"RequiredProfiles": {
    "SwordfishDiscovery": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.1.4",
      "ReadRequirement": "None",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.",
        "CompareProfile": "SwordfishCoSDiscovery",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    },
    "SwordfishCoSDiscovery": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.2.0",
      "ReadRequirement": "None",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.",
        "CompareProfile": "SwordfishDiscovery",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    }

{
    "Protocol": {
        "MinVersion": "1.8"
    }
}

    "AllocatedPools": {
        "ReadRequirement": "None",
        "ConditionalRequirements": [{
            "Purpose": "Required when NVMePoolType = EnduranceGroup. If NVMSet, do not implement.",
            "CompareProperty": "/NVMeProperties/NVMePoolType",
            "CompareType": "Equal",
            "CompareValues": ["EnduranceGroup"],
            "Comparison": "Absent",
            "ReadRequirement": "Mandatory"
        }]
    }

{
    "Pepperoni": {
        "ReadRequirement": "Recommended",
        "ConditionalRequirements": [
            {
                "Purpose": "Pepperoni is required on all pizza types except Cheese.",
                "CompareProperty": "PizzaType",
                "CompareType": "NotEqual",
                "CompareValues": [
                    "Cheese"
                ],
                "ReadRequirement": "Mandatory",
                "Comparison": "Equal",
                "Values": [
                    true
                ]
            }
        ]
    }
}

{
    "IndicatorLED": {
        "ReadRequirement": "Recommended",
        "ConditionalRequirements": [
            {
                "Purpose": "Physical and composed systems must have a writable LED",
                "CompareProperty": "SystemType",
                "CompareType": "AnyOf",
                "CompareValues": [
                    "Physical",
                    "Composed"
                ],
                "ReadRequirement": "Mandatory",
                "WriteRequirement": "Mandatory"
            }
        ]
    }
}

{
    "SerialNumber": {
        "ReadRequirement": "Conditional",
        "ConditionalRequirements": [
            {
                "Purpose": "SerialNumber is required on Memory resources whose LocationType is not Embedded.",
                "CompareProperty": "/Location/PartLocation/LocationType",
                "CompareType": "NotEqual",
                "CompareValues": [
                    "Embedded"
                ],
                "ReadRequirement": "Mandatory"
            }
        ]
    }
}

    "Volume": {
      "Purpose": "One of the following mechanisms is required to support reporting of volume capacity.  In order to claim support of the Capacity Management Feature, correspondingly 'write' (expand) on that property must be supported.",
      "PropertyRequirements": {
        "CapacityBytes": {
          "ReadRequirement": "Recommended",
          "ConditionalRequirements": [{
              "Purpose": "Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.",
              "CompareProperty": "/Capacity/Data/AllocatedBytes",
              "CompareType": "Absent",
              "WriteRequirement": "Mandatory"
          }]
        },
        "Capacity": {
          "PropertyRequirements": {
            "Data": {
              "PropertyRequirements": {
                "AllocatedBytes": {
                  "ConditionalRequirements": [{
                      "Purpose": "Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.",
                      "CompareProperty": "CapacityBytes",
                      "CompareType": "Absent",
                      "WriteRequirement": "Mandatory"
                  }]
                }
              }
            }
          }
        }
      }
    }

    "EthernetInterface": {
      "ReadRequirement": "DoNotImplement",
      "Purpose": "This property is recommended as 'Do not implement' for this device and protocol type."
    },
    "PhysicalNetworkPortAssignment": {}
  }

  "NetworkPorts": {
    "ReadRequirement": "DoNotImplement",
    "Purpose": "Deprecated, do not implement."
  },

  "Volume": {
    "ActionRequirements": {
      "CreateReplicaTarget": {
        "ReadRequirement": "IfImplemented",
        "Purpose": "Ability to reset the system is a core requirement of most users.",
        "ConditionalRequirements": [{
          "Purpose": "Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support, when ReplicationEnabled is defined on the volume.",
          "CompareProperty": "ReplicationEnabled",
          "CompareType": "Absent",
          "ReadRequirement": "None"
        },
          {
          "Purpose": "Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support, when ReplicationEnabled is defined on the volume.",
          "CompareProperty": "AssignReplicaTarget",
          "CompareType": "Absent",
          "ReadRequirement": "Mandatory"
        }]
      },
      "AssignReplicaTarget": {
        "ReadRequirement": "IfImplemented",
        "Purpose": "Ability to reset the system is a core requirement of most users.",
        "ConditionalRequirements": [{
          "Purpose": "Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support, when ReplicationEnabled is defined on the volume.",
          "CompareProperty": "ReplicationEnabled",
          "CompareType": "Absent",
          "ReadRequirement": "None"
        },{
          "Purpose": "Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support.",
          "CompareProperty": "CreateReplicaTarget",
          "CompareType": "Absent",
          "ReadRequirement": "Mandatory"
        }]
      }
    }
  }

  "RequiredProfiles": {
    "SwordfishDiscovery": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.1.4"
    },
    "SwordfishBlockProvisioning": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.3.0"
    },
    "SwordfishFabricConnectivityRightsforEthernet": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.0.2",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishFabricConnectivityRightsforEthernet or SwordfishFabricConnectivityRightsforRDMA must be supported.",
        "CompareProfile": "SwordfishFabricConnectivityRightsforRDMA",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    },
    "SwordfishFabricConnectivityRightsforRDMA": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.0.2",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishFabricConnectivityRightsforEthernet or SwordfishFabricConnectivityRightsforRDMA must be supported.",
        "CompareProfile": "SwordfishFabricConnectivityRightsforEthernet",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    },
    "SwordfishFabricAccessRightsforEthernet": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.0.2",
      "ReadRequirement": "None",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishFabricAccessRightsforEthernet or SwordfishFabricAccessRights must be supported.",
        "CompareProfile": "SwordfishFabricAccessRights",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    },
    "SwordfishFabricAccessRights": {
      "Repository": "https://redfish.dmtf.org/profiles/swordfish",
      "MinVersion": "1.0.2",
      "ReadRequirement": "None",
      "ConditionalRequirements": [{
        "Purpose": "Either SwordfishFabricAccessRightsforEthernet or SwordfishFabricAccessRights must be supported.",
        "CompareProfile": "SwordfishFabricAccessRightsforEthernet",
        "CompareType": "Absent",
        "ReadRequirement": "Mandatory"
      }]
    }
  },

4.2 SwordfishBlockCapacityManagement profile

4.2.1 Summary Information

• Version: 1.2.0
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Block Capacity Management implementation requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.Block.CapacityManagement

4.2.2 Protocol Information

No protocol information defined in this profile.

4.2.3 Other Registry Information

4.2.4 Required profiles

The SwordfishBlockCapacityManagement profile depends upon the profiles listed in Table 6 .

Profile	Version	Conditions
SwordfishBlockProvisioning	1.3.0

Table 6: Required profiles for SwordfishBlockCapacityManagement

4.2.5 Related resources

The SwordfishBlockCapacityManagement profile relies on the resources listed in Table 7

Resource	Purpose
VolumeCollection
Volume	One of the following mechanisms is required to support reporting of volume capacity. In order to claim support of the Capacity Management Feature, correspondingly ‘write’ (expand) on that property must be supported.
CapacityBytes	Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.
Capacity
Data
AllocatedBytes	Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.

Table 7: Related resources for SwordfishBlockCapacityManagement

4.2.6 Resource Manipulation

The SwordfishBlockCapacityManagement profile requires the resource manipulations listed in Table 8

Resource	Read	Write	Create	Delete	Update
VolumeCollection	IfImp				T
Volume	M
CapacityBytes	R	M/C
Capacity	M
Data	M
AllocatedBytes	M	M/C

Table 8: Resource manipulations for SwordfishBlockCapacityManagement

4.2.7 Conditional Requirements

4.2.7.1 CapacityBytes

Purpose

Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.

Test Condition / Requirement

if /Capacity/Data/AllocatedBytes is Absent, WriteRequirement is Mandatory

based on:

• CompareProperty: /Capacity/Data/AllocatedBytes
• CompareType: Absent
• WriteRequirement: Mandatory

4.2.7.2 AllocatedBytes

Purpose

Either CapacityBytes or Capacity/#Data/#AllocatedBytes must be supported.

Test Condition / Requirement

if CapacityBytes is Absent, WriteRequirement is Mandatory

based on:

• CompareProperty: CapacityBytes
• CompareType: Absent
• WriteRequirement: Mandatory

4.3 SwordfishBlockCoSLocalReplication profile

4.3.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Define local replication block requirements for service-based Swordfish conformant implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.Block.CoSLocalReplication

4.3.2 Protocol Information

No protocol information defined in this profile.

4.3.3 Other Registry Information

4.3.4 Required profiles

The SwordfishBlockCoSLocalReplication profile depends upon the profiles listed in Table 9 .

Profile	Version	Conditions
SwordfishBlockProvisioning	1.3.0
SwordfishCoSDiscovery	1.2.0

Table 9: Required profiles for SwordfishBlockCoSLocalReplication

4.3.5 Related resources

The SwordfishBlockCoSLocalReplication profile relies on the resources listed in Table 10

Resource	Purpose
Volume
ReplicaTargets	At least one volume must exist defined as a replica target.
ReplicaInfo	At least one volume must exist defined as a replica.
ReplicaType	At least one volume must exist defined as a replica.
ReplicaFaultDomain	The ReplicaFaultDomain type must be set to Local. Must be set to [‘Local’]
StorageService
Links
DataProtectionLoSCapabilities	The Data Protection Line of Service must be supported. DataProtectionLoSCapabilities are a pre-requisite to the Line of Service.
DataProtectionLineOfServiceCollection	The Data Protection Line of Service must be supported.
Members	MinCount = 0
DataProtectionLineOfService
ACTIONS
CreateReplicas()	Ability to create an on-demand (ad-hoc) replica.

Table 10: Related resources for SwordfishBlockCoSLocalReplication

4.3.6 Resource Manipulation

The SwordfishBlockCoSLocalReplication profile requires the resource manipulations listed in Table 11

Resource	Read	Write	Create	Delete	Update
Volume	M
ReplicaTargets	M/C
ReplicaInfo	M/C
ReplicaType	M/C
ReplicaFaultDomain	M/C
StorageService	M
Links	M
DataProtectionLoSCapabilities	IfImp
DataProtectionLineOfServiceCollection	IfImp		T	T
Members	M
DataProtectionLineOfService	M
ACTIONS
CreateReplicas	M
ACTIONS
CreateReplicas	M

Table 11: Resource manipulations for SwordfishBlockCoSLocalReplication

4.3.7 Conditional Requirements

4.3.7.1 ReplicaTargets

Purpose

At least one volume must exist defined as a replica target.

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘StorageService’]
• ReadRequirement: Mandatory

4.3.7.2 ReplicaInfo

Purpose

At least one volume must exist defined as a replica.

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘StorageService’]
• ReadRequirement: Mandatory

4.3.7.3 ReplicaType

Purpose

At least one volume must exist defined as a replica.

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘StorageService’]
• ReadRequirement: Mandatory

4.3.7.4 ReplicaFaultDomain

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘StorageService’]
• ReadRequirement: Mandatory

4.3.7.5 DataProtectionLoSCapabilities

Purpose

The Data Protection Line of Service must be supported. DataProtectionLoSCapabilities are a pre-requisite to the Line of Service.

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘StorageService’]

4.4 SwordfishBlockLocalReplication profile

4.4.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Define local replication block requirements for Swordfish conformant implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.Block.LocalReplication

4.4.2 Protocol Information

No protocol information defined in this profile.

4.4.3 Other Registry Information

4.4.4 Required profiles

The SwordfishBlockLocalReplication profile depends upon the profiles listed in Table 12 .

Profile	Version	Conditions
SwordfishBlockProvisioning	1.3.0

Table 12: Required profiles for SwordfishBlockLocalReplication

4.4.5 Related resources

The SwordfishBlockLocalReplication profile relies on the resources listed in Table 13

Resource	Purpose
Volume
ACTIONS
AssignReplicaTarget()	Ability to reset the system is a core requirement of most users. Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support, when ReplicationEnabled is defined on the volume. Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise local replication support.
ReplicationEnabled	The ReplicationEnabled property shall be set on the volume to indicate that this volume is capable of supporting replication. When implemented and false, replication is supported and disabled. When implemented and true, replication is enabled. When replication is enabled, one of the two Actions, CreateReplicaTarget and AssignReplicaTarget, shall be implemented, regardless of whether the volume is currently in a replica relationship. At least one volume must have ReplicationEnabled to support Swordfish block local replication; ReplicaFaultDomain type must be set to local.
ReplicaTargets
ReplicaInfo
ReplicaType
ReplicaFaultDomain	The ReplicaFaultDomain type must be set to Local.

Table 13: Related resources for SwordfishBlockLocalReplication

4.4.6 Resource Manipulation

The SwordfishBlockLocalReplication profile requires the resource manipulations listed in Table 14

Resource	Read	Write	Create	Delete	Update
Volume	M
ACTIONS
CreateReplicaTarget	M/C
AssignReplicaTarget	M/C
ReplicationEnabled	M/C
ReplicaTargets	IfImp
ReplicaInfo	IfImp
ReplicaType	M
ReplicaFaultDomain	M

Table 14: Resource manipulations for SwordfishBlockLocalReplication

4.4.7 Conditional Requirements

4.4.7.1 ReplicationEnabled

Purpose

At least one volume must have ReplicationEnabled to support Swordfish block local replication; ReplicaFaultDomain type must be set to local.

Test Condition / Requirement

When subordinate to [‘Volume’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Volume’]
• ReadRequirement: Mandatory

4.5 SwordfishBlockMappingMasking profile

4.5.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Block Mapping and Masking Feature details.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.Block.MappingMasking

4.5.2 Protocol Information

No protocol information defined in this profile.

