigning an existing Target Consistency Group |
Create Replica Target | Make a New Replication Relationship by Creating a Target Volume |
Create Replica Target (CG) | Make a New Replication Relationship by Creating a Target Consistency Group |
Remove Replication Relationship | Remove Replication Relationship |
Remove Replication Relationship (CG) | Remove Replication Relationship for a Consistency Group |
Resume the Replication Synchronization Activity | Resume the Replication Synchronization Activity |
Resume the Replication Synchronization Activity (CG) | Resume the Replication Synchronization Activity for a Consistency Group |
Reverse a Replication Relationship | Reverse a Replication Relationship |
Reverse a Replication Relationship (CG) | Reverse a Replication Relationship for Consistency Groups |
Split a Replica | Split a Replica |
Split a Replica (CG) | Split a set of Replicas in Consistency Groups |
Suspend Replication Synchronization Activity | Suspend Replication Synchronization Activity |
Suspend Replication Synchronization Activity (CG) | Suspend Replication Synchronization Activity between Consistency Groups |
The use cases that don’t align with a particular feature are summarized in Table .
Title | Description |
---|---|
Create Storage Pool | Create a StoragePool |
Create Storage Pool by drives | Create a StoragePool using a specific set of drives |
Create Storage Pool with drives and RAIDType | Create storage pool using Specified Set of Drives and RAIDTypes |
Subscribe to thresholds events | Subscribe to Threshold Events |
The use cases defined for block provisioning are summarized in Table .
Title | Description |
---|---|
Add Drives to a StoragePool | Add multiple drives to an existing StoragePool |
Change the only the RAID Type of an Existing Volume | Change the RAIDType of an existing Volume without a change to the underlying Drives collection |
Change the only the span count of an Existing Volume | Change the span count of an existing Volume without a change to the underlying Drives collection |
Create Volume from a StoragePool | Create Volume from an Existing Storage Pool |
Create Volume using the Volume Collection | Create Volume using the Volume Collection |
Delete Drives from a StoragePool | Delete multiple drives from an existing StoragePool |
The use cases defined for capacity management are summarized in Table .
Title | Description |
---|---|
Expand Volume | Expand capacity of a Volume |
The use cases defined for class of service are summarized in Table .
Title | Description |
---|---|
Create class of service | Create a class of service |
Create file system | Create a files system |
Create line of service | Create a line of service |
Create Volume specifying Class of Service | Create Volume specifying Class of Service |
Create Volume using Default Class of Service | Create Volume using Default Class of Service |
Create an on-demand snapshot of a Volume | Create an on-demand snapshot of a Volume |
The use cases defined for event notification are summarized in Table .
Title | Description |
---|---|
Subscribe to thresholds events | Subscribe to Threshold Events |
The use cases defined for file provisioning are summarized in Table .
Title | Description |
---|---|
Create file share | Create a file share |
Create file system | Create a file system |
The use cases defined for IO performance are summarized in Table .
Title | Description |
---|---|
Subscribe to thresholds events | Subscribe to Threshold Events |
The use cases defined for mapping and masking are summarized in Table .
Title | Description |
---|---|
Create StorageGroup | Create a StorageGroup |
Title | Description |
---|---|
Attach a Namespace | Attach a Namespace |
Deprovision a Namespace | Deprovision a Namespace |
Detach a Namespace | Detach a Namespace |
Provision a Namespace | Provision a Namespace |
Provision a Namespace with NVMSet | Provision a Namespace associated with an NVMSet |
Report capacity for a Namespace | Report capacity for a Namespace |
Report remaining life for a Namespace | Report remaining life for a Namespace |
The use cases defined for replication are summarized in Table .
Title | Description |
---|---|
Assign Replica Target | Create a New Replication Relationship by Assigning a Target Volume |
Assign Replica Target (CG) | Create a New Replication Relationship by Assigning an existing Target Consistency Group |
Create Replica Target | Make a New Replication Relationship by Creating a Target Volume |
Create Replica Target (CG) | Make a New Replication Relationship by Creating a Target Consistency Group |
Remove Replication Relationship | Remove Replication Relationship |
Remove Replication Relationship (CG) | Remove Replication Relationship for a Consistency Group |
Resume the Replication Synchronization Activity | Resume the Replication Synchronization Activity |
Resume the Replication Synchronization Activity (CG) | Resume the Replication Synchronization Activity for a Consistency Group |
Reverse a Replication Relationship | Reverse a Replication Relationship |
Reverse a Replication Relationship (CG) | Reverse a Replication Relationship for Consistency Groups |
Split a Replica | Split a Replica |
Split a Replica (CG) | Split a set of Replicas in Consistency Groups |
Suspend Replication Synchronization Activity | Suspend Replication Synchronization Activity |
Suspend Replication Synchronization Activity (CG) | Suspend Replication Synchronization Activity between Consistency Groups |
Summary: Establish a replication relationship by assigning an existing volume to serve as a target replica for an existing source volume.
Purpose: Leverage an existing volume resource to provide expanded data protection through a replica relationship with the specified source volume.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to provide expanded data protection through a replica relationship with the specified source volume.
Detailed Context: The admin needs to provide expanded data protection for the specified source volume, and the configuration includes pre-existing volume that can be repurposed as a replication target.
Preconditions: User has already identified an existing volume to use for the target replica (including the target system and storage pool properties), the type of replica, and the replica update mode (sync vs async).
Feature(s): Replication (both local and remote)
Inputs:
URL for target volume: /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245
Requested replica type: Mirror
ReplicaUpdateMode: Synchronous
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.AssignReplicaTarget
Headers: No additional headers required.
Body:
{
"ReplicaUpdateMode": "Synchronous",
"TargetVolume": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245",
"ReplicaType": "Mirror"
}
Response contains the details of the created volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaTargets": [
{
"@odata.id" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"
}
]
}
Postconditions: The selected volume has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a volume “650973452245” in the system that has a ReplicaInfo which points back to this volume and which contains all of the Replica configuration information.
Failure Scenario: None defined
See also: Assign Replica Target (CG).
Summary: Establish a replication relationship by assigning an existing consistency group to serve as the target in the replication relationship for an existing consistency group.
Purpose: Leverage an existing consistency group resource to provide expanded data protection by creating a replication relationship with the specified source consistency group.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to provide expanded data protection through a replica relationship with the specified source consistency group.
Detailed Context: The admin needs to provide expanded data protection for the specified source consistency group, and the configuration includes a pre-existing consistency group that can be repurposed as the replication target.
Preconditions: User has already identified an existing consistency group to use for the target replicas (including the target system and storage pool properties), the type of replica(s), and the replica update mode (sync vs async).
Feature(s): Replication (both local and remote)
Inputs:
URL for target volume: /redfish/v1/Storage/1/ConsistencyGroup/CG_DB2
Requested replica type: Mirror
ReplicaUpdateMode: Synchronous
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroup/CG_DB1/ConsistencyGroup.AssignReplicaTarget
Headers: No additional headers required.
Body:
{
"ReplicaUpdateMode": "Synchronous",
"TargetConsistencyGroup": "/redfish/v1/Storage/1/ConsistencyGroup/CG_DB2",
"ReplicaType": "Mirror"
}
Response contains the details of the created volume.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroup/CG_DB1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaTargets": [
{
"@odata.id" : "/redfish/v1/Storage/1/ConsistencyGroup/CG_DB2"
}
]
}
Postconditions: The selected ConsistencyGroup has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a ConsistencyGroup “CG_DB2” in the system that has a ReplicaInfo which points back to this ConsistencyGroup and which contains all of the Replica configuration information.
Failure Scenario: None defined
See also: Assign Replica Target.
Summary: Attach a Namespace
Purpose: Provide visibility to a namespace by attaching it to an IO Controller.
Who: StorageAdmin; CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: Attach a Namespace to an IO Controller to make it visible to the hosts that connect to that IO Conttoller, and accessible for block storage operations.
Preconditions: The IO Controller and Namespaces need to exist, and be fully defined.
Feature(s): NMVe
Inputs:
Basic Course of Events:
Request: PATCH /redfish/v1/redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Controllers/NVMeIOController/
Headers: No additional headers required.
Body:
{
"Links": {
"AttachedVolumes": [
{
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Volumes/SimpleNamespace"
}
]
}
}
Response: None defined.
Postconditions: The Namespace has been configured as an AttachedVolume to the IO Controller. This means that the Namespace is visible to hosts connected to the IO Controller.
Failure Scenario: None defined.
See also: None defined.
Summary: Create an on-demand snapshot of a volume
Purpose: Create a snapshot of an existing volume. The resulting snapshot can then be used either as a backup or as a separate copy to test against.
Who: CloudAdmin, StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need an on-demand snapshot of a Volume
Detailed Context: To take a snapshot of a volume, we need to find a DataProtectionLineOfService that can describe the new Snapshot.
The DataProtectionLineOfService must have no schedule set to be able to provide on-demand behavior.
Preconditions: None.