4.5.3 Other Registry Information

4.5.4 Required profiles

The SwordfishBlockMappingMasking profile depends upon the profiles listed in Table 15 .

Profile	Version	Conditions
CoSDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 15: Required profiles for SwordfishBlockMappingMasking

4.5.5 Related resources

The SwordfishBlockMappingMasking profile relies on the resources listed in Table 16

Resource	Purpose
ConnectionCollection
Members	MinCount = 1
EndpointCollection
Members	MinCount = 1
EndpointGroupCollection
Members	MinCount = 1
Connection
ConnectionType
VolumeInfo
AccessCapabilities
LUN
Volume
Links
InitiatorEndpointGroups
TargetEndpointGroups

Table 16: Related resources for SwordfishBlockMappingMasking

4.5.6 Resource Manipulation

The SwordfishBlockMappingMasking profile requires the resource manipulations listed in Table 17

Resource	Read	Write	Create	Delete	Update
ConnectionCollection	S		T	T	T
Members	M
EndpointCollection	IfImp		T	T	T
Members	M
EndpointGroupCollection	IfImp		T	T	T
Members	M
Connection	M
ConnectionType	M
VolumeInfo	M
AccessCapabilities	M
LUN	M
Volume	M
Links	M
InitiatorEndpointGroups	M
TargetEndpointGroups	M

Table 17: Resource manipulations for SwordfishBlockMappingMasking

4.5.7 Conditional Requirements

4.5.7.1 ConnectionCollection

Test Condition / Requirement

When subordinate to [‘Fabric’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’]

4.6 SwordfishBlockProvisioning profile

4.6.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Defines Block Provisioning requirements for Swordfish implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.Block.Provisioning

4.6.2 Protocol Information

No protocol information defined in this profile.

4.6.3 Other Registry Information

4.6.4 Required profiles

The SwordfishBlockProvisioning profile depends upon the profiles listed in Table 18 .

Profile	Version	Conditions
SwordfishCoSDiscovery	1.2.0	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 18: Required profiles for SwordfishBlockProvisioning

4.6.5 Related resources

The SwordfishBlockProvisioning profile relies on the resources listed in Table 19

Resource	Purpose
VolumeCollection

Table 19: Related resources for SwordfishBlockProvisioning

4.6.6 Resource Manipulation

The SwordfishBlockProvisioning profile requires the resource manipulations listed in Table 20

Resource	Read	Write	Create	Delete	Update
VolumeCollection	IfImp		T	T

Table 20: Resource manipulations for SwordfishBlockProvisioning

4.6.7 Conditional Requirements

4.6.7.1 VolumeCollection

Test Condition / Requirement

When subordinate to [‘Storage’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Storage’]

Test Condition / Requirement

When subordinate to [‘StoragePool’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘StoragePool’]

Test Condition / Requirement

When subordinate to [‘CapacitySource’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘CapacitySource’]

Test Condition / Requirement

When subordinate to [‘StorageService’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘StorageService’]

4.7 SwordfishBlockRemoteReplication profile

4.7.1 Summary Information

• Version: 1.2.1
• Contact Information: SNIA.org
• Purpose: Define remote replication block requirements for Swordfish conformant implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.Block.RemoteReplication

4.7.2 Protocol Information

No protocol information defined in this profile.

4.7.3 Other Registry Information

4.7.4 Required profiles

The SwordfishBlockRemoteReplication profile depends upon the profiles listed in Table 21 .

Profile	Version	Conditions
SwordfishBlockProvisioning	1.2.2

Table 21: Required profiles for SwordfishBlockRemoteReplication

4.7.5 Related resources

The SwordfishBlockRemoteReplication profile relies on the resources listed in Table 22

Resource	Purpose
Volume
ACTIONS
AssignReplicaTarget()	Ability to reset the system is a core requirement of most users. Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise remote replication support, when ReplicationEnabled is defined on the volume. Either CreateReplicaTarget or AssignReplicaTarget must be supported in order to advertise remote replication support.
ReplicationEnabled	The ReplicationEnabled property shall be set on the volume to indicate that this volume is capable of supporting replication. When implemented and false, replication is supported and disabled. When implemented and true, replication is enabled. When replication is enabled, one of the two Actions, CreateReplicaTarget and AssignReplicaTarget, shall be implemented, regardless of whether the volume is currently in a replica relationship. At least one volume must have ReplicationEnabled to support Swordfish block remote replication; ReplicaFaultDomain type must be set to Remote.
ReplicaTargets
ReplicaInfo
ReplicaType
ReplicaFaultDomain	The ReplicaFaultDomain type must be set to Remote.

Table 22: Related resources for SwordfishBlockRemoteReplication

4.7.6 Resource Manipulation

The SwordfishBlockRemoteReplication profile requires the resource manipulations listed in Table 23

Resource	Read	Write	Create	Delete	Update
Volume	M
ACTIONS
CreateReplicaTarget	M/C
AssignReplicaTarget	M/C
ReplicationEnabled	M/C
ReplicaTargets	IfImp
ReplicaInfo	IfImp
ReplicaType	M
ReplicaFaultDomain	M

Table 23: Resource manipulations for SwordfishBlockRemoteReplication

4.7.7 Conditional Requirements

4.7.7.1 ReplicationEnabled

Purpose

At least one volume must have ReplicationEnabled to support Swordfish block remote replication; ReplicaFaultDomain type must be set to Remote.

Test Condition / Requirement

When subordinate to [‘Volume’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Volume’]
• ReadRequirement: Mandatory

4.8 SwordfishCoSDiscovery profile

4.8.1 Summary Information

• Version: 1.2.0
• Contact Information: SNIA.org
• Purpose: Defines Class Of Service Discovery requirements for service-based Swordfish implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.CoSDiscovery

4.8.2 Protocol Information

• Protocol version: 1.18.0

4.8.3 Other Registry Information

4.8.4 Required profiles

4.8.5 Related resources

The SwordfishCoSDiscovery profile relies on the resources listed in Table 24

Resource	Purpose
StorageServiceCollection
Members	MinCount = 1
ServiceRoot
StorageServices
StorageService
Identifier
Status
State
Health
ClassesOfService
Volumes	Volumes must exist unless FileSystems exists, in which case it is only Recommended.
StoragePools
FileSystems	FileSystems must exist unless Volumes exists, in which case it is only Recommended.
Links
DefaultClassOfService	When there is at least one class of service instantiated, the DefaultClassOfService property should be set.
DataProtectionLoSCapabilities	One or more Line of Service Capabilities must be defined.
DataSecurityLoSCapabilities	One or more Line of Service Capabilities must be defined.
DataStorageLoSCapabilities	One or more Line of Service Capabilities must be defined.
IOConnectivityLoSCapabilities	One or more Line of Service Capabilities must be defined.
IOPerformanceLoSCapabilities	One or more Line of Service Capabilities must be defined.

Table 24: Related resources for SwordfishCoSDiscovery

4.8.6 Resource Manipulation

The SwordfishCoSDiscovery profile requires the resource manipulations listed in Table 25

Resource	Read	Write	Create	Delete	Update
StorageServiceCollection	M
Members	M
ServiceRoot	M
StorageServices	M
StorageService	M
Identifier	M
Status	M
State	M
Health	M
ClassesOfService	M
Volumes	M/C
StoragePools	M
FileSystems	M/C
Links	M
DefaultClassOfService	R
DataProtectionLoSCapabilities	M/C
DataSecurityLoSCapabilities	M/C
DataStorageLoSCapabilities	M/C
IOConnectivityLoSCapabilities	M/C
IOPerformanceLoSCapabilities	M/C

Table 25: Resource manipulations for SwordfishCoSDiscovery

4.8.7 Conditional Requirements

4.8.7.1 Volumes

Purpose

Volumes must exist unless FileSystems exists, in which case it is only Recommended.

Test Condition / Requirement

if FileSystems is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: FileSystems
• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.2 FileSystems

Purpose

FileSystems must exist unless Volumes exists, in which case it is only Recommended.

Test Condition / Requirement

if Volumes is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: Volumes
• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.3 DataProtectionLoSCapabilities

Purpose

One or more Line of Service Capabilities must be defined.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.4 DataSecurityLoSCapabilities

Purpose

One or more Line of Service Capabilities must be defined.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.5 DataStorageLoSCapabilities

Purpose

One or more Line of Service Capabilities must be defined.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.6 IOConnectivityLoSCapabilities

Purpose

One or more Line of Service Capabilities must be defined.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.8.7.7 IOPerformanceLoSCapabilities

Purpose

One or more Line of Service Capabilities must be defined.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.9 SwordfishDiscovery profile

4.9.1 Summary Information

• Version: 1.1.4
• Contact Information: SNIA.org
• Purpose: Define requirements for discovery of resources and relationships that are common to all Swordfish conformant implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.Discovery

summary supplement

4.9.2 Protocol Information

• Protocol version: 1.18.0

4.9.3 Other Registry Information

4.9.4 Required profiles

required profiles supplement

4.9.5 Related resources

related resources supplement

The SwordfishDiscovery profile relies on the resources listed in Table 26

Resource	Purpose
ServiceRoot
Chassis	If Drives are used as capacity sources, these must be in Chassis/{ChassisId}/Drives.
Storage
Systems	If Storage is attached to a ComputerSystem rather than instantiated as a Standalone instance.
StorageSystems	If Storage is attached to a ComputerSystem rather than instantiated as a Standalone instance.
StorageCollection
Members	MinCount = 1
VolumeCollection
Chassis
Drives	If Drives provide the capacity source for the related Storage object, Drives are required to be in at least one Chassis representation. As physical configurations can be represented by multiple Chassis instances, not all Chassis instances must include a Drives collection.
Storage
Volumes
StoragePools	StoragePools must be implemented in primary Storage object instances. For Storage objects modeling embedded or back-end devices (e.g., NVMe drives), StoragePools are not required to be modeled.
Drives	There are two requirements for Drives. The first is encapsulated in a custom test, as it cannot be well specified in the profile language. 1: The implementation must choose at least one selected media container (appropriate for the system’s selected media type) and instantiate a collection for it. This may be instantiated as a CapacitySources structure to feed a StoragePool, FileSystem, or Volume. When drives are used, the Drives Collection in either Storage or, when implementing the ClassOfService Feature, StorageServices shall be implemented. 2: When drives are used, the Drives Collection in Chassis shall be implemented.
ComputerSystem
HostingRoles	Swordfish implementations must specify a hosting role type of StorageServer. Must be set to [‘StorageServer’]

Table 26: Related resources for SwordfishDiscovery

4.9.6 Resource Manipulation

resource manipulation supplement

The SwordfishDiscovery profile requires the resource manipulations listed in Table 27

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Chassis	IfImp
Storage	M
Systems	IfImp
StorageSystems	IfImp
StorageCollection	M
Members	M
VolumeCollection	M
Chassis	M
Drives	IfImp/C
Storage	M
Volumes	M
StoragePools	IfImp
Drives	M/C
ComputerSystem	IfImp
HostingRoles	M

Table 27: Resource manipulations for SwordfishDiscovery

4.9.7 Conditional Requirements

conditional requirements supplement

4.9.7.1 Drives

Purpose

If Drives provide the capacity source for the related Storage object, Drives are required to be in at least one Chassis representation. As physical configurations can be represented by multiple Chassis instances, not all Chassis instances must include a Drives collection.

Test Condition / Requirement

When subordinate to [‘Chassis’], ReadRequirement is IfImplemented

based on:

• SubordinatetoResource [‘Chassis’]
• ReadRequirement: IfImplemented

4.9.7.2 Drives

Purpose

There are two requirements for Drives. The first is encapsulated in a custom test, as it cannot be well specified in the profile language. 1: The implementation must choose at least one selected media container (appropriate for the system’s selected media type) and instantiate a collection for it. This may be instantiated as a CapacitySources structure to feed a StoragePool, FileSystem, or Volume. When drives are used, the Drives Collection in either Storage or, when implementing the ClassOfService Feature, StorageServices shall be implemented. 2: When drives are used, the Drives Collection in Chassis shall be implemented.

Test Condition / Requirement

if /redfish/v1/Chassis/{ChassisId}/Drives is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: /redfish/v1/Chassis/{ChassisId}/Drives
• CompareType: Present
• ReadRequirement: Mandatory

4.10 SwordfishEnergyStar profile

4.10.1 Summary Information

• Version: 1.1.4
• Contact Information: SNIA.org
• Purpose: Defines Requirements for Swordfish to meet EnergyStar reporting for storage.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.EnergyStar

4.10.2 Protocol Information

No protocol information defined in this profile.

4.10.3 Other Registry Information

4.10.4 Required profiles

The SwordfishEnergyStar profile depends upon the profiles listed in Table 28 .

Profile	Version	Conditions
CoSDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 28: Required profiles for SwordfishEnergyStar

4.10.5 Related resources

The SwordfishEnergyStar profile relies on the resources listed in Table 29

Resource	Purpose
Chassis	To meet EnergyStar compliance, if the data is not reported or aggregated at the system level, it shall be reported for each shelf or enclosure. (Note that data can be aggregated external to the system by the client when reported by subcomponents.) These properties should be collected in the same request. The system shall be able to support client queries of these properties at an interval of at least every 10 seconds (per ENERGY STAR Data Center Storage Version 1.1 Updated Program Requirements – April 1, 2019).
Power
PowerSupply
PowerInputWatts
Thermal	Collect the inlet temperature for the power supply.
ReadingCelsius
PhysicalContext	Shall be equal to [‘Intake’]

Table 29: Related resources for SwordfishEnergyStar

4.10.6 Resource Manipulation

The SwordfishEnergyStar profile requires the resource manipulations listed in Table 30

Resource	Read	Write	Create	Delete	Update
Chassis	IfImp
Power	M
PowerSupply	M
PowerInputWatts	M
Thermal	M
ReadingCelsius	M
PhysicalContext	M

Table 30: Resource manipulations for SwordfishEnergyStar

4.10.7 Conditional Requirements

None defined.

4.11 SwordfishEventNotification profile

4.11.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Defines Swordfish Event Notification requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.7.0
• Supported Features
  • SNIA.Swordfish.EventNotification

4.11.2 Protocol Information

• Protocol version: 1.18.0

4.11.3 Other Registry Information

4.11.3.1 Registry Name:Base

Registry details:

• Minimum version: 1.4.0
• Messages
  • ResourceTypeIncompatible: The ResourceTypeIncompatible event shall be sent when the requested resource type of the operation does not match that for the operation. This shall apply to all instantiated resources.

4.11.3.2 Registry Name:ResourceEvent

Registry details:

• Minimum version: 1.2.0
• Messages
  • ResourceCreated: The ResourceCreated event shall be sent on creation of a resource to indicate that the resource has been successfully created. This shall apply to all instantiated resources of type ‘Collection’. The event shall be sent on any expansion of the collection, whether done by the user or by the system.
  • ResourceRemoved: The ResourceRemoved event shall be sent on removal (deletion) of a resource to indicate that the resource has been successfully removed. This applies to all resources of type ‘Collection’. The event shall be sent on any removal of resources from the collection, whether done by the user or by the system.
  • ResourceErrorsDetected: The ResourceRemoved event shall be sent on detection of errors on a resource. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceErrorsCorrected: The ResourceRemoved event shall be sent on detection of corrected errors on a resource. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceErrorThresholdExceeded: The ResourceRemoved event shall be sent when the threshold for detected errors has been exceeded. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceErrorThresholdCleared: The ResourceRemoved event shall be sent when the threshold for detected errors has been cleared. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceWarningThresholdExceeded: The ResourceRemoved event shall be sent when the warning threshold for a resource has been exceeded. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceWarningThresholdCleared: The ResourceRemoved event shall be sent on when the resources has cleared a warning threshold. As there are no standard schema properties that reflect error / threshold information in this release, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceStatusChangedOK: The ResourceStatusChangedOK event shall be sent when the Status.State has changed and the Status.Health of the resource is OK. The new and old values of the State are reported in the Event message. This shall apply to all instantiated resources that implements Status.State.
  • ResourceStatusChangedWarning: The ResourceStatusChangedWarning event shall be sent when the Status.State has changed and the Status.Health of the resource is Warning. The value of the State is reported in the Event message. This shall apply to all instantiated resources that implements Status.State.
  • ResourceStatusChangedCritical: The ResourceStatusChangedCritical event shall be sent when the Status.State has changed and the Status.Health of the resource is Critical. The value of the State is reported in the Event message. This shall apply to all instantiated resources that implements Status.State.
  • URIForResourceChanged: The URIForResourceChanged event shall be sent when the URI for the model resource has changed. Examples for this would be physical component replacement or redistribution.
  • ResourceChanged: The ResourceChanged event shall be sent when one or more properties of a resource have changed. This shall not be used whenever there is another event message for that specific change, such as only the state has changed. If multiple resource properties have changed, the event notification should be grouped together whenever possible. This should not be sent for changes related to fine-grained volatile values (eg., capacity, power, temperature). In the case of threshold crossings, other mechanisms should be employed, such as logging or threshold triggers.
  • ResourceVersionIncompatible: The ResourceVersionIncompatible event shall be sent when an incompatible version of software has been detected. This corresponds to schema that have a ‘Version’ or ‘Revision’ property, generally presenting either firmware or software version information. As there are no schema properties that specifically reflect compatibility, this may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceSelfTestFailed: The ResourceSelfTestFailed event shall be sent when a self-test has failed. As there are no schema properties that reflect self-test controls, these may be mapped to OEM properties or device-specific events, until standard properties are defined.
  • ResourceSelfTestCompleted: The ResourceSelfTestCompleted event shall be sent when a self-test has completed. As there are no schema properties that reflect self-test controls, these may be mapped to OEM properties or device-specific events, until standard properties are defined.

4.11.4 Required profiles

The SwordfishEventNotification profile depends upon the profiles listed in Table 31 .

Profile	Version	Conditions
CoSDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 31: Required profiles for SwordfishEventNotification

4.11.5 Related resources

The SwordfishEventNotification profile relies on the resources listed in Table 32

Resource	Purpose
EventService

Table 32: Related resources for SwordfishEventNotification

4.11.6 Resource Manipulation

The SwordfishEventNotification profile requires the resource manipulations listed in Table 33

Resource	Read	Write	Create	Delete	Update
EventService	M

Table 33: Resource manipulations for SwordfishEventNotification

4.11.7 Conditional Requirements

None defined.

4.12 SwordfishFabricAccessRights profile

4.12.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Access Rights implementation requirements using Fabrics.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.FabricAccessRights

4.12.2 Protocol Information

• Protocol version: 1.18.0

4.12.3 Other Registry Information

4.12.4 Required profiles

The SwordfishFabricAccessRights profile depends upon the profiles listed in Table 34 .

Profile	Version	Conditions
SwordfishDiscovery	1.1.4

Table 34: Required profiles for SwordfishFabricAccessRights

4.12.5 Related resources

The SwordfishFabricAccessRights profile relies on the resources listed in Table 35

Resource	Purpose
ServiceRoot
Fabrics
FabricCollection
Members	MinCount = 1
ConnectionCollection
EndpointCollection
Fabric
Connections	Required when Switches not defined for the fabric (switches are required for connectivity rights management).
Description
EndpointGroups
Endpoints
FabricType
Id
Name
Status
State
Connection
ConnectionType
Description
Id
Links
InitiatorEndpointGroups	Either InitiatorEndpointGroups or InitiatorEndpoints must be supported.
InitiatorEndpoints	Either InitiatorEndpoints or InitiatorEndpointGroups must be supported.
TargetEndpointGroups	Either TargetEndpointGroups or TargetEndpoints must be supported.
TargetEndpoints	Either TargetEndpoints or TargetEndpointGroups must be supported.
Name
VolumeInfo
AccessCapabilities
Volume
LUN	Dependent on protocol. Required for SCSI, FC connect.
Endpoint
ConnectedEntities
EntityLink
EntityRole
EntityType
EndpointProtocol
Identifiers
DurableName
DurableNameFormat
Links
Connections
EndpointGroup
AccessState	This property is recommended as ‘Do not implement’. This property has been deprecated.
Endpoints	This property is recommended as ‘Do not implement’. This property has been deprecated.
GroupType
Id
Links
Endpoints
Connections
Preferred	This property is recommended as ‘Do not implement’. This property has been deprecated.

Table 35: Related resources for SwordfishFabricAccessRights

4.12.6 Resource Manipulation

The SwordfishFabricAccessRights profile requires the resource manipulations listed in Table 36

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Fabrics	M
FabricCollection	M
Members	M
ConnectionCollection	M
EndpointCollection	M
Fabric	M
Connections	M/C
Description	M
EndpointGroups	R
Endpoints	M
FabricType	M
Id	M
Name	M
Status	M
State	M
Connection	M
ConnectionType	M
Description	M
Id	M
Links	M
InitiatorEndpointGroups	M/C
InitiatorEndpoints	M/C
TargetEndpointGroups	M/C
TargetEndpoints	M/C
Name	M
VolumeInfo	M
AccessCapabilities	M
Volume	M
LUN	R
Endpoint	M
ConnectedEntities	M
EntityLink	R
EntityRole	M
EntityType	M
EndpointProtocol	M
Identifiers	M
DurableName	M
DurableNameFormat	M
Links	M
Connections	R
EndpointGroup	R
AccessState	DNI
Endpoints	DNI
GroupType	M
Id	M
Links	M
Endpoints	M
Connections	M
Preferred	DNI

Table 36: Resource manipulations for SwordfishFabricAccessRights

4.12.7 Conditional Requirements

4.12.7.1 Connections

Purpose

Required when Switches not defined for the fabric (switches are required for connectivity rights management).

Test Condition / Requirement

if Switches is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: Switches
• CompareType: Absent
• ReadRequirement: Mandatory

4.12.7.2 InitiatorEndpointGroups

Purpose

Either InitiatorEndpointGroups or InitiatorEndpoints must be supported.

Test Condition / Requirement

if InitiatorEndpoints is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: InitiatorEndpoints
• CompareType: Absent
• ReadRequirement: Mandatory

4.12.7.3 InitiatorEndpoints

Purpose

Either InitiatorEndpoints or InitiatorEndpointGroups must be supported.

Test Condition / Requirement

if InitiatorEndpointGroups is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: InitiatorEndpointGroups
• CompareType: Absent
• ReadRequirement: Mandatory

4.12.7.4 TargetEndpointGroups

Purpose

Either TargetEndpointGroups or TargetEndpoints must be supported.

Test Condition / Requirement

if TargetEndpoints is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: TargetEndpoints
• CompareType: Absent
• ReadRequirement: Mandatory

4.12.7.5 TargetEndpoints

Purpose

Either TargetEndpoints or TargetEndpointGroups must be supported.

Test Condition / Requirement

if TargetEndpointGroups is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: TargetEndpointGroups
• CompareType: Absent
• ReadRequirement: Mandatory

4.13 SwordfishFabricAccessRightsforEthernet profile

4.13.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Access Rights requirements using Fabrics, for implementations using Ethernet.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.FabricAccessRightsforEthernet

4.13.2 Protocol Information

• Protocol version: 1.18.0

4.13.3 Other Registry Information

4.13.4 Required profiles

The SwordfishFabricAccessRightsforEthernet profile depends upon the profiles listed in Table 37 .

Profile	Version	Conditions
SwordfishFabricAccessRights	1.0.2

Table 37: Required profiles for SwordfishFabricAccessRightsforEthernet

4.13.5 Related resources

The SwordfishFabricAccessRightsforEthernet profile relies on the resources listed in Table 38

Resource	Purpose
Endpoint
IPTransportDetails
TransportProtocol
IPv4Address	Either IPv4Address or IPv6Address must be supported.
IPv6Address	Either IPv4Address or IPv6Address must be supported.
Port

Table 38: Related resources for SwordfishFabricAccessRightsforEthernet

4.13.6 Resource Manipulation

The SwordfishFabricAccessRightsforEthernet profile requires the resource manipulations listed in Table 39

Resource	Read	Write	Create	Delete	Update
Endpoint	M/C
IPTransportDetails	M
TransportProtocol	M
IPv4Address	M/C
IPv6Address	M/C
Port	M

Table 39: Resource manipulations for SwordfishFabricAccessRightsforEthernet

4.13.7 Conditional Requirements

4.13.7.1 Endpoint

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘EndpointCollection’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘EndpointCollection’]
• ReadRequirement: Mandatory

4.13.7.2 IPv4Address

Purpose

Either IPv4Address or IPv6Address must be supported.

Test Condition / Requirement

if IPv6Address is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Address
• CompareType: Absent
• ReadRequirement: Mandatory

4.13.7.3 IPv6Address

Purpose

Either IPv4Address or IPv6Address must be supported.

Test Condition / Requirement

if IPv4Address is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv4Address
• CompareType: Absent
• ReadRequirement: Mandatory

4.14 SwordfishFabricConnectivityRights profile

4.14.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Connectivity Rights implementation requirements using Fabrics.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.FabricConnectivityRights

4.14.2 Protocol Information

• Protocol version: 1.18.0

4.14.3 Other Registry Information

4.14.4 Required profiles

The SwordfishFabricConnectivityRights profile depends upon the profiles listed in Table 40 .

Profile	Version	Conditions
SwordfishDiscovery	1.1.4

Table 40: Required profiles for SwordfishFabricConnectivityRights

4.14.5 Related resources

The SwordfishFabricConnectivityRights profile relies on the resources listed in Table 41

Resource	Purpose
ServiceRoot
Fabrics
FabricCollection
Members	MinCount = 1
SwitchCollection
ZoneCollection
EndpointCollection
Fabric
Description
EndpointGroups
Endpoints
FabricType
Id
Name
MaxZones
Status
Conditions	Reports Conditions when HealthRollup is not ‘OK’.
HealthRollup
Health
State
Switches	Required when Connections not defined for the fabric (connections are required only for access rights management).
Zones	Required when Connections not defined for the fabric (connections are required only for access rights management).
Endpoint
ConnectedEntities
EntityLink
EntityRole
EntityType
EndpointProtocol
Identifiers
DurableName
DurableNameFormat
Links
Ports
Zones
EndpointGroup
GroupType
Id
Links
Endpoints
Connections
Port
CurrentSpeedGbps
Id
Links
AssociatedEndpoints
MaxSpeedGbps
Name
PortId
PortProtocol
Status
State
Switch
Description
FirmwareVersion
Id
IndicatorLED	Do not implement IndicatorLED
IsManaged
Links
Chassis
Location
Manufacturer
Model
Name
PartNumber
Ports
SerialNumber
SupportedProtocols
SwitchType
Zone
Description
ExternalAccessibility
Id
Links
Endpoints
InvolvedSwitches
Name
Status
State
ZoneType

Table 41: Related resources for SwordfishFabricConnectivityRights

4.14.6 Resource Manipulation

The SwordfishFabricConnectivityRights profile requires the resource manipulations listed in Table 42

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Fabrics	M
FabricCollection	M
Members	M
SwitchCollection	M
ZoneCollection	M
EndpointCollection	M
Fabric	M
Description	M
EndpointGroups	R
Endpoints	M
FabricType	M
Id	M
Name	M
MaxZones	R
Status	M
Conditions	M/C
HealthRollup	R
Health	M
State	M
Switches	M/C
Zones	M/C
Endpoint	M
ConnectedEntities	M
EntityLink	R
EntityRole	M
EntityType	M
EndpointProtocol	M
Identifiers	M
DurableName	M
DurableNameFormat	M
Links	M
Ports	R
Zones	R
EndpointGroup	IfImp
GroupType	M
Id	M
Links	M
Endpoints	M
Connections	M
Port	M
CurrentSpeedGbps	M
Id	M
Links	M
AssociatedEndpoints	M
MaxSpeedGbps	M
Name	M
PortId	M
PortProtocol	M
Status	M
State	M
Switch	M
Description	M
FirmwareVersion	M
Id	M
IndicatorLED	DNI
IsManaged	M
Links	M
Chassis	M
Location	R
Manufacturer	M
Model	M
Name	M
PartNumber	M
Ports	M
SerialNumber	M
SupportedProtocols	M
SwitchType	M
Zone	M
Description	M
ExternalAccessibility	M
Id	M
Links	M
Endpoints	M
InvolvedSwitches	R
Name	M
Status	M
State	M
ZoneType	M

Table 42: Resource manipulations for SwordfishFabricConnectivityRights

4.14.7 Conditional Requirements

4.14.7.1 Conditions

Purpose

Reports Conditions when HealthRollup is not ‘OK’.