Feature(s): Class of Service
Inputs:
/redfish/v1/StorageServices/1
/redfish/v1/StorageServices/1/StoragePools/BasePool/AllocatedVolumes/1
Basic Course of Events:
The first step is to get the current supported DataProtectionLineOfService entries, and find one that provides appropriate snapshot support (i.e., has no schedule set, and meets any other criteria the client may have).
Request:
GET /redfish/v1/StorageServices/1/Links/DataProtectionLoSCapabilities/SupportedLinesOfService
json { "SupportedLinesOfService": [ { "@odata.id": "/redfish/v1/StorageServices/1/Links/DataProtectionLoSCapabilities/SupportedLinesOfService/OnDemandSnapshot", "Name": "OnDemandSnapshot", "RecoveryGeographicObjective": "Server", "ReplicaType": "Snapshot", } ] }
Request:
POST /redfish/v1/StorageServices/1/Links/DataProtectionLoSCapabilities/SupportedLinesOfService/OnDemandSnapshot.CreateReplicas
Headers:
No additional headers required.
Body:
json { "ReplicaRequests": [{ "ReplicaSource": {"@odata.id": "/redfish/v1/StorageServices/1/StoragePools/BasePool/AllocatedVolumes/1"}, "ReplicaName": "MySnapshot" }] }
Response:
200 Success
Headers:
No additional headers required.
Body:
[ {
"ReplicaPriority": "Same",
"ReplicaReadOnlyAccess": "ReplicaElement",
"UndiscoveredElement": null,
"WhenSynced": "20171024T142000-00500",
"SyncMaintained": null,
"ReplicaRecoveryMode": null,
"ReplicaUpdateMode": "Synchronous",
"PercentSynced": 100,
"FailedCopyStopsHostIO": null,
"WhenActivated": "20171024T142000-00500",
"WhenDeactivated": null,
"WhenEstablished": "20171024T142000-00500",
"WhenSuspended": null,
"WhenSynchronized": null,
"ReplicaSkewBytes": null,
"ReplicaType": "Snapshot",
"ReplicaProgressStatus": "Completed",
"ReplicaState": "Synchronized",
"ConsistencyEnabled": false,
"ConsistencyType": null,
"ConsistencyState": null,
"ConsistencyStatus": null,
"ReplicaRole": "Target",
"Replica": {"odata.id": "/redfish/v1/StorageServices/1/StoragePools/BasePool/AllocatedVolumes/MySnapshot"},
"DataProtectionLineOfService": "/redfish/v1/StorageServices/1/Links/DataProtectionLoSCapabilities/SupportedLinesOfService/OnDemandSnapshot"}
]
Postconditions:
The original Volume (/redfish/v1/StorageServices/1/StoragePools/BasePool/AllocatedVolumes/1) now has a snapshot volume (/redfish/v1/StorageServices/1/StoragePools/BasePool/AllocatedVolumes/MySnapshot) that is available through its ReplicaTargets collection. All replication information (ReplicaInfo) is available on the snapshot (/redfish/v1/StorageServices/1/Volumes/MySnapshot) volume to describe the relationship.
Failure Scenario:
None defined.
See also:
None defined.
Summary: Change only the RAID type of an existing Volume
Purpose: Change the RAID type of an existing Volume to meet new protection requirements, without a change to the underlying Drives collection.
Who: StorageAdmin
Management Domain: Block storage management
Triggers: Change the RAID protection level of a Volume; this could be performance, capacity or application triggered.
Detailed Context: The storage admin needs to alter the underlying RAID layout for an existing Volume.
Preconditions: Volume already exists, and employs drives sufficient to satisfy the requested RAID geometry.
Feature(s): Block provisioning
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Basic Course of Events:
ChangeRAIDLayout
Action on the Volume, passing the requested RAIDType as input.Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Actions/ChangeRAIDLayout
Headers: No additional headers required.
Body:
{
"RAIDType" : "RAID5"
}
2a. If the implementation is able to return immediately:
Response returns success.
Response: 200 OK.
Headers: None.
Body: None.
A GET on volume will show the updated RAIDType.
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
```json
{ “@SSM.Copyright”: “Copyright (c) 2014-2021 SNIA. All rights reserved.”, “@odata.context”: “/redfish/v1/$metadata#Volume.Volume”, “@odata.id”: “/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1”, “@odata.type”: “#Volume_1_6_0.Volume”, “Name”: “MyVolume”, “Id”: “1”, “Description”: “Default Volume Description”, “RAIDType”: “RAID5”, “Identifiers”: [ { “DurableNameFormat”: “NAA”, “DurableName”: “65456765456761001234076100123487” } ], “Status”: { “State”: “Enabled”, “Health”: “OK” }, “CapacityBytes”: 1099511627776, “Links”: { “StoragePool”: “/redfish/v1/Storage/1/StoragePools/1” } }
```
2b. If the implementation requires a background task (using the Redfish task service) to return status:
Response returns success.
Response: 202 Accepted.
Headers: Location = /redfish/v1/TaskService/Tasks/TaskID2
Body: None.
A GET on volume while task is pending will indicate the in-process change to RAIDType, and that the transition to the new RAID layout is not complete, using Status.State
and Status.Health
:
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "Default Volume Description",
"RAIDType": "RAID5",
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Updating",
"Health": "Warning"
},
"CapacityBytes": 1099511627776,
"Links": {
"StoragePool": "/redfish/v1/Storage/1/StoragePools/PrimaryPool"
}
}
A subsequent GET on the Volume, once the task has completed, will reflect the new values:
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body: ```json
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "Default Volume Description",
"RAIDType": "RAID5",
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Enabled",
"Health": "OK"
},
"CapacityBytes": 1099511627776,
"Links": {
"StoragePool": "/redfish/v1/Storage/1/StoragePools/PrimaryPool"
}
} ```
Postconditions: None defined.
Failure Scenario: If the system is unable to complete the requrested change to the RAID layout for some reason (e.g., insufficient Drives in the underlying StoragePool to support the requested RAID type), the initial POST
will result in an error. For example:
Use the ChangeRAIDLayout
Action on the Volume, passing the requested RAIDType as input, as in the initial scenario.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Actions/ChangeRAIDLayout
Headers: No additional headers required.
Body:
{
"RAIDType" : "RAID5"
}
Response: 400
Headers: None.
Body:
{
"error": {
"code": "Base.1.6.ActionParameterMissing",
"message": "The action ChangeRAIDLayout requires the parameter Drives to be present in the request body.",
"@Message.ExtendedInfo" : [
"MessageId": "Base.1.6.ActionParameterMissing",
"Message" : "The Drives paramter must be included in this request",
"RelatedProperties" : "Drives"
]
}
}
See also: None defined.
Summary: Change only the span count of an existing Volume
Purpose: Change the span count RAID type of an existing Volume, without a change to the underlying Drives collection.
Who: StorageAdmin
Management Domain: Block storage management
Triggers: Change the span count of a Volume; this could be performance, capacity or application triggered.
Detailed Context: The storage admin needs to alter the underlying RAID layout for an existing Volume.
Preconditions: Volume already exists, and employs drives sufficient to satisfy the requested RAID geometry.
Feature(s): Block provisioning
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Basic Course of Events:
ChangeRAIDLayout
Action on the Volume, passing the requested MediaSpanCount as input.Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Actions/ChangeRAIDLayout
Headers: No additional headers required.
Body:
{
"MediaSpanCount" : 10
}
2a. If the implementation is able to return immediately:
Response returns success.
Response: 200 OK.
Headers: None.
Body: None.
A GET on volume will show the updated RAIDType.
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
Not clear what properties should be returned here. Is this up the implementation? Not clear what value changes with a change to MediaSpanCount
```json
{ “@SSM.Copyright”: “Copyright (c) 2014-2021 SNIA. All rights reserved.”, “@odata.context”: “/redfish/v1/$metadata#Volume.Volume”, “@odata.id”: “/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1”, “@odata.type”: “#Volume_1_6_0.Volume”, “Name”: “MyVolume”, “Id”: “1”, “Description”: “Default Volume Description”, “RAIDType”: “RAID50”, “MediaSpanCount”: 10, “Identifiers”: [ { “DurableNameFormat”: “NAA”, “DurableName”: “65456765456761001234076100123487” } ], “Status”: { “State”: “Enabled”, “Health”: “OK” }, “CapacityBytes”: 1099511627776, “Links”: { “StoragePool”: “/redfish/v1/Storage/1/StoragePools/PrimaryPool” } }
```
2b. If the implementation requires a background task (using the Redfish task service) to return status:
Response returns success.
Response: 202 Accepted.
Headers: Location = /redfish/v1/TaskService/Tasks/TaskID2
Body: None.
A GET on volume while task is pending will indicate the in-process change to RAIDType, and that the transition to the new RAID layout is not complete, using Status.State
and Status.Health
:
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "Default Volume Description",
"RAIDType": "RAID50",
"MediaSpanCount": 10,
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Updating",
"Health": "Warning"
},
"CapacityBytes": 1099511627776,
"Links": {
"StoragePool": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1"
}
}
A subsequent GET on the Volume, once the task has completed, will reflect the new values:
Request: GET /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Response: 200 OK.