Test Condition / Requirement

if HealthRollup is AnyOf to [‘Warning’, ‘Critical’], ReadRequirement is Mandatory

based on:

• CompareProperty: HealthRollup
• CompareType: AnyOf
• CompareValues: [‘Warning’, ‘Critical’]
• ReadRequirement: Mandatory

4.14.7.2 Switches

Purpose

Required when Connections not defined for the fabric (connections are required only for access rights management).

Test Condition / Requirement

if Connections is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: Connections
• CompareType: Absent
• ReadRequirement: Mandatory

4.14.7.3 Zones

Purpose

Required when Connections not defined for the fabric (connections are required only for access rights management).

Test Condition / Requirement

if Connections is Absent, ReadRequirement is Mandatory

based on:

• CompareProperty: Connections
• CompareType: Absent
• ReadRequirement: Mandatory

4.14.7.4 Endpoint

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘EndpointCollection’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘EndpointCollection’]

4.14.7.5 EndpointGroup

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘EndpointGroupCollection’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘EndpointGroupCollection’]

4.14.7.6 Port

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]

4.14.7.7 Switch

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’]

4.15 SwordfishFabricConnectivityRightsforEthernet profile

4.15.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Connectivity Rights requirements using Fabrics, for implementations using Ethernet.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.FabricConnectivityRightsforEthernet

4.15.2 Protocol Information

• Protocol version: 1.18.0

4.15.3 Other Registry Information

4.15.4 Required profiles

The SwordfishFabricConnectivityRightsforEthernet profile depends upon the profiles listed in Table 43 .

Profile	Version	Conditions
SwordfishFabricConnectivityRights	1.0.2

Table 43: Required profiles for SwordfishFabricConnectivityRightsforEthernet

4.15.5 Related resources

The SwordfishFabricConnectivityRightsforEthernet profile relies on the resources listed in Table 44

Resource	Purpose
ServiceRoot
Chassis
Chassis
NetworkAdapters
ChassisCollection
Endpoint
IPTransportDetails
TransportProtocol	TransportProtocol must exist and be set to ‘Ethernet’ Shall be equal to [‘Ethernet’]
Port
EthernetInterface
DHCPv4
DHCPv6
Description
FQDN
HostName
IPv4Addresses
IPv4StaticAddresses
IPv6Addresses
IPv6DefaultGateway	If IPv6Addresses is implemented, then IPv6DefaultGateway is required.
IPv6StaticAddresses	If IPv6Addresses is implemented, then IPv6StaticAddresses is required.
IPv6StaticDefaultGateways	If IPv6Addresses is implemented, then IPv6StaticDefaultGateways is required.
Id
LinkStatus
Links
Chassis
MACAddress
Name
PermanentMACAddress
StatelessAddressAutoConfig
Status
Health
State
EthernetInterfaceCollection
NetworkAdapter
Controllers
ControllerCapabilities
NetworkDeviceFunctionCount
NetworkPortCount
Links
Ports
Description
Id
Manufacturer
Measurements	Deprecated, do not implement.
Model
Name
NetworkDeviceFunctions
NetworkPorts	Deprecated, do not implement.
PartNumber
Ports
SKU
SerialNumber
NetworkAdapterCollection
NetworkDeviceFunction
AssignablePhysicalNetworkPorts
BootMode
DeviceEnabled
Ethernet
EthernetInterfaces
MACAddress
MTUSize
MUTSizeMaximum
PermanentMACAddress
Id
Links
PhysicalNetworkPortAssignment
MaxVirtualFunctions
NetDevFuncCapabilities
VirtualFunctionsEnabled
NetworkDeviceFunctionCollection
Port	The Port object is used by both NetworkAdapter and Switch. Requirements for both are represented in this set of property requirements.
CurrentSpeedGbps
Ethernet
AssociatedMACAddresses	Optional for NetworkAdapter ports, Required for Switch ports.
EEEEnabled	Required for NetworkAdapter ports, optional for Switch ports.
FlowControlConfiguration	Required for NetworkAdapter ports, recommended for Switch ports.
FlowControlStatus	Required for NetworkAdapter ports, recommended for Switch ports.
SupportedEthernetCapabilities	Deprecated. Do not implement.
WakeOnLANEnabled	Required for NetworkAdapter ports, Optional for Switch ports.
Id
InterfaceEnabled
LinkConfiguration
AutoSpeedNegotiationCapable
AutoSpeedNegotiationEnabled
CapableLinkSpeedGbps
ConfiguredNetworkLinks
LinkNetworkTechnology
LinkState
LinkStatus
Links
AssociatedEndpoints
LocationIndicatorActive
MaxFrameSize
MaxSpeedGbps
Name
PortId
PortProtocol	PortProtocol must exist and be set to ‘Ethernet’ Shall be equal to [‘Ethernet’]
SFP
Status
State
Type
Width
PortCollection
Switch
DomainID

Table 44: Related resources for SwordfishFabricConnectivityRightsforEthernet

4.15.6 Resource Manipulation

The SwordfishFabricConnectivityRightsforEthernet profile requires the resource manipulations listed in Table 45

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Chassis	M
Chassis	M
NetworkAdapters	M
ChassisCollection	M
Endpoint	M/C
IPTransportDetails	M
TransportProtocol	M
Port	R
EthernetInterface	M/C
DHCPv4	R
DHCPv6	R
Description	M
FQDN	M
HostName	M
IPv4Addresses	M
IPv4StaticAddresses	M
IPv6Addresses	R
IPv6DefaultGateway	M/C
IPv6StaticAddresses	M/C
IPv6StaticDefaultGateways	M/C
Id	M
LinkStatus	M
Links	M
Chassis	M
MACAddress	M
Name	M
PermanentMACAddress	R
StatelessAddressAutoConfig	R
Status	M
Health	M
State	M
EthernetInterfaceCollection	M
NetworkAdapter	M
Controllers	M
ControllerCapabilities	M
NetworkDeviceFunctionCount	M
NetworkPortCount	M
Links	M
Ports	R
Description	M
Id	M
Manufacturer	M
Measurements	DNI
Model	M
Name	M
NetworkDeviceFunctions	M
NetworkPorts	DNI
PartNumber	M
Ports	M
SKU	R
SerialNumber	M
NetworkAdapterCollection	M
NetworkDeviceFunction	M
AssignablePhysicalNetworkPorts	M
BootMode	M
DeviceEnabled	M
Ethernet	M
EthernetInterfaces	M
MACAddress	M
MTUSize	M
MUTSizeMaximum	R
PermanentMACAddress	M
Id	M
Links	M
PhysicalNetworkPortAssignment	M
MaxVirtualFunctions	M
NetDevFuncCapabilities	M
VirtualFunctionsEnabled	M
NetworkDeviceFunctionCollection	M
Port	M
CurrentSpeedGbps	M
Ethernet	M
AssociatedMACAddresses	R/C
EEEEnabled	R/C
FlowControlConfiguration	R/C
FlowControlStatus	R/C
SupportedEthernetCapabilities	DNI
WakeOnLANEnabled	???
Id	M
InterfaceEnabled	M
LinkConfiguration	M
AutoSpeedNegotiationCapable	M
AutoSpeedNegotiationEnabled	M
CapableLinkSpeedGbps	M
ConfiguredNetworkLinks	M
LinkNetworkTechnology	M
LinkState	M
LinkStatus	M
Links	M
AssociatedEndpoints	M
LocationIndicatorActive	R
MaxFrameSize	R
MaxSpeedGbps	M
Name	M
PortId	M
PortProtocol	M
SFP	IfImp
Status	M
State	M
Type	M
Width	M
PortCollection	M
Switch	M
DomainID	M

Table 45: Resource manipulations for SwordfishFabricConnectivityRightsforEthernet

4.15.7 Conditional Requirements

4.15.7.1 Endpoint

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘EndpointCollection’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘EndpointCollection’]
• ReadRequirement: Mandatory

4.15.7.2 EthernetInterface

Test Condition / Requirement

When subordinate to [‘Manager’, ‘EthernetInterfaceCollection’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Manager’, ‘EthernetInterfaceCollection’]
• ReadRequirement: Mandatory

4.15.7.3 IPv6DefaultGateway

Purpose

If IPv6Addresses is implemented, then IPv6DefaultGateway is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.15.7.4 IPv6StaticAddresses

Purpose

If IPv6Addresses is implemented, then IPv6StaticAddresses is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.15.7.5 IPv6StaticDefaultGateways

Purpose

If IPv6Addresses is implemented, then IPv6StaticDefaultGateways is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.15.7.6 Port

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]

4.15.7.7 AssociatedMACAddresses

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is None

based on:

• SubordinatetoResource [‘NetworkAdapter’]
• ReadRequirement: None

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is Recommended

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]
• ReadRequirement: Recommended

4.15.7.8 EEEEnabled

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]
• ReadRequirement: Mandatory

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is Recommended

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]
• ReadRequirement: Recommended

4.15.7.9 FlowControlConfiguration

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]
• ReadRequirement: Mandatory

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is Recommended

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]
• ReadRequirement: Recommended

4.15.7.10 FlowControlStatus

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]
• ReadRequirement: Mandatory

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is Recommended

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]
• ReadRequirement: Recommended

4.15.7.11 WakeOnLANEnabled

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]
• ReadRequirement: Mandatory

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is None

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]
• ReadRequirement: None

4.16 SwordfishFabricConnectivityRightsforRDMA profile

4.16.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Connectivity Rights requirements using Fabrics, for implementations using RDMA.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.FabricConnectivityRightsforRDMA

4.16.2 Protocol Information

• Protocol version: 1.18.0

4.16.3 Other Registry Information

4.16.4 Required profiles

The SwordfishFabricConnectivityRightsforRDMA profile depends upon the profiles listed in Table 46 .

Profile	Version	Conditions
SwordfishFabricConnectivityRights	1.0.2

Table 46: Required profiles for SwordfishFabricConnectivityRightsforRDMA

4.16.5 Related resources

The SwordfishFabricConnectivityRightsforRDMA profile relies on the resources listed in Table 47

Resource	Purpose
ServiceRoot
Chassis
Chassis
NetworkAdapters
ChassisCollection
Endpoint
IPTransportDetails
TransportProtocol	TransportProtocol must exist and be set to ‘InfiniBand’ Shall be equal to [‘InfiniBand’]
Port
NetworkAdapter
Controllers
ControllerCapabilities
NetworkDeviceFunctionCount
NetworkPortCount
Description
Id
Manufacturer
Measurements	Deprecated, do not implement.
Model
Name
NetworkDeviceFunctions
NetworkPorts	Deprecated, do not implement.
PartNumber
Ports
SKU
SerialNumber
NetworkAdapterCollection
NetworkDeviceFunction
AssignablePhysicalNetworkPorts
AssignableNetworkPorts	Deprecated, do not implement.
DeviceEnabled
Id
InfiniBand
MTUSize
NodeGUID
PermanentNodeGUID
PermanentPortGUID
PermanentSystemGUID
PortGUID
SupportedMTUSizes
SystemGUID
Links
PhysicalNetworkPortAssignment
MaxVirtualFunctions
NetDevFuncCapabilities
VirtualFunctionsEnabled
NetworkDeviceFunctionCollection
Port	The Port object is used by both NetworkAdapter and Switch. Requirements for both are represented in this set of property requirements.
CurrentSpeedGbps
Id
InterfaceEnabled
LinkConfiguration
AutoSpeedNegotiationCapable
AutoSpeedNegotiationEnabled
CapableLinkSpeedGbps
ConfiguredNetworkLinks
LinkNetworkTechnology
LinkState
LinkStatus
Links
AssociatedEndpoints
LocationIndicatorActive
MaxFrameSize
MaxSpeedGbps
Name
PortId
PortProtocol	PortProtocol must exist and be set to ‘InfiniBand’ Shall be equal to [‘InfiniBand’]
SFP
Status
State
Type
Width
PortCollection
Switch
DomainID

Table 47: Related resources for SwordfishFabricConnectivityRightsforRDMA

4.16.6 Resource Manipulation

The SwordfishFabricConnectivityRightsforRDMA profile requires the resource manipulations listed in Table 48