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body: ```json
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "Default Volume Description",
"RAIDType": "RAID50",
"MediaSpanCount": 10,
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Enabled",
"Health": "OK"
},
"CapacityBytes": 1099511627776,
"Links": {
"StoragePool": "/redfish/v1/Storage/1/StoragePools/PrimaryPool"
}
} ```
Postconditions: None defined.
Failure Scenario: If the system is unable to complete the requrested change to the RAID layout for some reason (e.g., insufficient Drives in the underlying StoragePool to support the requested MediaSpanCount), the initial POST
will result in an error. For example:
Use the ChangeRAIDLayout
Action on the Volume, passing the requested MediaSpanCount as input, as in the initial scenario.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Actions/ChangeRAIDLayout
Headers: No additional headers required.
Body:
{
"MediaSpanCount": 10
}
Response: 400
Headers: None.
Body:
{
"error": {
"code": "Base.1.6.ActionParameterMissing",
"message": "The action ChangeRAIDLayout requires the parameter Drives to be present in the request body.",
"@Message.ExtendedInfo" : [
"MessageId": "Base.1.6.ActionParameterMissing",
"Message" : "The Drives paramter must be included in this request",
"RelatedProperties" : "Drives"
]
}
}
See also: None defined.
Summary: Create a class of service
Purpose: Create a new class of service in the service catalog to match a newly available type of storage
Who: StorageAdmin
Management Domain: Block storage management, Service catalog management
Triggers: The administrator has determined that a new class of service needs to be created to reflect a new class of SSD storage in the infrastructure.
Detailed Context: This is a simple scenario where the primary characteristic is the enhanced performance available from SSD drives.
Preconditions: None defined.
Feature(s): Class of Service
Inputs:
URL for Storage Service: /redfish/v1/StorageServices(1)
New class of service characteristics
Name: "SSD"
Description: "Minimal SSD class of service."
IOPerformanceLineOfService
"SSDLoS"
false
100000
10
Basic Course of Events:
Request: POST /redfish/v1/StorageServices(1)/ClassesOfService/Members
Headers: No additional headers required.
Body:
{
"Name": "SSD",
"Description": "Minimal SSD class of service.",
"LinesOfService": {
"IOPerformanceLinesOfService": [ {
"Name": "SSDLoS",
"IOOperationsPerSecondIsLimited": false,
"MaxIOOperationsPerSecondPerTerabyte": 100000,
"AverageIOOperationLatencyMicroseconds": 10
}]
}
}
Headers:
Location= /redfish/v1/StorageServices(1)/ClassesOfService(SSD)
Postconditions: The requested class of service is added to the ClassesOfService collection.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a file share
Purpose: Share an existing file system as /Shares/MyShare
Who: CloudAdmin, StorageAdmin, DevOps
Management Domain: File system storage management
Triggers: None defined.
Detailed Context: Create a share starting at /Shares/MyShare.
Preconditions: None defined.
Feature(s): File provisioning
Inputs:
/redfish/v1/StorageServices/1/FileSystems/QuickFiles
"/Shares/MyShare"
"Share of files under MyShare."
Basic Course of Events:
1. Create a file share
Request: POST /redfish/v1/StorageServices/1/FileSystems/QuickFiles/ExportedShares
Headers: No additional headers required.
Body:
{
"Name" : "MyShare",
"Description" : "Share of files under MyShare.",
"SharedFilePath" : "/Shares/MyShare"
}
Response:
Headers:
Location= /redfish/v1/StorageServices/1/FileSystems/QuickFiles/ExportedShares/MyShare
Postconditions: The requested file share is added to the ExportedShares collection for the file system.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a file system
Purpose: Create a file system with a given capacity and performance level.
Who: StorageAdmin
Management Domain: File system storage management
Triggers: None defined.
Detailed Context: Create a 100 TB file system based on SSD class storage.
Preconditions: None defined.
Feature(s): Class of Service
Inputs:
URL for storage service: /redfish/v1/StorageServices/1
Name for the new file system: "QuickFiles"
Description: "100 TB FileSystem having SSD class storage."
URL for class of service: /redfish/v1/StorageServices/1/Links/ClassesOfService/SSD
File system capacity:
{
"Data":
{
"ProvisionedBytes": 100000000000000,
"IsThinProvisioned": true
}
}
Basic Course of Events:
Request: POST /redfish/v1/StorageServices/1/FileSystems
Headers: No additional headers required.
Body:
{
"Name": "QuickFiles",
"Description": "100 TB FileSystem having SSD class storage.",
"Capacity": {
"Data": {
"ProvisionedBytes": 100000000000000
},
"IsThinProvisioned": true
},
"Links" : {
"ClassOfService": {"odata.id":
"/redfish/v1/StorageServices/1/Links/ClassesOfService/SSD"}
}
}
Response:
Location= /redfish/v1/StorageServices/1/FileSystems/QuickFiles
Postconditions: The requested file system is added to the FileSystems collection for the Storage Service.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a file system
Purpose: Create a file system with a given capacity and performance level.
Who: StorageAdmin
Management Domain: File system storage management
Triggers: None defined.
Detailed Context: Create a 100 TB file system based on SSD class storage.
Preconditions: None defined.
Feature(s): File provisioning
Inputs:
URL for storage service: /redfish/v1/StorageServices/1
Name for the new file system: "QuickFiles"
Description: "100 TB FileSystem having SSD class storage."
URL for class of service: /redfish/v1/StorageServices/1/Links/ClassesOfService/SSD
File system capacity:
{
"Data":
{
"ProvisionedBytes": 100000000000000;
"IsThinProvisioned": true;
}
}
Basic Course of Events:
Request: POST /redfish/v1/StorageServices/1/FileSystems
Headers: No additional headers required.
Body:
{
"Name": "QuickFiles",
"Description": "100 TB FileSystem having SSD class storage.",
"Capacity": {
"Data": {
"ProvisionedBytes": 100000000000000
},
"IsThinProvisioned": true
},
"Links" : {
"ClassOfService": {"odata.id":
"/redfish/v1/StorageServices/1/Links/ClassesOfService/SSD"}
}
}
Response:
Location= /redfish/v1/StorageServices/1/FileSystems/QuickFiles
Postconditions: The requested file system is added to the FileSystems collection for the Storage Service.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a line of service to reflect the performance characteristics of SSD storage
Purpose: The definition is created here in preparation of creating ClassOfService instances that include a requirement for SSD storage performance.
Who: StorageAdmin
Management Domain: Block storage management, Service catalog management
Triggers: None defined.
Detailed Context: SSD storage is introduced and need a new performance line of service to reflect their capability.
Preconditions: None defined.
Feature(s): Class of Service
Inputs:
URL for Storage Service: /redfish/v1/StorageServices/1
New IO performance line of service
{
"Name": "NewSSDLoS",
"IoOperationsPerSecondIsLimitedBoolean": false,
"MaxIoOperationsPerSecondPerTerabyte": 100000,
"AverageIoOperationLatencyMicroseconds": 10
}
Basic Course of Events:
1. Get existing supported lines of service
Request:
GET /redfish/v1/StorageServices/1/Links/IOPerformanceLoSCapabilities/SupportedIOPerformanceLinesOfService
Reply:
Headers: `ETag: “123-a”``
Body:
{
"Value": [{
"Name": "LoS1",
"IoOperationsPerSecondIsLimitedBoolean": false,
"SamplePeriodSeconds": 60,
"MaxIoOperationsPerSecondPerTerabyte": 83,
"AverageIoOperationLatencyMicroseconds": 8000,
},
{
"Name": "LoS2",
"IoOperationsPerSecondIsLimitedBoolean": "false",
"SamplePeriodSeconds": 60,
"MaxIoOperationsPerSecondPerTerabyte": 133,
"AverageIoOperationLatencyMicroseconds": 5000,
"IOWorkload": {
"Name": "Duplicon: OLTP"
}
}]
}
2. Create new line of service
Request:
PATCH /redfish/v1/StorageServices/1/Links/IOPerformanceLoSCapabilities
Headers:
`If-Match: "123-a"`
Body:
{
"SupportedIOPerformanceLinesOfService":[{
"Name": "LoS1",
"IoOperationsPerSecondIsLimitedBoolean": false,
"SamplePeriodSeconds": 60,
"MaxIoOperationsPerSecondPerTerabyte": 83,
"AverageIoOperationLatencyMicroseconds": 8000
},
{
"Name": "LoS2",
"IoOperationsPerSecondIsLimitedBoolean": "false",
"SamplePeriodSeconds": 60,
"MaxIoOperationsPerSecondPerTerabyte": 133,
"AverageIoOperationLatencyMicroseconds": 5000,
"IOWorkload": {
"Name": "Duplicon: OLTP"
}
},
{
"Name": "NewSSDLoS",
"IoOperationsPerSecondIsLimitedBoolean": "false",
"MaxIoOperationsPerSecondPerTerabyte": 100000,
"AverageIoOperationLatencyMicroseconds": 10
}]
}
Response:
Postconditions: The requested line of service is added to the SupportedIOPerformanceLinesOfService of the Storage Service.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a StoragePool
Purpose: Create a StoragePool using a Specified set of drives and a specified set of supported RAIDTypes
Who: StorageAdmin
Management Domain: Block storage management
Triggers: Users need to allocate storage.