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Chassis	M
Chassis	M
NetworkAdapters	M
ChassisCollection	M
Endpoint	M/C
IPTransportDetails	M
TransportProtocol	M
Port	R
NetworkAdapter	M
Controllers	M
ControllerCapabilities	M
NetworkDeviceFunctionCount	M
NetworkPortCount	M
Description	M
Id	M
Manufacturer	M
Measurements	DNI
Model	M
Name	M
NetworkDeviceFunctions	M
NetworkPorts	DNI
PartNumber	M
Ports	M
SKU	R
SerialNumber	M
NetworkAdapterCollection	M
NetworkDeviceFunction	M
AssignablePhysicalNetworkPorts	M
AssignableNetworkPorts	DNI
DeviceEnabled	M
Id	M
InfiniBand	M
MTUSize	M
NodeGUID	M
PermanentNodeGUID	M
PermanentPortGUID	M
PermanentSystemGUID	M
PortGUID	M
SupportedMTUSizes	R
SystemGUID	M
Links	M
PhysicalNetworkPortAssignment	M
MaxVirtualFunctions	M
NetDevFuncCapabilities	M
VirtualFunctionsEnabled	M
NetworkDeviceFunctionCollection	M
Port	M
CurrentSpeedGbps	M
Id	M
InterfaceEnabled	M
LinkConfiguration	M
AutoSpeedNegotiationCapable	M
AutoSpeedNegotiationEnabled	M
CapableLinkSpeedGbps	M
ConfiguredNetworkLinks	M
LinkNetworkTechnology	M
LinkState	M
LinkStatus	M
Links	M
AssociatedEndpoints	M
LocationIndicatorActive	R
MaxFrameSize	R
MaxSpeedGbps	M
Name	M
PortId	M
PortProtocol	M
SFP	IfImp
Status	M
State	M
Type	M
Width	M
PortCollection	M
Switch	M
DomainID	M

Table 48: Resource manipulations for SwordfishFabricConnectivityRightsforRDMA

4.16.7 Conditional Requirements

4.16.7.1 Endpoint

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘EndpointCollection’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘EndpointCollection’]
• ReadRequirement: Mandatory

4.16.7.2 Port

Test Condition / Requirement

When subordinate to [‘NetworkAdapter’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘NetworkAdapter’]

Test Condition / Requirement

When subordinate to [‘Fabric’, ‘SwitchCollection’, ‘Switch’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Fabric’, ‘SwitchCollection’, ‘Switch’]

4.17 SwordfishFileCapacityManagement profile

4.17.1 Summary Information

• Version: 1.1.4
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish File Capacity Management requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.File.CapacityManagement

4.17.2 Protocol Information

No protocol information defined in this profile.

4.17.3 Other Registry Information

4.17.4 Required profiles

The SwordfishFileCapacityManagement profile depends upon the profiles listed in Table 49 .

Profile	Version	Conditions
SwordfishFileProvisioning	1.1.4

Table 49: Required profiles for SwordfishFileCapacityManagement

4.17.5 Related resources

The SwordfishFileCapacityManagement profile relies on the resources listed in Table 50

Resource	Purpose
FileSystemCollection
FileSystem
Capacity

Table 50: Related resources for SwordfishFileCapacityManagement

4.17.6 Resource Manipulation

The SwordfishFileCapacityManagement profile requires the resource manipulations listed in Table 51

Resource	Read	Write	Create	Delete	Update
FileSystemCollection	IfImp				T
FileSystem	M
Capacity	M	M

Table 51: Resource manipulations for SwordfishFileCapacityManagement

4.17.7 Conditional Requirements

None defined.

4.18 SwordfishFileProvisioning profile

4.18.1 Summary Information

• Version: 1.1.4
• Contact Information: SNIA.org
• Purpose: Defines File Provisioning requirements for service-based Swordfish implementations.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.File.Provisioning

4.18.2 Protocol Information

No protocol information defined in this profile.

4.18.3 Other Registry Information

4.18.4 Required profiles

The SwordfishFileProvisioning profile depends upon the profiles listed in Table 52 .

Profile	Version	Conditions
CoSDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 52: Required profiles for SwordfishFileProvisioning

4.18.5 Related resources

The SwordfishFileProvisioning profile relies on the resources listed in Table 53

Resource	Purpose
FileSystemCollection
Members	MinCount = 0
Filesystem
ExportedShares
ImportedShares	Require the Imported Shares structure to be complete and Create / Delete if implemented.
ImportedShare
FileSharePath

Table 53: Related resources for SwordfishFileProvisioning

4.18.6 Resource Manipulation

The SwordfishFileProvisioning profile requires the resource manipulations listed in Table 54

Resource	Read	Write	Create	Delete	Update
FileSystemCollection	M		T	T
Members	M
Filesystem	IfImp
ExportedShares	IfImp	M
ImportedShares	IfImp	M
ImportedShare	M
FileSharePath	M

Table 54: Resource manipulations for SwordfishFileProvisioning

4.18.7 Conditional Requirements

4.18.7.1 FileSystemCollection

Test Condition / Requirement

When subordinate to [‘Storage’, ‘StorageService’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Storage’, ‘StorageService’]

4.19 SwordfishIOPerformance profile

4.19.1 Summary Information

• Version: 1.2.0
• Contact Information: SNIA.org
• Purpose: Defines Swordfish IO Performance requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.IOPerformance

4.19.2 Protocol Information

No protocol information defined in this profile.

4.19.3 Other Registry Information

4.19.4 Required profiles

The SwordfishIOPerformance profile depends upon the profiles listed in Table 55 .

Profile	Version	Conditions
CoSDiscovery	1.2.0	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 55: Required profiles for SwordfishIOPerformance

4.19.5 Related resources

The SwordfishIOPerformance profile relies on the resources listed in Table 56

Resource	Purpose
Volume
Metrics
StoragePool
Metrics
FileSystem
Metrics
StorageService
Metrics
VolumeMetrics
IOStatistics
WriteIORequestTime
WriteIORequests
WriteIOKiBytes
WriteHitIORequests
ReadIORequestTime
ReadIORequests
ReadIOKiBytes
ReadHitIORequests
NonIORequestTime
NonIORequests
StoragePoolMetrics
IOStatistics
WriteIORequestTime
WriteIORequests
WriteIOKiBytes
WriteHitIORequests
ReadIORequestTime
ReadIORequests
ReadIOKiBytes
ReadHitIORequests
NonIORequestTime
NonIORequests
StorageServiceMetrics
IOStatistics
WriteIORequestTime
WriteIORequests
WriteIOKiBytes
WriteHitIORequests
ReadIORequestTime
ReadIORequests
ReadIOKiBytes
ReadHitIORequests
NonIORequestTime
NonIORequests
FileSystemMetrics
IOStatistics
WriteIORequestTime
WriteIORequests
WriteIOKiBytes
WriteHitIORequests
ReadIORequestTime
ReadIORequests
ReadIOKiBytes
ReadHitIORequests
NonIORequestTime
NonIORequests

Table 56: Related resources for SwordfishIOPerformance

4.19.6 Resource Manipulation

The SwordfishIOPerformance profile requires the resource manipulations listed in Table 57

Resource	Read	Write	Create	Delete	Update
Volume	IfImp
Metrics	M
StoragePool	IfImp
Metrics	M
FileSystem	IfImp
Metrics	M
StorageService	IfImp
Metrics	M
VolumeMetrics	IfImp
IOStatistics	M
WriteIORequestTime	M
WriteIORequests	M
WriteIOKiBytes	M
WriteHitIORequests	M
ReadIORequestTime	M
ReadIORequests	M
ReadIOKiBytes	M
ReadHitIORequests	M
NonIORequestTime	M
NonIORequests	M
StoragePoolMetrics	IfImp
IOStatistics	M
WriteIORequestTime	M
WriteIORequests	M
WriteIOKiBytes	M
WriteHitIORequests	M
ReadIORequestTime	M
ReadIORequests	M
ReadIOKiBytes	M
ReadHitIORequests	M
NonIORequestTime	M
NonIORequests	M
StorageServiceMetrics	IfImp
IOStatistics	M
WriteIORequestTime	M
WriteIORequests	M
WriteIOKiBytes	M
WriteHitIORequests	M
ReadIORequestTime	M
ReadIORequests	M
ReadIOKiBytes	M
ReadHitIORequests	M
NonIORequestTime	M
NonIORequests	M
FileSystemMetrics	IfImp
IOStatistics	M
WriteIORequestTime	M
WriteIORequests	M
WriteIOKiBytes	M
WriteHitIORequests	M
ReadIORequestTime	M
ReadIORequests	M
ReadIOKiBytes	M
ReadHitIORequests	M
NonIORequestTime	M
NonIORequests	M

Table 57: Resource manipulations for SwordfishIOPerformance

4.19.7 Conditional Requirements

None defined.

4.20 SwordfishManagementController profile

4.20.1 Summary Information

• Version: 1.0.2
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish Management Controller requirements for configurations such as embedded management controllers.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.ManagementController

4.20.2 Protocol Information

• Protocol version: 1.18.0

4.20.3 Other Registry Information

4.20.4 Required profiles

4.20.5 Related resources

The SwordfishManagementController profile relies on the resources listed in Table 58

Resource	Purpose
ServiceRoot
Managers
EthernetInterface
DHCPv4
DHCPv6
Description
FQDN
HostName
IPv4Addresses
IPv4StaticAddresses
IPv6Addresses
IPv6DefaultGateway	If IPv6Addresses is implemented, then IPv6DefaultGateway is required.
IPv6StaticAddresses	If IPv6Addresses is implemented, then IPv6StaticAddresses is required.
IPv6StaticDefaultGateways	If IPv6Addresses is implemented, then IPv6StaticDefaultGateways is required.
Id
LinkStatus
Links
Chassis
MACAddress
Name
PermanentMACAddress
StatelessAddressAutoConfig
Status
Health
State
EthernetInterfaceCollection
Manager
ACTIONS
Reset()
DateTime
DateTimeLocalOffset
Description
EthernetInterfaces
FirmwareVersion
Id
Links
ManagerForServers	Must have one of the ‘ManagerFor’ implemented.
ManagerForChassis	Must have one of the ‘ManagerFor’ implemented.
ManagerForSwitches	Must have one of the ‘ManagerFor’ implemented.
ManagerForManagers	Must have one of the ‘ManagerFor’ implemented.
LocationIndicatorActive
ManagerType
Manufacturer
Model
Name
NetworkProtocol
SerialNumber
ServiceEntryPointUUID
Status
Health
State
VirtualMedia	Deprecated. Do not implement.
ManagerCollection
ManagerNetworkProtocol
Description
HTTP
HTTPS
Id
NTP
NTPServers
Port
Name
Proxy
SSDP
NotifyIPv6Scope	Required if IPv6 is implemented.
NotifyMulticastIntervalSeconds
NotifyTTL
Port
ProtocolEnabled

Table 58: Related resources for SwordfishManagementController

4.20.6 Resource Manipulation

The SwordfishManagementController profile requires the resource manipulations listed in Table 59

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Managers	M
EthernetInterface	M/C
DHCPv4	R
DHCPv6	R
Description	M
FQDN	M
HostName	M
IPv4Addresses	M
IPv4StaticAddresses	M
IPv6Addresses	R
IPv6DefaultGateway	M/C
IPv6StaticAddresses	M/C
IPv6StaticDefaultGateways	M/C
Id	M
LinkStatus	M
Links	M
Chassis	M
MACAddress	M
Name	M
PermanentMACAddress	R
StatelessAddressAutoConfig	R
Status	M
Health	M
State	M
EthernetInterfaceCollection	M
Manager	M
ACTIONS
Reset	R
DateTime	M
DateTimeLocalOffset	M
Description	M
EthernetInterfaces	M
FirmwareVersion	M
Id	M
Links	M
ManagerForServers	M/C
ManagerForChassis	M/C
ManagerForSwitches	M/C
ManagerForManagers	M/C
LocationIndicatorActive	M
ManagerType	M
Manufacturer	M
Model	M
Name	M
NetworkProtocol	M
SerialNumber	M
ServiceEntryPointUUID	M
Status	M
Health	M
State	M
VirtualMedia	DNI
ManagerCollection	M
ManagerNetworkProtocol	M
Description	M
HTTP	M
HTTPS	M
Id	M
NTP	M
NTPServers	M
Port	M
Name	M
Proxy	M
SSDP	M
NotifyIPv6Scope	R
NotifyMulticastIntervalSeconds	M
NotifyTTL	M
Port	M
ProtocolEnabled	M

Table 59: Resource manipulations for SwordfishManagementController

4.20.7 Conditional Requirements

4.20.7.1 EthernetInterface

Test Condition / Requirement

When subordinate to [‘Manager’, ‘EthernetInterfaceCollection’], ReadRequirement is Mandatory

based on:

• SubordinatetoResource [‘Manager’, ‘EthernetInterfaceCollection’]
• ReadRequirement: Mandatory

4.20.7.2 IPv6DefaultGateway

Purpose

If IPv6Addresses is implemented, then IPv6DefaultGateway is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.20.7.3 IPv6StaticAddresses

Purpose

If IPv6Addresses is implemented, then IPv6StaticAddresses is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.20.7.4 IPv6StaticDefaultGateways

Purpose

If IPv6Addresses is implemented, then IPv6StaticDefaultGateways is required.

Test Condition / Requirement

if IPv6Addresses is Present, ReadRequirement is Mandatory

based on:

• CompareProperty: IPv6Addresses
• CompareType: Present
• ReadRequirement: Mandatory

4.20.7.5 ManagerForServers

Purpose

Must have one of the ‘ManagerFor’ implemented.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.20.7.6 ManagerForChassis

Purpose

Must have one of the ‘ManagerFor’ implemented.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.20.7.7 ManagerForSwitches

Purpose

Must have one of the ‘ManagerFor’ implemented.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.20.7.8 ManagerForManagers

Purpose

Must have one of the ‘ManagerFor’ implemented.