Detailed Context: Create a storage pool containing an amount of storage that can be used to create volumes with the specified set of RAIDTypes.
Preconditions: The user has the information about the set of drives.
Feature(s): None.
Inputs:
URL for storage pool collection:
NSB: /redfish/v1/Storage/1/StoragePool
(Also applicable to SB: /redfish/v1/StorageServices/1/StoragePool)
Name for the new storage pool: "SSD"
Description: "SSD Storage Pool"
Set of Drives:
{
"Drives": [
{"odata.id": "/redfish/v1/Storage/1/Drive/1"},
{"odata.id": "/redfish/v1/Storage/1/Drive/2"},
{"odata.id": "/redfish/v1/Storage/1/Drive/3"},
{"odata.id": "/redfish/v1/Storage/1/Drive/4"},
{"odata.id": "/redfish/v1/Storage/1/Drive/5"},
{"odata.id": "/redfish/v1/Storage/1/Drive/6"},
{"odata.id": "/redfish/v1/Storage/1/Drive/7"},
{"odata.id": "/redfish/v1/Storage/1/Drive/8"}
]
}
{
"SupportedRAIDTypes": ["RAID1","RAID5","RAID50"]
}
Basic Course of Events:
Request: POST /redfish/v1/Storage/1/StoragePools/
Headers: No additional headers required.
Body:
{
"Name": "SSD",
"Description": "Storage Pool for RAID1, 5 or 50.",
"RAIDTypes": ["RAID1","RAID5","RAID50"],
"Drives": [
{"odata.id": "/redfish/v1/Storage/1/Drive/1"},
{"odata.id": "/redfish/v1/Storage/1/Drive/2"},
{"odata.id": "/redfish/v1/Storage/1/Drive/3"},
{"odata.id": "/redfish/v1/Storage/1/Drive/4"},
{"odata.id": "/redfish/v1/Storage/1/Drive/5"},
{"odata.id": "/redfish/v1/Storage/1/Drive/6"},
{"odata.id": "/redfish/v1/Storage/1/Drive/7"},
{"odata.id": "/redfish/v1/Storage/1/Drive/8"}
]
Response: None.
Headers:
Location=/redfish/v1/Storage/1/StoragePools/SSD
Post-Conditions: The requested StoragePool is added to the collection for Storage.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a StoragePool
Purpose: Create a StoragePool using a specified set of drives
Who: StorageAdmin
Management Domain: Block storage management
Triggers: Users need to allocate storage.
Detailed Context: Create a storage pool containing an amount of storage that can be used to create volumes with the specified set of RAIDTypes.
Preconditions: The user has the information about the set of drives.
Feature(s): None.
Inputs:
URL for storage pool collection:
NSB: /redfish/v1/Storage/1/StoragePool
(Also applicable to SB: /redfish/v1/StorageServices/1/StoragePool)
Name for the new storage pool: "SP1"
Description: "Storage Pool 1"
Set of Drives:
{
"Drives": [
{"odata.id": "/redfish/v1/Storage/1/Drive/1"}
]
}
Basic Course of Events:
Request: POST /redfish/v1/Storage/1/StoragePools/
Headers: No additional headers required.
Body:
{
"Name": "SSD",
"Description": "Storage Pool 1",
"Drives": [
{"odata.id": "/redfish/v1/Storage/1/Drive/1"}
]
}
Response:
Headers:
`Location=/redfish/v1/Storage/1/StoragePools/SP1`
Post-Conditions: The requested StoragePool is added to the collection for Storage.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a StoragePool
Purpose: Create a StoragePool
Who: StorageAdmin
Management Domain: Block storage management
Triggers: Users need to allocate storage with characteristics satisfied by a class of service.
Detailed Context: Create a storage pool containing an amount of storage that can be used to create a requested class of service. The storage pool implementation will attempt to find and allocate enough storage that will satisfy the request. No metadata or snapshot storage is reserved.
Preconditions: None defined.
Feature(s): Class of Service
Inputs:
/redfish/v1/StorageServices/1
"SSD"
"100 TB pool of SSD class storage."
/redfish/v1/StorageServices/1/ClassesOfService/SSD
{
"Data": {
"ProvisionedBytes": 100000000000000,
"IsThinProvisioned": false
}
}
Basic Course of Events:
Request: POST /redfish/v1/StorageServices/1/StoragePools/Members
Headers: No additional headers required.
Body:
{
"Name": "SSD",
"Description": "100 TB pool of SSD class storage.",
"Capacity": {
"Data": {
"ProvisionedBytes": 100000000000000
},
"IsThinProvisioned": false
},
"ClassesOfService": {
"Members": [{
"@odata.id": "/redfish/v1/StorageServices/Members/1/ClassesOfService/SSD"
}]
}
}
Response:
Headers:
Location=/redfish/v1/StorageServices/1/StoragePools/SSD
Post-Conditions: The requested StoragePool is added to the collection for the Storage Service.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a StorageGroup
Purpose: Create a StorageGroup
Who: CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: Create a collection of application storage that is exposed to an application and managed as a unit.
Preconditions: None defined.
Feature(s): Mapping and masking
Inputs:
/redfish/v1/StorageService
true
Basic Course of Events:
Request: POST /redfish/v1/StorageService/StorageGroups/Members
Headers: No additional headers required.
Body:
{
"Name" : "HillOfBeans1",
"Description" : "New storage group to support accounting",
"MembersAreConsistent" : true
}
Response: None defined.
Postconditions: The requested StorageGroup is added to the Members collection for the Storage Service.
Failure Scenario: None defined.
See also: None defined.
Summary: Create a new Volume from a Storage Pool.
Purpose: Create a new volume, with a specified capacity, from a previously created StoragePool.
Who: CloudAdmin, StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to allocate storage for a new application.
Detailed Context: The admin needs to satisfy a user or application request to provide a given amount of capacity with a specified RAIDType, and wants to leverage a preconfigured Storage Pool.
Preconditions: User has already selected a Pool and checked the supported RAIDType properties.
Feature(s): Block provisioning
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool
1099511627776
"MyVolume"
RAID1
Basic Course of Events:
This instructs the service to use the identified StoragePool to allocate a new volume of the requested size that meets the requirements of the specified protection level. Since additional details are not provided, the service will rely on default values as required.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool
Headers: No additional headers required.
Body:
{
"Name" : "MyVolume",
"CapacityBytes" : 1099511627776,
"RAIDType" : "RAID1"
}
Response contains the details of the created volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/Volumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "Default Volume Description",
"RAIDType": "RAID1",
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Enabled",
"Health": "OK"
},
"CapacityBytes": 1099511627776,
"Links": {
"StoragePool": "/redfish/v1/Storage/1/StoragePools/1"
}
}
Postconditions: The selected volume is added to the AllocatedVolumes collection within the selected storage pool.
Failure Scenario: None defined
See also: None defined.
Summary: Add a new Volume to the Volume Collection
Purpose: Create a new volume with a specified capacity, RAID Type, and set of drives.
Who: CloudAdmin, StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to allocate storage for a new application.
Detailed Context: The admin needs to satisfy a user or application request to provide a given amount of capacity, and to assure a given protection level.
Preconditions: None.
Feature(s): Block provisioning
Inputs:
/redfish/v1/Storage/1/Volumes
1099511627776
"MyVolume"
RAID1
/redfish/v1/Chassis/1/Drives
: - /redfish/v1/Chassis/1/Drive/1
- /redfish/v1/Chassis/1/Drive/2
Basic Course of Events:
This instructs the service to allocate a new volume of the requested size that meets the requirements of the specified protection level. Since additional details are not provided, the service will rely on default values as required.
Request: POST /redfish/v1/Storage/1/Volumes
Headers: No additional headers required.
Body:
{
"Name" : "MyVolume",
"CapacityBytes" : 1099511627776,
"RAIDType" : "RAID1",
"Drives" : [
{"odata.id" : "/redfish/v1/Chassis/1/Drive/1"},
{"odata.id" : "/redfish/v1/Chassis/1/Drive/2"}
]
}
Response:
Headers: Location = /redfish/v1/Storage/1/Volumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/Volumes/1",
"@odata.type": "#Volume_1_4_0.Volume",
"Name": "MyVolume",
"Id": "1",
"Description": "",
"RAIDType": "RAID1",
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "65456765456761001234076100123487"
}
],
"Status": {
"State": "Enabled",
"Health": "OK"
},
"CapacityBytes": 1099511627776,
"Links" : {
"Drives": [
{"odata.id": "/redfish/v1/Chassis/1/Drives/1"},
{"odata.id": "/redfish/v1/Chassis/1/Drives/2"}
]
}
}
Postconditions: The selected volume is added to the Volume collection for Storage.
Failure Scenario: None defined
See also: None defined.
Summary: Create a Volume
Purpose: Create a Volume with a known capacity and class of service.
Who: CloudAdmin, StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to allocate storage for a new application.
Detailed Context: The admin needs to satisfy a service request to provide a given amount of storage to an application, and to assure a given class of service.
Preconditions: None.
Feature(s): Class of Service
Inputs:
/redfish/v1/StorageServices/1
1099511627776
/redfish/v1/StorageServices/1/ClassesofService/BostonBunker
"Snapshot1"
Basic Course of Events:
This instructs the service to allocate a new volume of the requested size that meets the requirements of the specified class of service. Since additional details are not provided, the service is free to allocate the storage from any of its storage pools that can satisfy the request.
Request: POST /redfish/v1/StorageServices/1/Volumes/Members
Headers: No additional headers required.
Body:
{
"Name": "Snapshot1",
"CapacityBytes": 1099511627776,
"Links": {
"ClassOfService": {"odata.id":
"/redfish/v1/StorageServices/1/ClassesofService/BostonBunker"}
}
}
Response:
Headers:
Location = /redfish/v1/StorageServices/1/Volumes/3
{
"\@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"\@odata.context": "/redfish/v1/\$metadata\#Volume.Volume",
"\@odata.id": "/redfish/v1/StorageServices/1/Volumes/3",
"\@odata.type": "\#Volume_1_0_0.Volume",
"Name": "Snapshot1",
"Id": "3",
"Description": "",
"Identifiers": [
{
"DurableNameFormat": "NAA6",
"DurableName": "65456765456761001234076100123487"
}
],
"Manufacturer": "SuperDuperSSD",
"Model": "Drive Model string",
"Status": {
"State": "Enabled",
"Health": "OK"
},
"AccessCapabilities": [
"Read",
"Write",
"Append",
"Streaming"
],
"BlockSizeBytes": 512,
"CapacitySources": [
{
"ConsumedBytes": 0,
"AllocatedBytes": 10737418240,
"GuaranteedBytes": 536870912,
"ProvisionedBytes": 1099511627776,
"Links": {
"ClassOfService": {
"\@odata.id": "/redfish/v1/StorageServices/1/Links/ClassesOfService/SilverBoston"
},
"ProvidingPool": {
"\@odata.id": "/redfish/v1/StorageServices/1/StoragePools/SpecialPool"
}
}
}],
"CapacityBytes": 1099511627776,
"Capacity": {
"Data": {
"ConsumedBytes": 0,
"AllocatedBytes": 10737418240,
"GuaranteedBytes": 1099511627776,
"ProvisionedBytes": 1099511627776
},
"Metadata": {
"ConsumedBytes": 536870912,
"AllocatedBytes": 536870912
}
},
"Links": {
"ClassofService": {
"\@odata.id":
"/redfish/v1/StorageServices/1/Links/ClassesofService/BostonBunker"
}
}
}
Postconditions: The selected volumes are added to the collection for the Storage Group.
Failure Scenario: None defined
See also: None defined.
Summary: Deprovision a Namespace
Purpose: Deprovision (delete) a Namespace that is no longer needed.
Who: StorageAdmin CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: Delete the namespace and free resources reserved for it. This can happen regardless of the controller attachment state of the namespace.
Preconditions: None defined.
Feature(s): NVMe
Inputs:
Basic Course of Events:
Delete the Namespace.
Request: DELETE /redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Volumes/SimpleNamespace
Headers: No additional headers required.
Body: None defined.
Response: None defined.
Postconditions: The requested namespace has been deprovisioned.
Failure Scenario: None defined.
See also: None defined.
Summary: Retrieve storage capacity information for a storage pool to check available capacity before expanding a storage volume.
Purpose:
Who: StorageAdmin at an enterprise
Management domain: Block storage management
Trigger: Low available capacity warning
Detailed context: The enterprise administrator offers managed storage services to business units in her organization. The administrator has established an SLA with application owners for storage volume expansion:
The application monitoring tool sends a warning alert to the administrator’s datacenter monitoring tool indicating that a storage volume’s capacity is at 80% and must be increased to ensure the application does not experience unplanned downtime. The administrator first checks the available capacity on the storage pool for a given storage class of service. Since the storage system is new, there is sufficient capacity available. Next the administrator figures out that the storage volume has never been expanded based on the original size tag. At the start of the maintenance window, non-business hours, the administrator initiates the expand action. For this particular storage system, the expand is a long running action so the administrator tracks the progress using the associated task.
Preconditions:
Feature(s): Block capacity management
Inputs:
/redfish/v1/StorageService/1
BasePool
61001234876545676100123487654567
Basic Course of Events:
Request: GET /redfish/v1/StorageServices/1/Volumes/61001234876545676100123487654567
Response:
{
"@Redfish.Copyright": "Copyright 2015-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/StorageServices/1/Volumes/61001234876545676100123487654567",
"@odata.type": "#Volume_1_0_0.Volume",
"Id": "61001234876545676100123487654567",
"Name": "Volume 1",
"Description": "application storage",
"Identifiers": [
{
"DurableNameFormat": "NAA6",
"DurableName": "61001234876545676100123487654567"
}
],
"Manufacturer": "SuperDuperStorageProvider",
"Status": {
"State": "Enabled",
"Health": "OK"
},
"BlockSizeBytes": 512,
"LowSpaceWarningThresholdPercent": [
80,
null,
null,
null,
null
],
"Capacity": {
"Data": {
"ConsumedBytes": 879609302221,
"AllocatedBytes": 879609302221,
"GuaranteedBytes": 549755813888,
"ProvisionedBytes": 1099511627776
},
}
}
Request: GET /redfish/v1/StorageServices/1/StoragePools/BasePool
Response:
{
"@Redfish.Copyright": "Copyright 2015-2016 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#StoragePool.StoragePool",
"@odata.id": "/redfish/v1/StorageServices/1/StoragePools/BasePool",
"@odata.type": "#StoragePool.1_0_0.StoragePool",
"Id": "BasePool",
"Name": "BasePool",
"Description": "Base storage pool for this storage service",
"Status": {
"State": "Enabled",
"Health": "OK",
"HealthRollUp": "Degraded"
},
"BlockSizeBytes": 8192,
"Capacity": {
"Data": {
"ConsumedBytes": 824633720832,
"AllocatedBytes": 1099511627776
},
"Metadata": null,
"Snapshot": null
},
"CapacitySources": [
{
"ProvidedCapacity": {
"ConsumedBytes": 70368744177664,
"AllocatedBytes": 140737488355328,
"GuaranteedBytes": 17592186044416,
"ProvisionedBytes": 562949953421312
},
"Links": {
"ClassOfService": {
"@odata.id": "/redfish/v1/StorageServices/1/ClassesOfService/GoldBoston"
},
"ProvidingPool": null,
"ProvidingVolume": null
}
}
],
"LowSpaceWarningThresholdPercent": [
70,
80,
90
],
"Links": {
"AllocatedPools": [],
"AllocatedVolumes": [
{
"@odata.id": "/redfish/v1/StorageServices/1/Volumes/61001234876545676100123487654567"
}
],
"SupportedClassesOfService": [
{
"@odata.id": "/redfish/v1/StorageServices/1/ClassesOfService/GoldBoston"
},
{
"@odata.id": "/redfish/v1/StorageServices/1/ClassesOfService/SilverBoston"
}
]
}
}
Note that there are two different properties that can be used to report available capacity, depending on the implementation - either CapacityBytes or Capacity->Data->AllocatedBytes. This use case shows how to do this function using the latter property, but would work equally if the implementation supported this function using the CapacityBytes property instead.
Request: PATCH /redfish/v1/StorageServices/1/Volumes/61001234876545676100123487654567
Headers: No additional headers required
Body:
{
"Capacity": {
"Data": {
"AllocatedBytes": 1374389534720
}
}
}
Response:
{
"taskid":"ExpandTask123"
}
Postconditions: The volume’s capacity expands by 25%. Administrator needs to track the associated task to know when the volume expansion completes.
See also: None defined.
Summary: Retrieve storage metrics information for a storage volume.
Purpose:
Who: DevOps at an enterprise
Management domain: Block storage management
Trigger: Lower than expected application requests completed per second
Detailed context: Devops creates diagnostics scripts that retrieve performance information from multiple layers in the application stack, including infrastructure, to help identify potential bottlenecks during production hours. Devops already understand that the issue is not in the application layers so now they have to dig deeper. Members of devops are typically not experts in infrastructure compute, storage, and networking so they need simple scripts that can provide the information they require without a deep understanding of underlying hardware. With the storage administrator’s help, devops use a few simple GETs on storage objects related to their application. To help simplify the query, the storage administrator tags the volumes associated with the application. Devops can use stack wide performance metrics to quickly isolate potential bottlenecks that may be contributing to the slow down in the application.