Test Condition / Requirement

if is Absent, ReadRequirement is Mandatory

based on:

• CompareType: Absent
• ReadRequirement: Mandatory

4.21 SwordfishNVMeDrive profile

4.21.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Define requirements for resources and relationships that are common to all Swordfish conformant implementations of NVMe Drives.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.NVMeDrive

4.21.2 Protocol Information

• Protocol version: 1.18.0

4.21.3 Other Registry Information

4.21.4 Required profiles

4.21.5 Related resources

The SwordfishNVMeDrive profile relies on the resources listed in Table 60

Resource	Purpose
ServiceRoot
Chassis
Storage
Systems	If Storage is attached to a ComputerSystem rather than instantiated as a Standalone instance.
StorageSystems	If Storage is attached to a ComputerSystem rather than instantiated as a Standalone instance.
DriveCollection
Members	MinCount = 1
StorageCollection
Members	MinCount = 1
VolumeCollection
StorageControllerCollection
Members	MinCount = 1
Assembly
BinaryDataURI
Chassis
Drives
Drive
ACTIONS
Reset()	This action resets this drive.
Assembly	The BinaryDataURI property within the Assembly resource in Drive is recommended to be implemented to support mapping a binary blob via NVMe-MI to the VPD.
BlockSizeBytes
CapableSpeedGbs
CapacityBytes
Description
EncryptionAbility
EncryptionStatus	Required when encryption is supported (EncryptionAbility is set to anything other than none).
FailurePredicted	Recommended when controller type is Admin or IO.
Id
Identifiers
DurableName
DurableNameFormat
IndicatorLED	This property is recommended as ‘Do not implement’ for this device and protocol type.
Links
Volumes
Location	This property is recommended as ‘Do not implement’ for this device and protocol type. This property has been deprecated in favor of the PhysicalLocation property.
LocationIndicatorActive
Manufacturer
MediaType
Model
Multipath
Name
NegotiatedSpeedGbs
PhysicalLocation
PartLocation
PredictedMediaLifeLeftPercent
Protocol
PowerMode	Required when MediaType != SSD. If SSD, do not implement.
Revision
RotationSpeedRPM	Required when MediaType != SSD. If SSD, do not implement.
SKU
SerialNumber
Status
State
Health
StatusIndicator
WriteCacheEnabled
Storage
ACTIONS
SetEncryptionKey()	This property is recommended as ‘Do not implement’ for this device and protocol type.
Controllers
Description	Shall be equal to [‘An NVM Express Subsystem is an NVMe device that contains one or more NVM Express controllers and may contain one or more namespaces.’]
Drives
Id
Identifiers
DurableName
DurableNameFormat
Links
Enclosures	This resource shall contain the link to the chassis with the Drive object.
SimpleStorage	This resource is recommended as ‘Do not implement’ for this device and protocol type.
Name
Status
Health
State	This property is recommended as ‘Do not implement’ for this device and protocol type.
HealthRollup
StorageControllers	This resource is recommended as ‘Do not implement’ for this device and protocol type. Use the ‘Controller’ resource instead.
StorageGroups	This resource is recommended as ‘Do not implement’ for this device and protocol type. Note that this function has been deprecated and replaced by Connections in Fabrics.
Volumes
StorageController
Assembly	This property is recommended as ‘Do not implement’ for this device and protocol type. This information is available in the Drive resource if needed.
AssetTag	This property is recommended as ‘Do not implement’ for this device and protocol type. This information is available in the Drive resource if needed.
CacheSummary	This property is recommended as ‘Do not implement’ for this device and protocol type.
ControllerRates	This property is recommended as ‘Do not implement’ for this device and protocol type.
Description	The Description must be set to the designated string when the ControllerType is Admin. There is a different specified value for IO and Discovery. The Description must be set to the designated string when the ControllerType is Discovery. There is a different specified value for Admin and IO. The Description must be set to the designated string when the ControllerType is IO. There is a different specified value for Admin and Discovery.
FirmwareVersion
Links
AttachedVolumes	AttachedVolumes must be implemented when the ControllerType is IO. Do not implement when ControllerType is Discovery or Admin.
Location	This resource is recommended as ‘Do not implement’ for this device and protocol type. Implemented in the ‘Drive’ object as ‘PhysicalLocation’.
Manufacturer	Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported. Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported. Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.
Model	Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller. Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.
NVMeControllerProperties
ControllerType
NVMeVersion	NVMeVersion is required when the underlying NVMe implementation is revision 1.2 or higher.
MaxQueueSize
NVMeControllerAttributes
ReportsNamespaceGranularity
Supports128BitHostId	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
NVMeSMARTCriticalWarnings
MediaInReadOnly
OverallSubsystemDegraded	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
PMRUnreliable
PowerBackupFailed	Recommended when controller type is Admin or IO. Do not implement for Discovery controllers.
SpareCapacityWornOut	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
SpeedGbps	This resource is recommended as ‘Do not implement’ for this device and protocol type.
SKU	This resource is recommended as ‘Do not implement’ for this device and protocol type.
SupportedControllerProtocols
SupportedDeviceProtocols	This resource is recommended as ‘Do not implement’ for this device and protocol type.
SupportedRAIDTypes
PCIeInterface	This property is required for implementations that connect via PCIe (e.g., do not implement for Ethernet-Attach drives).
PCIeType
MaxPCIeType
LanesInUse
MaxLanes
Volume
BlockSizeBytes
Capacity
Data
AllocatedBytes
ConsumedBytes
DisplayName
Description	Shall be equal to [‘A Namespace is a quantity of non-volatile memory that may be formatted into logical blocks. When formatted, a namespace of size n is a collection of logical blocks with logical block addresses from 0 to (n-1). NVMe systems can support multiple namespaces.’]
Id
Identifiers
DurableName
DurableNameFormat
InitializeMethod
LogicalUnitNumber	This resource is recommended as ‘Do not implement’ for this device and protocol type.
NVMeNamespaceProperties
IsShareable
NVMeVersion
NamespaceFeatures
SupportsDeallocatedOrUnwrittenLBError
SupportsNGUIDReuse
SupportsAtomicTransactionSize
SupportsIOPerformanceHints
NamespaceId
MetadataTransferredAtEndOfDataLBA
Links
Controllers	This resource shall contain links to the associated controllers.
Drives	This resource shall contain the link to the Drive object.
Name
OptimumIOSizeBytes
ProvisioningPolicy	Recommended to implement when device supports thin provisioning.
RAIDType
Status
Health
State
HealthRollup	This property is recommended as ‘Do not implement’ for this device and protocol type.
StorageGroups	This resource is recommended as ‘Do not implement’ for this device and protocol type. Note that this function has been deprecated and replaced by Connections in Fabrics.
VolumeType	This property is recommended as ‘Do not implement’ for this device and protocol type. It has been deprecated and replaced by RAIDType.
WriteCachePolicy

Table 60: Related resources for SwordfishNVMeDrive

4.21.6 Resource Manipulation

The SwordfishNVMeDrive profile requires the resource manipulations listed in Table 61

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Chassis	M
Storage	M
Systems	IfImp
StorageSystems	IfImp
DriveCollection	M
Members	M
StorageCollection	M
Members	M
VolumeCollection	M
StorageControllerCollection	M
Members	M
Assembly	R/C
BinaryDataURI	R
Chassis	M
Drives	M
Drive	M
ACTIONS
Reset	M
SecureErase	M
Assembly	R
BlockSizeBytes	M
CapableSpeedGbs	M
CapacityBytes	M
Description	M
EncryptionAbility	M
EncryptionStatus	M/C
FailurePredicted	R/C
Id	M
Identifiers	M
DurableName	M
DurableNameFormat	M
IndicatorLED	DNI
Links	M
Volumes	M
Location	DNI
LocationIndicatorActive	R
Manufacturer	M
MediaType	M
Model	M
Multipath	R
Name	M
NegotiatedSpeedGbs	M
PhysicalLocation	M
PartLocation	M
PredictedMediaLifeLeftPercent	M
Protocol	M
PowerMode	M/C
Revision	M
RotationSpeedRPM	M/C
SKU	M
SerialNumber	M
Status	M
State	M
Health	M
StatusIndicator	M
WriteCacheEnabled	M
Storage	M
ACTIONS
SetEncryptionKey	DNI
Controllers	M
Description	M
Drives	M
Id	M
Identifiers	M
DurableName	M
DurableNameFormat	M
Links	M
Enclosures	M
SimpleStorage	DNI
Name	M
Status	M
Health	M
State	DNI
HealthRollup	M
StorageControllers	DNI
StorageGroups	DNI
Volumes	M
StorageController	M
Assembly	DNI
AssetTag	DNI
CacheSummary	DNI
ControllerRates	DNI
Description	M
FirmwareVersion	M
Links	M
AttachedVolumes	M/C	M/C
Location	DNI
Manufacturer	???
Model	R/C
NVMeControllerProperties	M
ControllerType	M
NVMeVersion	IfImp
MaxQueueSize	M
NVMeControllerAttributes	M
ReportsNamespaceGranularity	R
Supports128BitHostId	M/C
NVMeSMARTCriticalWarnings	M
MediaInReadOnly	M
OverallSubsystemDegraded	M/C
PMRUnreliable	R
PowerBackupFailed	R/C
SpareCapacityWornOut	M/C
SpeedGbps	DNI
SKU	DNI
SupportedControllerProtocols	M
SupportedDeviceProtocols	DNI
SupportedRAIDTypes	M
PCIeInterface	IfImp
PCIeType	M
MaxPCIeType	M
LanesInUse	M
MaxLanes	M
Volume	M
BlockSizeBytes	M
Capacity	M
Data	M
AllocatedBytes	M
ConsumedBytes	M
DisplayName	M
Description	M
Id	M
Identifiers	M
DurableName	M
DurableNameFormat	M
InitializeMethod	R
LogicalUnitNumber	DNI
NVMeNamespaceProperties	M
IsShareable	M
NVMeVersion	M
NamespaceFeatures	M
SupportsDeallocatedOrUnwrittenLBError	M
SupportsNGUIDReuse	M
SupportsAtomicTransactionSize	M
SupportsIOPerformanceHints	M
NamespaceId	M
MetadataTransferredAtEndOfDataLBA	M
Links	M
Controllers	M
Drives	M
Name	M
OptimumIOSizeBytes	R
ProvisioningPolicy	R
RAIDType	M
Status	M
Health	M
State	M
HealthRollup	DNI
StorageGroups	DNI
VolumeType	DNI
WriteCachePolicy	R

Table 61: Resource manipulations for SwordfishNVMeDrive

4.21.7 Conditional Requirements

4.21.7.1 Assembly

Test Condition / Requirement

When subordinate to [‘Drive’], ReadRequirement is Recommended

based on:

• SubordinatetoResource [‘Drive’]
• ReadRequirement: Recommended

4.21.7.2 EncryptionStatus

Purpose

Required when encryption is supported (EncryptionAbility is set to anything other than none).

Test Condition / Requirement

if EncryptionAbility is NotEqual to [‘None’], ReadRequirement is Mandatory

based on:

• CompareProperty: EncryptionAbility
• CompareType: NotEqual
• CompareValues: [‘None’]
• ReadRequirement: Mandatory

4.21.7.3 FailurePredicted

Purpose

Recommended when controller type is Admin or IO.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Recommended

4.21.7.4 PowerMode

Purpose

Required when MediaType != SSD. If SSD, do not implement.

Test Condition / Requirement

if MediaType is NotEqual to [‘SSD’], ReadRequirement is Mandatory

based on:

• CompareProperty: MediaType
• CompareType: NotEqual
• CompareValues: [‘SSD’]
• ReadRequirement: Mandatory

4.21.7.5 RotationSpeedRPM

Purpose

Required when MediaType != SSD. If SSD, do not implement.

Test Condition / Requirement

if MediaType is NotEqual to [‘SSD’], ReadRequirement is Mandatory

based on:

• CompareProperty: MediaType
• CompareType: NotEqual
• CompareValues: [‘SSD’]
• ReadRequirement: Mandatory

4.21.7.6 Description

Purpose

The Description must be set to the designated string when the ControllerType is Admin. There is a different specified value for IO and Discovery.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’]

Purpose

The Description must be set to the designated string when the ControllerType is Discovery. There is a different specified value for Admin and IO.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]

Purpose

The Description must be set to the designated string when the ControllerType is IO. There is a different specified value for Admin and Discovery.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]

4.21.7.7 AttachedVolumes

Purpose

AttachedVolumes must be implemented when the ControllerType is IO. Do not implement when ControllerType is Discovery or Admin.

Test Condition / Requirement

if ControllerType is Equal to [‘IO’], WriteRequirement is Mandatory, ReadRequirement is Mandatory

based on:

• CompareProperty: ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• WriteRequirement: Mandatory
• ReadRequirement: Mandatory

4.21.7.8 Manufacturer

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• ReadRequirement: Mandatory

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]
• ReadRequirement: Recommended

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’], ReadRequirement is None

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’]
• ReadRequirement: None

4.21.7.9 Model

Purpose

Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• ReadRequirement: Mandatory

Purpose

Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]
• ReadRequirement: Recommended

4.21.7.10 Supports128BitHostId

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.21.7.11 OverallSubsystemDegraded

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.21.7.12 PowerBackupFailed

Purpose

Recommended when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Recommended

4.21.7.13 SpareCapacityWornOut

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.22 SwordfishNVMeDriveAdvancedFeatures profile

4.22.1 Summary Information

• Version: 1.1.2
• Contact Information: SNIA.org
• Purpose: Define requirements for resources and relationships for Advanced Features (implementing NVMe Endurance Groups and NVM Sets) on Swordfish conformant implementations of NVMe Drives.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.NVMeDriveAdvancedFeatures

4.22.2 Protocol Information

No protocol information defined in this profile.