Preconditions:
Feature(s): Block IO performance
Inputs:
/redfish/v1/StorageServices/1
4
Basic course of events:
Request: GET /redfish/v1/StorageServices/1/Volumes/4/Metrics
Response:
{
"@Redfish.Copyright": "Copyright 2015-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#VolumeMetrics.VolumeMetrics",
"@odata.id": "/redfish/v1/StorageServices/1/Volumes/4/Metrics",
"@odata.type": "#VolumeMetrics.v1_0_0.VolumeMetrics",
"Id": "Metrics",
"Name": "Volume 1 Metrics",
"CurrentPeriod": {
"BlocksRead": 125534,
"BlocksWritten": 542653
},
"Lifetime": {
"BlocksRead": 125534,
"BlocksWritten": 542653
},
"PerformanceData": {
"AverageSecondsPerRead": 1,
"AverageSecondsPerWrite": 1,
"AverageSecondsPerTransfer": 1,
"ReadsPerSecond": 2134,
"WritesPerSecond": 4325,
"TransfersPerSecond": 6459,
"WriteBlocksPerSecond": 3085784,
"ReadBlocksPerSecond": 9257350,
"BlocksPerSecond": 12343134
},
"Actions": {
"#Volume.ClearCurrentPeriod": {
"target": "/redfish/v1/StorageServices/1/Volumes/4/Actions/Volume.ClearCurrentPeriod"
},
"Oem": {}
},
"Oem": {}
}
Postconditions: None defined.
See also: None defined.
Summary: Create a new Consistency Group to serve as the target in the replication relationship for an existing source Consistency Group.
Purpose: Create a new ConsistencyGroup resource to provide expanded data protection through a replica relationship with the specified source ConsistencyGroup.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to create a replication relationship for a source ConsistencyGroup when there are no existing ConsistencyGroups that can be assigned as the target.
Detailed Context: The admin needs to satisfy a user or application request for a copy of some sort of the original ConsistencyGroup.
Preconditions: User has already selected the type of replica, the replica update mode (sync vs async), and the target system and storage pool from which to create the new ConsistencyGroup to serve as the replica.
Feature(s): Replication (both local and remote)
Inputs:
URL for Storage Pool: /redfish/v1/Storage/1/StoragePools/PrimaryPool
Requested replica type: Mirror
Requested name of ConsistencyGroup (string): CG_DB2
ReplicaUpdateMode: Synchronous
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1/ConsistencyGroup.CreateReplicaTarget
Headers: No additional headers required.
Body:
{
"ConsistencyGroupName" : "CG_DB2",
"ReplicaUpdateMode" : "Synchronous",
"TargetStoragePool" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool",
"ReplicaType" : "Mirror"
}
Response contains the details of the created ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/ConsistencyGroups/23423"}]
}
Postconditions: The selected ConsistencyGroup has a new ReplicaTargets property with the link to the new ConsistencyGroup. Elsewhere, there is a new ConsistencyGroup in the system (Name == “CG_DB2”, the id set by the system to 23423) that has a ReplicaInfo pointing back to this ConsistencyGroup and which contains all of the replication properties.
Failure Scenario: None defined
See also: Create Replica Target
Summary: Create a new volume to serve as a target replica for an existing source volume.
Purpose: Create a new volume resource to provide expanded data protection through a replica relationship with the specified source volume.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to create a replication relationship for a source volume when there are no existing volumes that can be assigned as the target.
Detailed Context: The admin needs to satisfy a user or application request for a copy of some sort of the original volume.
Preconditions: User has already selected the type of replica, the replica update mode (sync vs async), and the target system and storage pool from which to create the new volume to serve as the replica.
Feature(s): Replication (both local and remote)
Inputs:
URL for Storage Pool: /redfish/v1/Storage/1/StoragePools/PrimaryPool
Requested replica type: Mirror
Requested name of volume (string): Mirror of Volume 65
ReplicaUpdateMode: Synchronous
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.CreateReplicaTarget
Headers: No additional headers required.
Body:
{
"VolumeName" : "Mirror of Volume 65",
"ReplicaUpdateMode" : "Synchronous",
"TargetStoragePool" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool",
"ReplicaType" : "Mirror"
}
Response contains the details of the created volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/2345"}]
}
Postconditions: The selected volume has a new ReplicaTargets property with the link to the new volume. Elsewhere, there is a new volume in the system (Name == “Mirror of Volume 65”, the id set by the system to 2345) that has a ReplicaInfo pointing back to this volume and which contains all of the replication properties.
Failure Scenario: None defined
See also: Create Replica Target (CG)
Summary: Provision a Namespace
Purpose: Provision a Namespace from a simple NVMe device that does not support Endurance Groups and NVM Sets.
Who: StorageAdmin CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: Create a namespace, and allocate resources reserved for it, from an NVMe device that does not support Endurance Groups and NVM Sets. The Create Namespace request is performed on the Volume Collection in this configuration. The admin needs to satisfy a user or application request to provide a given amount of capacity by creating a new Namespace. Note that this specific use case does not include the assignment of this namespace to an IO Controller.
Preconditions: User has already selected the desired capacity.
Feature(s): NVMe
Inputs:
/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes
1099511627776
(Provisioned Capacity), 1099511627776
(Allocated Capacity)"MyNamespace"
Basic Course of Events:
This instructs the service to provision (create) a new Namespace of the requested size. Any additional protection properties will be inherited from the NVM Subsystem.
Request: POST /redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes
Headers: No additional headers required.
Body:
{
"Name" : "MyNamespace",
"Capacity": {
"Data": {
"AllocatedBytes": 1099511627776,
"ProvisionedBytes": 1099511627776
}
}
}
Response:
Response contains the details of the created volume.
Headers:
Location = /redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/MyNamespace"
Body:
{
"@Redfish.Copyright": "Copyright 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/MyNamespace",
"@odata.type": "#Volume.v1_5_0.Volume",
"Id": "1",
"Name": "MyNamespace",
"LogicalUnitNumber": 1,
"Status": {
"State": "Enabled",
"Health": "OK"
},
"Identifiers": [
{
"DurableNameFormat": "NQN",
"DurableName": "nqn.2014-08.org.nvmexpress:uuid:6c5fe566-10e6-4fb6-aad4-8b4159029384"
}
],
"Capacity": {
"Data": {
"ConsumedBytes": 0,
"AllocatedBytes": 1099511627776,
"ProvisionedBytes": 1099511627776
}
},
"CapacitySources": [
{
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/MyNamespace/CapacitySources/Source1"
}
],
"NVMeNamespaceProperties": {
"NamespaceId": "0x224",
"NamespaceFeatures": {
"SupportsThinProvisioning": false,
"SupportsAtomicTransactionSize": false,
"SupportsDeallocatedOrUnwrittenLBError": false,
"SupportsNGUIDReuse": false,
"SupportsIOPerformanceHints": false
},
"NumberLBAFormats": 0,
"FormattedLBASize": "LBAFormat0Support",
"MetadataTransferredAtEndOfDataLBA": false,
"NVMeVersion": "1.4"
}
}
Postconditions: The selected Namespace has been created and is added to the NVM Subsystem.
Failure Scenario: None defined.
See also: NVMe use case to Attach a Namespace, and to Provision a Namespace with NVMSet.
Summary: Disable data synchronization between a source and target Consistency Group, remove the replication relationship, and optionally delete the target Consistency Group.
Purpose: The administrator wants to completely delete the relationship between the target and source ConsistencyGroups.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to remove a replication relationship due to changing system or environment requirements.
Detailed Context: The identified replication relationship is no longer needed, and is to be completely removed from the configuration.
Preconditions: User has already identified which replication relationship to delete, and whether or not to retain the target ConsistencyGroup.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2
false
Basic Course of Events:
This instructs the service to delete the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1/ConsistencyGroup.RemoveReplicaRelationship
Headers: No additional headers required.
Body:
{
"TargetConsistencyGroup": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2",
"DeleteTargetConsistencyGroup": "false"
}
Response contains the details of the source ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary"
}
Postconditions: The ConsistencyGroup will no longer have an entry in “ReplicaTargets” for the former replication relationship (the property is not returned in the above example if it were null). Elsewhere, the ConsistencyGroup “CG_DB2” in the system will still exist but will no longer have a StorageReplicaInfo which points back to this ConsistencyGroup.
Failure Scenario: None defined
See also: Remove Replication Relationship
Summary: Disable data synchronization between a source and target volume, remove the replication relationship, and optionally delete the target volume.
Purpose: The administrator wants to completely delete the relationship between the target and source volumes.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to remove a replication relationship due to changing system or environment requirements.
Detailed Context: The identified replication relationship is no longer needed, and is to be completely removed from the configuration.
Preconditions: User has already identified which replication relationship to delete, and whether or not to retain the target volume.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245
false
Basic Course of Events:
This instructs the service to delete the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.RemoveReplicaRelationship
Headers: No additional headers required.
Body:
{
"TargetVolume" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245",
"DeleteTargetVolume" : "false"
}
Response contains the details of the source volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_4_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": ""
}
Postconditions: The volume will no longer have an entry in “ReplicaTargets” for the former replication relationship (the property is not returned in the above example if it were null). Elsewhere, the volume “650973452245” in the system will still exist but will no longer have a StorageReplicaInfo which points back to this volume.