4.22.3 Other Registry Information

4.22.4 Required profiles

The SwordfishNVMeDriveAdvancedFeatures profile depends upon the profiles listed in Table 62 .

Profile	Version	Conditions
SwordfishNVMeDrive	1.3.0

Table 62: Required profiles for SwordfishNVMeDriveAdvancedFeatures

4.22.5 Related resources

The SwordfishNVMeDriveAdvancedFeatures profile relies on the resources listed in Table 63

Resource	Purpose
StoragePoolCollection
Members	MinCount = 1
Storage
StoragePools
StorageController
NVMeControllerProperties
NVMeControllerAttributes
SupportsEnduranceGroups
SupportsNVMSets
StoragePool
AllocatedPools	Required when NVMePoolType = EnduranceGroup. If NVMSet, do not implement.
Capacity
Data
AllocatedBytes
ConsumedBytes
CapacitySources	Required only when NVMePoolType = EnduranceGroup. Not required for NVM Sets.
Description	The Description must be set to the designated string when the NVMePoolType is set to EnduranceGroup. There is a different specified value for NVMSet. The Description must be set to the designated string when the NVMePoolType is set to NVMSet. There is a different specified value for EnduranceGroup.
Id
Identifier
Links
OwningStorageResource	Required only when NVMePoolType = EnduranceGroup. Not required for NVM Sets.
Name
NVMeEnduranceGroupProperties
EndGrpLifetime
DataUnitsRead	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
DataUnitsWritten	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
EnduranceEstimate	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
ErrorInformationLogEntryCount	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
HostReadCommandCount	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
HostWriteCommandCount	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
MediaAndDataIntegrityErrorCount	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
MediaUnitsWritten	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
PercentUsed	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
PredictedMediaLifeLeftPercent	Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.
NVMeSetProperties
EnduranceGroupIdentifier	Required only when NVMePoolType = NVMSet. Otherwise, do not implement.
OptimalWriteSizeBytes	Required only when NVMePoolType = NVMSet. Otherwise, do not implement.
Random4kReadTypicalNanoSeconds	Required only when NVMePoolType = NVMSet. Otherwise, do not implement.
SetIdentifier	Required only when NVMePoolType = NVMSet. Otherwise, do not implement.
UnallocatedNVMNamespaceCapacityBytes	Required only when NVMePoolType = NVMSet. Otherwise, do not implement.
Status
State	This property is recommended as ‘Do not implement’ for this device and protocol type.
Health	This property is recommended as ‘Do not implement’ for this device and protocol type.

Table 63: Related resources for SwordfishNVMeDriveAdvancedFeatures

4.22.6 Resource Manipulation

The SwordfishNVMeDriveAdvancedFeatures profile requires the resource manipulations listed in Table 64

Resource	Read	Write	Create	Delete	Update
StoragePoolCollection	M
Members	M
Storage	M
StoragePools	M
StorageController	M
NVMeControllerProperties	M
NVMeControllerAttributes	M
SupportsEnduranceGroups	M
SupportsNVMSets	M
StoragePool	M
AllocatedPools	M/C
Capacity	M
Data	M
AllocatedBytes	M
ConsumedBytes	M
CapacitySources	M/C
Description	M
Id	M
Identifier	M
Links	S
OwningStorageResource	M/C
Name	M
NVMeEnduranceGroupProperties	S
EndGrpLifetime	M
DataUnitsRead	M/C
DataUnitsWritten	M/C
EnduranceEstimate	M/C
ErrorInformationLogEntryCount	M/C
HostReadCommandCount	M/C
HostWriteCommandCount	M/C
MediaAndDataIntegrityErrorCount	M/C
MediaUnitsWritten	M/C
PercentUsed	M/C
PredictedMediaLifeLeftPercent	M/C
NVMeSetProperties	S
EnduranceGroupIdentifier	M/C
OptimalWriteSizeBytes	M/C
Random4kReadTypicalNanoSeconds	M/C
SetIdentifier	M/C
UnallocatedNVMNamespaceCapacityBytes	M/C
Status	???
State	???
Health	???

Table 64: Resource manipulations for SwordfishNVMeDriveAdvancedFeatures

4.22.7 Conditional Requirements

4.22.7.1 StorageController

Test Condition / Requirement

When subordinate to [‘Storage’, ‘StorageCollection’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Storage’, ‘StorageCollection’]

4.22.7.2 StoragePool

Test Condition / Requirement

When subordinate to [‘Storage’, ‘StorageCollection’], ReadRequirement is mandatory

based on:

• SubordinatetoResource [‘Storage’, ‘StorageCollection’]

4.22.7.3 AllocatedPools

Purpose

Required when NVMePoolType = EnduranceGroup. If NVMSet, do not implement.

Test Condition / Requirement

if /NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: /NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.4 CapacitySources

Purpose

Required only when NVMePoolType = EnduranceGroup. Not required for NVM Sets.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.5 Description

Purpose

The Description must be set to the designated string when the NVMePoolType is set to EnduranceGroup. There is a different specified value for NVMSet.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]

Purpose

The Description must be set to the designated string when the NVMePoolType is set to NVMSet. There is a different specified value for EnduranceGroup.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]

4.22.7.6 OwningStorageResource

Purpose

Required only when NVMePoolType = EnduranceGroup. Not required for NVM Sets.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.7 DataUnitsRead

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.8 DataUnitsWritten

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.9 EnduranceEstimate

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.10 ErrorInformationLogEntryCount

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.11 HostReadCommandCount

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.12 HostWriteCommandCount

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.13 MediaAndDataIntegrityErrorCount

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.14 MediaUnitsWritten

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.15 PercentUsed

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.16 PredictedMediaLifeLeftPercent

Purpose

Required only when NVMePoolType = EnduranceGroup. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘EnduranceGroup’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘EnduranceGroup’]
• ReadRequirement: Mandatory

4.22.7.17 EnduranceGroupIdentifier

Purpose

Required only when NVMePoolType = NVMSet. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]
• ReadRequirement: Mandatory

4.22.7.18 OptimalWriteSizeBytes

Purpose

Required only when NVMePoolType = NVMSet. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]
• ReadRequirement: Mandatory

4.22.7.19 Random4kReadTypicalNanoSeconds

Purpose

Required only when NVMePoolType = NVMSet. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]
• ReadRequirement: Mandatory

4.22.7.20 SetIdentifier

Purpose

Required only when NVMePoolType = NVMSet. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]
• ReadRequirement: Mandatory

4.22.7.21 UnallocatedNVMNamespaceCapacityBytes

Purpose

Required only when NVMePoolType = NVMSet. Otherwise, do not implement.

Test Condition / Requirement

if NVMeProperties/NVMePoolType is Equal to [‘NVMSet’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeProperties/NVMePoolType
• CompareType: Equal
• CompareValues: [‘NVMSet’]
• ReadRequirement: Mandatory

4.23 SwordfishNVMeEBOF profile

4.23.1 Summary Information

• Version: 1.2.1
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish NVMe EBOF Requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.NVMeEBOF

4.23.2 Protocol Information

No protocol information defined in this profile.

4.23.3 Other Registry Information

4.23.4 Required profiles

The SwordfishNVMeEBOF profile depends upon the profiles listed in Table 65 .

Profile	Version	Conditions
SwordfishFabricAccessRightsforEthernet	1.0.2
SwordfishFabricConnectivityRightsforEthernet	1.0.2
SwordfishManagementController	1.0.2
SwordfishNVMeEthernetAttach	1.2.1

Table 65: Required profiles for SwordfishNVMeEBOF

4.23.5 Related resources

None defined. ### Resource Manipulation

None defined. ### Conditional Requirements

None defined.

4.24 SwordfishNVMeEthernetAttach profile

4.24.1 Summary Information

• Version: 1.2.1
• Contact Information: SNIA.org
• Purpose: Define requirements for resources and relationships for Ethernet Attach support on Swordfish conformant implementations of NVMe Drives.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.5.1
• Supported Features
  • SNIA.Swordfish.NVMeDriveEthernetAttach

4.24.2 Protocol Information

No protocol information defined in this profile.

4.24.3 Other Registry Information

4.24.4 Required profiles

The SwordfishNVMeEthernetAttach profile depends upon the profiles listed in Table 66 .

Profile	Version	Conditions
SwordfishNVMeDrive	1.2.1

Table 66: Required profiles for SwordfishNVMeEthernetAttach

4.24.5 Related resources

The SwordfishNVMeEthernetAttach profile relies on the resources listed in Table 67

Resource	Purpose
NetworkAdapterCollection
Members	MinCount = 1
NetworkDeviceFunctionCollection
Members	MinCount = 1
PortCollection
Members	MinCount = 1
StorageController
NVMeControllerProperties
NVMeControllerAttributes
SupportsTrafficBasedKeepAlive	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
PCIeInterface	This property is only required for implementations that connect via PCIe - do not implement for Ethernet-Attach drives.
Volume
OptimumIOSizeBytes
NetworkAdapter
Controllers
ControllerCapabilities
DataCenterBridging
Capable
NetworkDeviceFunctionCount
NetworkPortCount
VirtualizationOffload	This property is required for implementations that connect via PCIe (e.g., do not implement for Ethernet-Attach drives).
FirmwarePackageVersion
Links
NetworkDeviceFunctions
Ports
Location	This property is recommended as ‘Do not implement’ for this device and protocol type.
Description
Id
Location	This property is recommended as ‘Do not implement’ for this device and protocol type.
Manufacturer
Model
Name
NetworkDeviceFunctions
PartNumber
Ports
SKU
SerialNumber
NetworkDeviceFunction
AssignablePhysicalNetworkPorts
Description
DeviceEnabled
Ethernet
MACAddress
MTUSize
MTUSizeMaximum
PermanentMACAddress
FibreChannel	This property is recommended as ‘Do not implement’ for this device and protocol type.
InfiniBand	This property is recommended as ‘Do not implement’ for this device and protocol type.
Links
Endpoints
EthernetInterface	This property is recommended as ‘Do not implement’ for this device and protocol type.
PhysicalNetworkPortAssignment
Name
NetDevFuncCapabilities
NetDevFuncType
iSCSIBoot	This property is recommended as ‘Do not implement’ for this device and protocol type.
Port
CurrentSpeedGbps
Description
Ethernet
FlowControlConfiguration
FlowControlStatus
EEEEnabled
WakeOnLANEnabled
FibreChannel	This property is recommended as ‘Do not implement’ for this device and protocol type.
GenZ	This property is recommended as ‘Do not implement’ for this device and protocol type.
Id
LinkConfiguration
AutoSpeedNegotiationCapable
AutoSpeedNegotiationEnabled
CapableLinkSpeedGbps
ConfiguredNetworkLinks
ConfiguredLinkSpeedGbps
ConfiguredWidth
LinkNetworkTechnology
LinkState
LinkStatus
Location	This property is recommended as ‘Do not implement’ for this device and protocol type.
MaxFrameSize
MaxSpeedGbps
Name
PortId	This property is recommended as ‘Do not implement’ for this device and protocol type.
PortMedium
PortProtocol	This property is recommended as ‘Do not implement’ for this device and protocol type.
PortType	This property is recommended as ‘Do not implement’ for this device and protocol type.
SignalDetected
Width

Table 67: Related resources for SwordfishNVMeEthernetAttach

4.24.6 Resource Manipulation

The SwordfishNVMeEthernetAttach profile requires the resource manipulations listed in Table 68

Resource	Read	Write	Create	Delete	Update
NetworkAdapterCollection	M
Members	M
NetworkDeviceFunctionCollection	M
Members	M
PortCollection	M
Members	M
StorageController	M
NVMeControllerProperties	M
NVMeControllerAttributes	M
SupportsTrafficBasedKeepAlive	M/C
PCIeInterface	DNI
Volume	M
OptimumIOSizeBytes	M
NetworkAdapter	M
Controllers	M
ControllerCapabilities	M
DataCenterBridging	M
Capable	M
NetworkDeviceFunctionCount	M
NetworkPortCount	M
VirtualizationOffload	DNI
FirmwarePackageVersion	M
Links	M
NetworkDeviceFunctions	M
Ports	M
Location	DNI
Description	M
Id	M
Location	DNI
Manufacturer	M
Model	M
Name	M
NetworkDeviceFunctions	M
PartNumber	M
Ports	M
SKU	M
SerialNumber	M
NetworkDeviceFunction	M
AssignablePhysicalNetworkPorts	M
Description	M
DeviceEnabled	M
Ethernet	M
MACAddress	M
MTUSize	M
MTUSizeMaximum	M
PermanentMACAddress	M
FibreChannel	DNI
InfiniBand	DNI
Links	M
Endpoints	M
EthernetInterface	DNI
PhysicalNetworkPortAssignment	M
Name	M
NetDevFuncCapabilities	M
NetDevFuncType	M
iSCSIBoot	DNI
Port	M
CurrentSpeedGbps	M
Description	M
Ethernet	M
FlowControlConfiguration	M
FlowControlStatus	M
EEEEnabled	M
WakeOnLANEnabled	M
FibreChannel	DNI
GenZ	DNI
Id	M
LinkConfiguration	M
AutoSpeedNegotiationCapable	M
AutoSpeedNegotiationEnabled	M
CapableLinkSpeedGbps	M
ConfiguredNetworkLinks	M
ConfiguredLinkSpeedGbps	M
ConfiguredWidth	M
LinkNetworkTechnology	M
LinkState	M
LinkStatus	M
Location	DNI
MaxFrameSize	M
MaxSpeedGbps	M
Name	M
PortId	DNI
PortMedium	M
PortProtocol	DNI
PortType	DNI
SignalDetected	M
Width	M

Table 68: Resource manipulations for SwordfishNVMeEthernetAttach

4.24.7 Conditional Requirements

4.24.7.1 SupportsTrafficBasedKeepAlive

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.25 SwordfishNVMeFrontEnd profile

4.25.1 Summary Information

• Version: 1.3.0
• Contact Information: SNIA.org
• Purpose: Defines requirements for Swordfish implementations with NVMe front-end interfaces, such as storage arrays.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.SwordfishNVMeFrontEnd

4.25.2 Protocol Information

• Protocol version: 1.18.0

4.25.3 Other Registry Information

4.25.4 Required profiles

The SwordfishNVMeFrontEnd profile depends upon the profiles listed in Table 69 .