Failure Scenario: None defined
See also: Remove Replication Relationship (CG)
Summary: Report Namespace Capacity
Purpose: Report Namespace Capacity
Who: StorageAdmin CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: The namespace capacity information is provided as properties in the namespace object. The NVMe capacity information reported via the Redfish/Swordfish data structures maps the NVMe native capacity information into the RF/SF capacity structures, showing the capacity presented by the namespace to the consumer as AllocatedBytes (e.g., the addressable capacity), and the total available capacity of the namespace as ProvisionedBytes (e.g., the amount of addressable capacity that may actually be used). Note that for a thin provisioned system these values are expected to be different.
Preconditions: None defined.
Feature(s): NVMe
Inputs:
/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/Namespace1
Basic Course of Events:
Capacity.Data.AllocatedBytes
property within the returned JSON data:Request: GET /redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/Namespace1
Headers: No additional headers required.
Body:
{
"@Redfish.Copyright": "Copyright 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/Namespace1",
"@odata.type": "#Volume.v1_5_0.Volume",
"Id": "1",
"Name": "Namespace 1",
"LogicalUnitNumber": 1,
"Status": {
"State": "Enabled",
"Health": "OK"
},
"Identifiers": [
{
"DurableNameFormat": "NQN",
"DurableName": "nqn.2014-08.org.nvmexpress:uuid:6c5fe566-10e6-4fb6-aad4-8b4159029384"
}
],
"Capacity": {
"Data": {
"ConsumedBytes": 0,
"AllocatedBytes": 10737418240,
"ProvisionedBytes": 10737418240
}
},
"CapacitySources": [
{
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/NVMeSSD-EG/Volumes/Namespace1/CapacitySources/Source1"
}
],
"NVMeNamespaceProperties": {
"NamespaceId": "0x224",
"NamespaceFeatures": {
"SupportsThinProvisioning": false,
"SupportsAtomicTransactionSize": false,
"SupportsDeallocatedOrUnwrittenLBError": false,
"SupportsNGUIDReuse": false,
"SupportsIOPerformanceHints": false
},
"NumberLBAFormats": 0,
"FormattedLBASize": "LBAFormat0Support",
"MetadataTransferredAtEndOfDataLBA": false,
"NVMeVersion": "1.4"
},
"Links": {
}
}
Response: None defined.
Postconditions: The requested capacity information is returned in the GET request:
{
"Capacity": {
"Data": {
"ConsumedBytes": 0,
"AllocatedBytes": 10737418240,
"ProvisionedBytes": 10737418240
}
}
Failure Scenario: None defined.
See also: None defined.
Summary: Report Remaining Life for a Namespace
Purpose: Report Remaining Life for a Namespace
Who: StorageAdmin CloudAdmin
Management Domain: Block storage management
Triggers: None defined.
Detailed Context: The namespace itself doesn’t have the notion of “remaining life”. Instead, the user should go to the corresponding drive object, and retrieve the “PredictedMediaLifeLeftPercent” property. Note, for a system that has endurance groups and sets, the endurance group also has this property, and the namespace could take the related “PredictedMediaLifeLeftPercent” from its related endurance group as well.
Preconditions: The namespace object has a direct link (in the Links property) to its related Drive. This path may not exist in certain types of NVMe devices, such as an Opaque Array.
Feature(s): NVMe
Inputs:
Basic Course of Events:
GET the Namespace of interest.
Request: GET /redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Volumes/SimpleNamespace
Headers: No additional headers required.
Body:
{
"@Redfish.Copyright": "Copyright 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Volumes/SimpleNamespace",
"@odata.type": "#Volume.v1_5_0.Volume",
"Id": "1",
"Name": "Namespace 1",
"LogicalUnitNumber": 1,
"Status": {
"State": "Enabled",
"Health": "OK"
},
"Identifiers": [
{
"DurableNameFormat": "NQN",
"DurableName": "nqn.2014-08.org.nvmexpress:uuid:6c5fe566-10e6-4fb6-aad4-8b4159029384"
}
],
"Capacity": {
"Data": {
"ConsumedBytes": 0,
"AllocatedBytes": 10737418240
},
"Metadata": {
"AllocatedBytes": 536870912
}
},
"NVMeNamespaceProperties": {
"NamespaceId": "0x22F",
"NamespaceFeatures": {
"SupportsThinProvisioning": false,
"SupportsAtomicTransactionSize": false,
"SupportsDeallocatedOrUnwrittenLBError": false,
"SupportsNGUIDReuse": false,
"SupportsIOPerformanceHints": false
},
"NumberLBAFormats": 0,
"FormattedLBASize": "LBAFormat0Support",
"MetadataTransferredAtEndOfDataLBA": false,
"NVMeVersion": "1.4"
},
"Links": {
"Drives": {
"@odata.id": "/redfish/v1/Chassis/SimplestNVMeSSD/Drives/SimplestNVMeSSD"
}
}
}
Request: GET /redfish/v1/Chassis/SimplestNVMeSSD/Drives/SimplestNVMeSSD
Headers: No additional headers required.
Body:
{
"@odata.id": "/redfish/v1/Chassis/SimplestNVMeSSD/Drives/SimplestNVMeSSD",
"@odata.type": "#Drive.v1_9_0.Drive",
"IndicatorLED": "Lit",
"Model": "ST9146802SS",
"Revision": "S20A",
"Status": {
"State": "Enabled",
"Health": "OK"
},
"CapacityBytes": 899527000000,
"FailurePredicted": false,
"PredictedMediaLifeLeftPercent": 18,
"Protocol": "NVMe",
"MediaType": "SSD",
"Manufacturer": "Contoso",
"SerialNumber": "72D0A037FRD26",
"PartNumber": "SG0GP8811253178M02GJA00",
"Identifiers": [
{
"DurableNameFormat": "NAA",
"DurableName": "500003942810D13A"
}
],
"Links": {
"Volumes": [
{
"@odata.id": "/redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Volumes/SimpleNamespace"
}
]
},
"Actions": {
"#Drive.Reset": {
"target": "/redfish/v1/Chassis/SimplestNVMeSSD/Drives/SimplestNVMeSSD/Actions/Drive.Reset"
}
}
}
Postconditions: The drive object returned a “PredictedMediaLifeLeftPercent” value of 18. The user can use this value as the apparent namespace life value.
Failure Scenario: None defined.
See also: None defined.
Summary: Resume the active data synchronization between a source and target Consistency Group, without otherwise altering the replication relationship.
Purpose: The administrator wants to restore the relationship between the target and source ConsistencyGroups, since the temporary condition that led to a suspension of replication has passed.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to re-activate a suspended replication relationship.
Detailed Context: The temporary condition that led to a suspension of replication has passed, and the admin needs to resume replication using the existing replication relationship.
Preconditions: User has already identified which target ConsistencyGroup to resume, and implementation preserves replication information what a relationship is suspended.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/DB_CG1/ConsistencyGroup.ResumeReplication
Headers: No additional headers required.
Body:
{
"TargetConsistencyGroup": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"
}
Response contains the details of the source ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"}]
}
Postconditions: The selected ConsistencyGroup has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a ConsistencyGroup “CG_DB2” in the system that has a ReplicaInfo which points back to this ConsistencyGroup and which contains all of the Replica configuration information. The replica state in the target ConsistencyGroup has been updated according to the requested action (e.g., from “suspended” to “active”).
Failure Scenario: None defined
See also: Resume the Replication Synchronization Activity
Summary: Resume the active data synchronization between a source and target volume, without otherwise altering the replication relationship.
Purpose: The administrator wants to restore the relationship between the target and source volumes, since the temporary condition that led to a suspension of replication has passed.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to re-activate a suspended replication relationship.
Detailed Context: The temporary condition that led to a suspension of replication has passed, and the admin needs to resume replication using the existing replication relationship.
Preconditions: User has already identified which target volume to resume, and implementation preserves replication information what a relationship is suspended.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/Volumes/650973452245
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.ResumeReplication
Headers: No additional headers required.
Body:
{
"TargetVolume" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"
}
Response contains the details of the source volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"}]
}
Postconditions: The selected volume has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a volume “650973452245” in the system that has a ReplicaInfo which points back to this volume and which contains all of the Replica configuration information. The replica state in the target volume has been updated according to the requested action (e.g., from “suspended” to “active”).
Failure Scenario: None defined
See also: Resume the Replication Synchronization Activity (CG)
Summary: Reverse the replication relationship between a source and target Consistency Group.
Purpose: The administrator wants to reconfigure the relationship between the target and source ConsistencyGroups, reversing their roles.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request swapping the target/source roles in a replication relationship.
Preconditions: User has already identified which target ConsistencyGroup and replication relationship to reverse.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/DB_CG1/ConsistencyGroup.ReverseReplicationRelationship
Headers: No additional headers required.
Body:
{
"TargetConsistencyGroup": "/redfish/v1/Storage/1/ConsistencyGroups/DB_CG2"
}
Response contains the details of the source ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaInfos": [{
"ReplicaState": "Failedover",
"ReplicaType": "Snapshot",
"ReplicaPriority": "Default",
"ReplicaRecoveryMode": "Manual",
"ReplicaUpdateMode": "Asynchronous",
"Replica": {"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/DB_CG2"}
}],
}
Postconditions: The selected ConsistencyGroup will now have an updated ReplicaInfo for the relationship, which contains the replication attributes and a pointer to the source replica. Elsewhere, there is a ConsistencyGroup “DB_CG2” in the system that now has an ReplicaTargets entry that points back to this ConsistencyGroup (“@odata.id”: “/redfish/v1/Storage/1/ConsistencyGroups/DB_CG1”).
Failure Scenario: None defined
See also: Reverse a Replication Relationship
Summary: Reverse the replication relationship between a source and target volume.
Purpose: The administrator wants to reconfigure the relationship between the target and source volumes, reversing their roles.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request swapping the target/source roles in a replication relationship.
Preconditions: User has already identified which target volume and replication relationship to reverse.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.ReverseReplicationRelationship
Headers: No additional headers required.
Body:
{
"TargetVolume" : "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"
}
Response contains the details of the source volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaInfos": [{
"ReplicaState": "Failedover",
"ReplicaType": "Snapshot",
"ReplicaPriority": "Default",
"ReplicaRecoveryMode": "Manual",
"ReplicaUpdateMode": "Asynchronous",
"Replica": {"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"}
}],
}
Postconditions: The selected volume will now have an updated ReplicaInfo for the relationship, which contains the replication attributes and a pointer to the source replica. Elsewhere, there is a volume “650973452245” in the system that now has an ReplicaTargets entry that points back to this volume (“@odata.id”: “/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1”).
Failure Scenario: None defined
See also: Reverse a Replication Relationship (CG)
Summary: Split the replication relationship and suspend data synchronization between a source and target volume.
Purpose: The administrator wants to reconfigure the relationship between the target and source volumes.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request to change the existing configuration between the target and source volumes in a replication relationship.
Preconditions: User has already identified which target volume and replication relationship to split.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/Volumes/650973452245
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.SplitReplication
Headers: No additional headers required.
Body:
{
"TargetVolume": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"
}
Response contains the details of the source volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_6_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"}]
}
Postconditions: The selected volume has a new ReplicaTargets property with the link to the volume. Elsewhere, there is a volume “650973452245” in the system that has a ReplicaInfo pointing back to this volume and which contains all of the Replica configuration information. The replica state in the target volume has been updated according to the requested action (e.g., from “active” to “suspended / split”).
Failure Scenario: None defined
See also: Split a Replica (CG)
Summary: Split the replication relationship and suspend data synchronization between a source and target ConsistencyGroup.
Purpose: The administrator wants to reconfigure the relationship between the target and source ConsistencyGroups.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request to change the existing configuration between the target and source ConsistencyGroups in a replication relationship.
Preconditions: User has already identified which target ConsistencyGroup and replication relationship to split.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1/ConsistencyGroup.SplitReplication
Headers: No additional headers required.
Body:
{
"TargetConsistencyGroup" : "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"
}
Response contains the details of the source ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"}]
}
Postconditions: The selected ConsistencyGroup has a new ReplicaTargets property with the link to the ConsistencyGroup. Elsewhere, there is a ConsistencyGroup “650973452245” in the system that has a ReplicaInfo pointing back to this ConsistencyGroup and which contains all of the Replica configuration information. The replica state in the target ConsistencyGroup has been updated according to the requested action (e.g., from “active” to “suspended / split”).
Failure Scenario: None defined
See also: Split a Replica
Summary: Subscribe to Trigger/Clear events for LowSpaceWarningThresholds for a named Volume.
Purpose: Provide an event stream to support utilization management. This is used in conjunction with LowSpaceWarningThresholds to provide a means for on-going monitoring of resource consumption.
Who: CloudAdmin, StorageAdmin, DevOps
Management domain: Block storage management, Application storage management
Triggers: None defined.
Detailed Context: This provides the basis for monitoring capacity consumption.
Preconditions: None defined.
Feature(s): Event notification
Inputs:
The URL of the StorageService: /redfish/v1/StorageServices/Simple1
The Volume to be monitored: Vol1
The subscription destination: "http://www.dnsname.com/Destination1"
An array of events to be subscribed:
["LowSpaceWarningThresholdTriggered", "LowSpaceWarningThresholdCleared"]
Basic course of events:
Request: POST /redfish/v1/EventService/Subscriptions/Members
Headers: No additional headers required.
Body:
{
"@Redfish.Copyright": "Copyright 2016-2021 Storage Networking Industry Association (SNIA), USA. All rights reserved. For the full SNIA copyright policy, see http://www.snia.org/about/corporate_info/copyright",
"@odata.context": "/redfish/v1/$metadata#EventDestination.EventDestination",
"@odata.type": "#EventDestination.v1_0_2.EventDestination",
"Name": "Volume1 Usage Threshold",
"Destination": "http://www.dnsname.com/Destination1",
"EventTypes": [
"Alert"
],
"Context": "WebUser3",
"Protocol": "Redfish",
"OriginResources": [{"odata.id" : "/redfish/v1/StorageServices/Simple1/Volumes/Vol1"}],
"MessageIds": ["LowSpaceWarningThresholdTriggered", "LowSpaceWarningThresholdCleared"]
}
Response: 201 - Created
{
"Location": "/redfish/v1/EventService/Subscriptions/1/Members/1e7da"
}
Postconditions: Newly-created event subscription is added to the EventService.
Failure Scenario: None defined.
See also: None defined.
Summary: Suspend active data synchronization between a source and target ConsistencyGroup, without otherwise altering the replication relationship.
Purpose: Due to temporarily changed environmental constraints, the administrator wants to change the level of data protection between the target and source ConsistencyGroups.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request to change the existing configuration between the existing target and source ConsistencyGroups in a replication relationship, without deleting the relationship.
Preconditions: User has already identified which target ConsistencyGroup to suspend.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2
Basic Course of Events:
This instructs the service to use the identified ConsistencyGroup as the source ConsistencyGroup for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1/ConsistencyGroup.SuspendReplication
Headers: No additional headers required.
Body:
{
"TargetConsistencyGroup": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"
}
Response contains the details of the source ConsistencyGroup.
Response:
Headers: Location = /redfish/v1/Storage/1/ConsistencyGroups/CG_DB1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#ConsistencyGroup.ConsistencyGroup",
"@odata.id": "/redfish/v1/Storage/1/ConsistencyGroups/CG_DB1",
"@odata.type": "#ConsistencyGroup_1_0_0.ConsistencyGroup",
"Name": "ConsistencyGroup DB1",
"Id": "1",
"Description": "Database group 1 primary",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/ConsistencyGroups/CG_DB2"}]
}
Postconditions: The selected ConsistencyGroup has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a ConsistencyGroup “CG_DB2” in the system that has a ReplicaInfo which points back to this ConsistencyGroup and which contains all of the Replica configuration information. The replica state in the target ConsistencyGroup has been updated according to the requested action (e.g., from “Active” to “Suspended”).
Failure Scenario: None defined
See also: Suspend Replication Synchronization Activity
Summary: Suspend active data synchronization between a source and target volume, without otherwise altering the replication relationship.
Purpose: Due to temporarily changed environmental constraints, the administrator wants to change the level of data protection between the target and source volumes.
Who: StorageAdmin, DevOps
Management Domain: Block storage management
Triggers: Need to reconfigure existing storage due to changing system or environment requirements.
Detailed Context: The admin needs to satisfy a user or application request to change the existing configuration between the existing target and source volumes in a replication relationship, without deleting the relationship.
Preconditions: User has already identified which target volume to suspend.
Feature(s): Replication (both local and remote)
Inputs:
/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245
Basic Course of Events:
This instructs the service to use the identified Volume as the source Volume for the specified replication relationship. For any additional details required, the service will rely on default values.
Request: POST /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1/Volume.SuspendReplication
Headers: No additional headers required.
Body:
{
"TargetVolume": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"
}
Response contains the details of the source volume.
Response:
Headers: Location = /redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1
Body:
{
"@SSM.Copyright": "Copyright (c) 2014-2021 SNIA. All rights reserved.",
"@odata.context": "/redfish/v1/$metadata#Volume.Volume",
"@odata.id": "/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/1",
"@odata.type": "#Volume_1_4_0.Volume",
"Name": "Volume 65",
"Id": "1",
"Description": "",
"ReplicaTargets":[{"@odata.id":"/redfish/v1/Storage/1/StoragePools/PrimaryPool/AllocatedVolumes/650973452245"}]
}
Postconditions: The selected volume has an updated ReplicaTargets entry for the new relationship. Elsewhere, there is a volume “650973452245” in the system that has a ReplicaInfo which points back to this volume and which contains all of the Replica configuration information. The replica state in the target volume has been updated according to the requested action (e.g., from “Active” to “Suspended”).
Failure Scenario: None defined