Profile	Version	Conditions
CoSDiscovery	1.2.0	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.
SwordfishDiscovery	1.1.4	Required Either SwordfishDiscovery or SwordfishCoSDiscovery must be supported.

Table 69: Required profiles for SwordfishNVMeFrontEnd

4.25.5 Related resources

The SwordfishNVMeFrontEnd profile relies on the resources listed in Table 70

Resource	Purpose
ServiceRoot
Chassis
StorageCollection
Members	MinCount = 1
VolumeCollection
StorageControllerCollection
Members	MinCount = 1
Assembly
BinaryDataURI
Chassis
NetworkAdapters
Storage
ACTIONS
SetEncryptionKey()	This property is recommended as ‘Do not implement’ for this device and protocol type.
Controllers	Controllers are required for Storage instances representing the NVMeFrontEnd. They are not required for Storage instances representing embedded, or back-end NVMe devices.
Description	Shall be equal to [‘An NVM Express Subsystem is an NVMe device that contains one or more NVM Express controllers and may contain one or more namespaces.’]
Id
Identifiers
DurableName
DurableNameFormat
Links
Enclosures	This resource shall contain the link to the chassis with the Drive object.
SimpleStorage	This resource is recommended as ‘Do not implement’ for this device and protocol type.
Name
Status
Health
State	Map the device’s concept of ’Enabled / Disabled / etc. to the state reflected by the NVM Subsystem. There aren’t NVMe specific properties to correspond; these should map from the underlying device’s state. This should reflect the NVMe portion of the device, not the non-NVMe characteristics.
HealthRollup
StorageControllers	This resource is recommended as ‘Do not implement’ for this device and protocol type. Use the ‘Controller’ resource instead.
StorageGroups	This resource is recommended as ‘Do not implement’ for this device and protocol type. Note that this function has been deprecated and replaced by Connections in Fabrics.
Volumes
StorageController
Assembly	This property is recommended as ‘Do not implement’ for this device and protocol type. This information is available in the Drive resource if needed.
AssetTag	This property is recommended as ‘Do not implement’ for this device and protocol type. This information is available in the Drive resource if needed.
CacheSummary	This property is recommended as ‘Do not implement’ for this device and protocol type.
ControllerRates	This property is recommended as ‘Do not implement’ for this device and protocol type.
Description	The Description must be set to the designated string when the ControllerType is Admin. There is a different specified value for IO and Discovery. The Description must be set to the designated string when the ControllerType is Discovery. There is a different specified value for Admin and IO. The Description must be set to the designated string when the ControllerType is IO. There is a different specified value for Admin and Discovery.
FirmwareVersion
Id
Links
AttachedVolumes	AttachedVolumes must be implemented when the ControllerType is IO. Do not implement when ControllerType is Discovery or Admin.
NetworkDeviceFunctions
Location	This resource is recommended as ‘Do not implement’ for this device and protocol type. Implemented in the ‘Drive’ object as ‘PhysicalLocation’.
Manufacturer	Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported. Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported. Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.
Model	Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller. Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.
SpeedGbps	This resource is recommended as ‘Do not implement’ for this device and protocol type.
SKU	This resource is recommended as ‘Do not implement’ for this device and protocol type.
Status
Health
State
SupportedControllerProtocols
SupportedDeviceProtocols	This resource is recommended as ‘Do not implement’ for this device and protocol type.
NVMeControllerProperties
ControllerType
NVMeVersion	NVMeVersion is required when the underlying NVMe implementation is revision 1.2 or higher.
MaxQueueSize
NVMeControllerAttributes
ReportsNamespaceGranularity
Supports128BitHostId	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
SupportsReservations
SupportsTrafficBasedKeepAlive	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
NVMeSMARTCriticalWarnings
MediaInReadOnly
OverallSubsystemDegraded	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
PMRUnreliable
PowerBackupFailed	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
SpareCapacityWornOut	Required when controller type is Admin or IO. Do not implement for Discovery controllers.
Volume
BlockSizeBytes
Capacity
Data
AllocatedBytes
ConsumedBytes
DisplayName
Description	Shall be equal to [‘A Namespace is a quantity of non-volatile memory that may be formatted into logical blocks. When formatted, a namespace of size n is a collection of logical blocks with logical block addresses from 0 to (n-1). NVMe systems can support multiple namespaces.’]
Id
Identifiers
DurableName
DurableNameFormat
InitializeMethod
Links
Controllers	This resource shall contain links to the associated controllers.
LogicalUnitNumber	This resource is recommended as ‘Do not implement’ for this device and protocol type.
Name
NVMeNamespaceProperties
IsShareable
NVMeVersion
NamespaceFeatures
SupportsDeallocatedOrUnwrittenLBError
SupportsNGUIDReuse
SupportsAtomicTransactionSize
SupportsIOPerformanceHints
SupportsThinProvisioning
NamespaceId
MetadataTransferredAtEndOfDataLBA
OptimumIOSizeBytes
ProvisioningPolicy	Recommended to implement when device supports thin provisioning.
RAIDType
Status
Health
State
HealthRollup	This property is recommended as ‘Do not implement’ for this device and protocol type.
StorageGroups	This resource is recommended as ‘Do not implement’ for this device and protocol type. Note that this function has been deprecated and replaced by Connections in Fabrics.
VolumeType	This property is recommended as ‘Do not implement’ for this device and protocol type. It has been deprecated and replaced by RAIDType.
WriteCachePolicy

Table 70: Related resources for SwordfishNVMeFrontEnd

4.25.6 Resource Manipulation

The SwordfishNVMeFrontEnd profile requires the resource manipulations listed in Table 71

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Chassis	M
StorageCollection	M
Members	M
VolumeCollection	M
StorageControllerCollection	M
Members	M
Assembly	R
BinaryDataURI	R
Chassis	M
NetworkAdapters	IfImp
Storage	M
ACTIONS
SetEncryptionKey	DNI
Controllers	IfImp
Description	M
Id	M
Identifiers	M
DurableName	M
DurableNameFormat	M
Links	M
Enclosures	M
SimpleStorage	DNI
Name	M
Status	M
Health	M
State	M
HealthRollup	M
StorageControllers	DNI
StorageGroups	DNI
Volumes	M
StorageController	M
Assembly	DNI
AssetTag	DNI
CacheSummary	DNI
ControllerRates	DNI
Description	M
FirmwareVersion	M
Id	M
Links	M
AttachedVolumes	M/C	M/C
NetworkDeviceFunctions	R
Location	DNI
Manufacturer	???
Model	R/C
SpeedGbps	DNI
SKU	DNI
Status	M
Health	M
State	M
SupportedControllerProtocols	M
SupportedDeviceProtocols	DNI
NVMeControllerProperties	M
ControllerType	M
NVMeVersion	IfImp
MaxQueueSize	M
NVMeControllerAttributes	M
ReportsNamespaceGranularity	R
Supports128BitHostId	M/C
SupportsReservations	M
SupportsTrafficBasedKeepAlive	M/C
NVMeSMARTCriticalWarnings	M
MediaInReadOnly	M
OverallSubsystemDegraded	M/C
PMRUnreliable	R
PowerBackupFailed	M/C
SpareCapacityWornOut	M/C
Volume	M
BlockSizeBytes	M
Capacity	M
Data	M
AllocatedBytes	M
ConsumedBytes	M
DisplayName	M
Description	M
Id	M
Identifiers	M
DurableName	M
DurableNameFormat	M
InitializeMethod	R
Links	M
Controllers	M
LogicalUnitNumber	DNI
Name	M
NVMeNamespaceProperties	M
IsShareable	M
NVMeVersion	M
NamespaceFeatures	M
SupportsDeallocatedOrUnwrittenLBError	M
SupportsNGUIDReuse	M
SupportsAtomicTransactionSize	M
SupportsIOPerformanceHints	M
SupportsThinProvisioning	M
NamespaceId	M
MetadataTransferredAtEndOfDataLBA	M
OptimumIOSizeBytes	R
ProvisioningPolicy	R
RAIDType	M
Status	M
Health	M
State	M
HealthRollup	DNI
StorageGroups	DNI
VolumeType	DNI
WriteCachePolicy	R

Table 71: Resource manipulations for SwordfishNVMeFrontEnd

4.25.7 Conditional Requirements

4.25.7.1 Description

Purpose

The Description must be set to the designated string when the ControllerType is Admin. There is a different specified value for IO and Discovery.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’]

Purpose

The Description must be set to the designated string when the ControllerType is Discovery. There is a different specified value for Admin and IO.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]

Purpose

The Description must be set to the designated string when the ControllerType is IO. There is a different specified value for Admin and Discovery.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]

4.25.7.2 AttachedVolumes

Purpose

AttachedVolumes must be implemented when the ControllerType is IO. Do not implement when ControllerType is Discovery or Admin.

Test Condition / Requirement

if ControllerType is Equal to [‘IO’], WriteRequirement is Mandatory, ReadRequirement is Mandatory

based on:

• CompareProperty: ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• WriteRequirement: Mandatory
• ReadRequirement: Mandatory

4.25.7.3 Manufacturer

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• ReadRequirement: Mandatory

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]
• ReadRequirement: Recommended

Purpose

Manufacturer must be implemented when the ControllerType is IO. It may be implemented for a Discovery controller. It is generally optional for an Admin controller, but should not be implemented when NVMeoF is supported.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’], ReadRequirement is None

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’]
• ReadRequirement: None

4.25.7.4 Model

Purpose

Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘IO’]
• ReadRequirement: Mandatory

Purpose

Model must be implemented when the ControllerType is IO. It is recommended to implement when ControllerType is Admin, and may be implemented for a Discovery controller.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Discovery’], ReadRequirement is Recommended

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Discovery’]
• ReadRequirement: Recommended

4.25.7.5 Supports128BitHostId

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.25.7.6 SupportsTrafficBasedKeepAlive

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.25.7.7 OverallSubsystemDegraded

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.25.7.8 PowerBackupFailed

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.25.7.9 SpareCapacityWornOut

Purpose

Required when controller type is Admin or IO. Do not implement for Discovery controllers.

Test Condition / Requirement

if NVMeControllerProperties/ControllerType is Equal to [‘Admin’, ‘IO’], ReadRequirement is Mandatory

based on:

• CompareProperty: NVMeControllerProperties/ControllerType
• CompareType: Equal
• CompareValues: [‘Admin’, ‘IO’]
• ReadRequirement: Mandatory

4.26 SwordfishNVMeoF profile

4.26.1 Summary Information

• Version: 1.2.0
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish NVMe over Fabrics Requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.NVMeoF

4.26.2 Protocol Information

• Protocol version: 1.18.0

4.26.3 Other Registry Information

4.26.4 Required profiles

The SwordfishNVMeoF profile depends upon the profiles listed in Table 72 .

Profile	Version	Conditions
SwordfishBlockProvisioning	1.3.0
SwordfishDiscovery	1.1.4
SwordfishFabricAccessRights	1.0.2	Required Either SwordfishFabricAccessRightsforEthernet or SwordfishFabricAccessRights must be supported.
SwordfishFabricAccessRightsforEthernet	1.0.2	Required Either SwordfishFabricAccessRightsforEthernet or SwordfishFabricAccessRights must be supported.
SwordfishFabricConnectivityRightsforEthernet	1.0.2	Required Either SwordfishFabricConnectivityRightsforEthernet or SwordfishFabricConnectivityRightsforRDMA must be supported.
SwordfishFabricConnectivityRightsforRDMA	1.0.2	Required Either SwordfishFabricConnectivityRightsforEthernet or SwordfishFabricConnectivityRightsforRDMA must be supported.

Table 72: Required profiles for SwordfishNVMeoF

4.26.5 Related resources

The SwordfishNVMeoF profile relies on the resources listed in Table 73

Resource	Purpose
ServiceRoot
Storage
Storage
Controllers
StorageController
Manufacturer	Manufacturer should not be implemented when NVMeoF is supported.

Table 73: Related resources for SwordfishNVMeoF

4.26.6 Resource Manipulation

The SwordfishNVMeoF profile requires the resource manipulations listed in Table 74

Resource	Read	Write	Create	Delete	Update
ServiceRoot	M
Storage	M
Storage	M
Controllers	M
StorageController	M
Manufacturer	DNI

Table 74: Resource manipulations for SwordfishNVMeoF

4.26.7 Conditional Requirements

None defined.

4.27 SwordfishPCIeJBOF profile

4.27.1 Summary Information

• Version: 1.2.1
• Contact Information: SNIA.org
• Purpose: Defines the Swordfish PCIe JBOF Requirements.
• Owning Entity: SNIA.org
• Introduced in: SwordfishFeatureRegistry version 1.6.0
• Supported Features
  • SNIA.Swordfish.PCIeJBOF

4.27.2 Protocol Information

No protocol information defined in this profile.

4.27.3 Other Registry Information

4.27.4 Required profiles

The SwordfishPCIeJBOF profile depends upon the profiles listed in Table 75 .

Profile	Version	Conditions
SwordfishManagementController	1.0.2
SwordfishNVMeDrive	1.3.0

Table 75: Required profiles for SwordfishPCIeJBOF

4.27.5 Related resources

None defined. ### Resource Manipulation

None defined. ### Conditional Requirements

None defined.
